2004 INFINITI QX56 COMBINATION METER

AV-122
NAVIGATION SYSTEM
Revision: August 20072004 QX56
Vehicle Speed Signal Check for Display Control UnitEKS007M4
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect display control unit connector, combination meter connector, NAVI control unit connector and
shift lock control unit connector.
3. Check continuity between display control unit harness connector
M94 terminal 16 (W/R) and combination meter harness connec-
tor M24 terminal 29 (W/R).
4. Check continuity between display control unit harness connector
M94 terminal 16 (W/R) and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness.
2. CHECK 1: VEHICLE SPEED SIGNAL
1. Connect display control unit connector.
2. Turn ignition switch ON.
3. Check voltage between display control unit harness connector
M94 terminal 16 (W/R) and ground.
OK or NG
OK >> GO TO 3.
NG >> Replace display control unit. Refer to AV- 1 5 8 , "
Removal
and Installation of Display Control Unit" .
3. CHECK 2: VEHICLE SPEED SIGNAL
1. Connect combination meter connector, NAVI control unit connector and shift lock control unit connector.
2. Drive vehicle at a constant speed.
3. Check signal between display control unit harness connector
M94 terminal 16 (W/R) and ground with CONSULT-ll or oscillo-
scope.
OK or NG
OK >> Replace display control unit. Refer to AV- 1 5 8 , "Removal
and Installation of Display Control Unit" .
NG >> Check combination meter system. Refer to DI-19, "
Vehi-
cle Speed Signal Inspection" . Continuity should exist.
Continuity should not exist.
WKIA1506E
Approx. 3.5V or more
SKIA4297E
16 (W/R) – Ground : Refer to AV- 9 2 , "Terminals
and Reference Value for Dis-
play Control unit" .
SKIA4616E

BCS-6
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56

When BCM is in sleep mode, transistors of OUTPUT 1 and 5 stop the output, and BCM enters low-cur-
rent-consumption mode. OUTPUTS (2, 3, and 4) turn ON-OFF at 60 ms intervals, and receives lighting
switch input only.
CAN COMMUNICATION CONTROL
CAN communication allows a high rate of information through the two communication lines (CAN-L, CAN-H)
connecting the various control units in the system. Each control unit transmits/receives data, but selectively
reads required data only.
BCM STATUS CONTROL
BCM changes its status depending on the operation status in order to save power consumption.
1. CAN communication status

With ignition switch ON, CAN communicates with other control units normally.

Control by BCM is being operated properly.

When ignition switch is OFF, switching to sleep mode is possible.

Even when ignition switch is OFF, if CAN communication with IPDM E/R and combination meter is
active, CAN communication status is active.
2. Sleep transient status

This status shuts down CAN communication when ignition switch is turned OFF.

It transmits sleep request signal to IPDM E/R and combination meter.

Two seconds after CAN communication of all control units stops, CAN communication switches to inac-
tive status.
3. CAN communication inactive status

With ignition switch OFF, CAN communication is not active.

With ignition switch OFF, control performed only by BCM is active.

Three seconds after CAN communication of all control units stops, CAN communication switches to
inactive status.
4. Sleep status
WKIA4093E

BCS-8
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56
CAN Communication System DescriptionEKS007GF
Refer to LAN-5, "CAN COMMUNICATION" .
Power supply (BAT) to power window and
sunroofBattery power supply Power supply to power window and sunroof system
Panic alarm

Key switch

KeyfobIPDM E/R
Auto light system

Auto light sensor

Combination switchIPDM E/R
Battery saver control

Ignition switch

Combination switch

Front door switch LH

Front door switch RHIPDM E/R
Headlamp Combination switch IPDM E/R
Tail lamp Combination switch IPDM E/R
Fog lamp Combination switch IPDM E/R
Turn signal lamp Combination switch

Turn signal lamp

Combination meter
Hazard lamp Hazard switch

Turn signal lamp

Combination meter
Room lamp timer

Key switch

Keyfob

Main power window and door
lock/unlock switch

Front door lock assembly LH
(key cylinder switch)

All door switchInterior room lamp
Key warning chime

Key switch

Front door switch LHCombination meter (warning buzzer)
Light warning chime

Combination switch

Key switch

Front door switch LHCombination meter (warning buzzer)
Vehicle-speed-sensing intermittent wiper

Combination switch

Combination meterIPDM E/R
Rear window defogger Rear window defogger switch IPDM E/R
Air conditioner switch signal Front air control ECM
Blower fan switch signal Front air control ECM
Low tire pressure warning system Remote keyless entry receiver

Combination meter

Display control unit
Trailer tow Combination switch Trailer turn signal lamp
Vehicle security system

Remote keyless entry receiver
(Keyfob)

Main power window and door
lock/unlock switch

Power window and door lock/
unlock switch RH

Front door lock assembly LH
(key cylinder switch)

All door switch

Glass hatch ajar switch

IPDM E/R

Security indicator lamp System Input Output
