2004 INFINITI QX56 COMBINATION METER

WT-20
TROUBLE DIAGNOSES
Revision: August 20072004 QX56
Preliminary CheckEES0012F
BASIC INSPECTION
1. CHECK ALL TIRE PRESSURES
Check all tire pressures. Refer to WT-33, "
Tire" .
OK or NG
OK >> GO TO 2.
NG >> Adjust tire pressure to specified value.
2. CHECK LOW TIRE PRESSURE WARNING LAMP ACTIVATION
Check low tire pressure warning lamp activation.
Does low tire pressure warning lamp activate for 1 second when ignition switch is turned ON?
YES >> GO TO 3.
NO >> Check fuse and combination meter.
3. CHECK CONNECTOR
1. Disconnect BCM harness connector.
2. Check terminals for damage or loose connection.
3. Reconnect harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4. CHECK TRANSMITTER ACTIVATION TOOL
Check transmitter activation tool battery.
OK or NG
OK >> Carry out self-diagnosis.
NG >> Replace transmitter activation tool battery.

TROUBLE DIAGNOSES
WT-21
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: August 20072004 QX56
Malfunction Code/Symptom ChartEES0012G
Code/Symptom Malfunction partReference
page
15
16
17
18Front-left tire pressure drops to 193 kPa (2.0 kg/cm
2 , 28 psi) or less
Front-right tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less
Rear-right tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less
Rear-left tire pressure drops to 193 kPa (2.0 kg/cm2 , 28 psi) or less—
21
22
23
24Transmitter no data (front - left)
Transmitter no data (front - right)
Transmitter no data (rear - right)
Transmitter no data (rear - left)WT-23,
"Inspection 1:
Transmitter or
Control Unit
(BCM)"
31
32
33
34Transmitter checksum error (front - left)
Transmitter checksum error (front - right)
Transmitter checksum error (rear - right)
Transmitter checksum error (rear - left)WT-23,
"Inspection 2:
Tran s mitte r -
1"
35
36
37
38Transmitter pressure data error (front - left)
Transmitter pressure data error (front - right)
Transmitter pressure data error (rear - right)
Transmitter pressure data error (rear - left)WT-24,
"Inspection 3:
Tran s mitte r -
2"
41
42
43
44Transmitter function code error (front - left)
Transmitter function code error (front - right)
Transmitter function code error (rear - right)
Transmitter function code error (rear - left)WT-23,
"Inspection 2:
Tran s mitte r -
1"
45
46
47
48Transmitter battery voltage low (front - left)
Transmitter battery voltage low (front - right)
Transmitter battery voltage low (rear - right)
Transmitter battery voltage low (rear - left)WT-23,
"Inspection 2:
Tran s mitte r -
1"
52 Vehicle speed signalWT-25, "Inspection 4:
Vehicle Speed
Signal"
Low tire pressure warning lamp does
not come on when ignition switch is
turned on.Fuse or combination meter
BCM connector or circuit
BCM WT-26,
"Inspection 1:
Low Tire
Pressure
Warning
Lamp Does
Not Come On
When Ignition
Switch Is
Turned On"
Low tire pressure warning lamp stays
on when ignition switch is turned on.Combination meter
BCM connector or circuit
BCMWT-26,
"Inspection 2:
Low Tire
Pressure
Warning
Lamp Stays
On When
Ignition
Switch Is
Turned On"

WT-26
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: August 20072004 QX56
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Inspection 1: Low Tire Pressure Warning Lamp Does Not Come On When Igni-
tion Switch Is Turned On
EES001PV
DIAGNOSTIC PROCEDURE
1. SELF-DIAGNOSTIC RESULT CHECK
1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link con-
nector, then turn the ignition switch ON.
2. Select “START (NISSAN BASED VHCL)”.
3. Select "BCM" on “SELECT SYSTEM” screen.
NOTE:
If the BCM is not indicated, refer to LAN-5, "
CAN COMMUNICATION" .
4. Select "BCM" on "SELECT TEST ITEM" screen, and select "SELF-DIAG RESULTS".
5. Check display contents in self-diagnostic results.
Is "CAN COMM CIRCUIT" displayed in the self-diagnosis display items?
YES >> Malfunction in CAN communication system. Go To LAN-5, "CAN COMMUNICATION" .
NO >> GO TO 2.
2. CHECK COMBINATION METER
Check combination meter operation. Refer to DI-8, "
Combination Meter"
Inspection results OK?
OK >> GO TO 3.
NG >> Replace combination meter. Refer to IP-13, "
Combination Meter" .
3. CHECK LOW TIRE PRESSURE WARNING LAMP
Disconnect BCM harness connector.
Does the low tire pressure warning lamp activate?
YES >> Replace BCM. Refer to BCS-19, "Removal and Installation of BCM" .
NO >> Check combination meter and repair or replace.
Inspection 2: Low Tire Pressure Warning Lamp Stays On When Ignition Switch
Is Turned On
EES0012M
DIAGNOSTIC PROCEDURE
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect BCM harness connectors M18 and M20.
3. Check terminals for damage or loose connections.
Inspection results OK?
OK >> GO TO 2.
NG >> Repair or replace damaged parts.
