6. CHECK ENCODER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH and power window and door lock/unlock switch RH.
3. Check continuity between front power window motor RH connector D104 terminal 3 and power window
and door lock/unlock switch RH connector D105 terminal 12.
OK or NG
OK >> Replace front power window motor RH.
NG >> Repair or replace harness.
Door Switch CheckEIS002V6
1. CHECK FRONT DOOR SWITCH INPUT SIGNAL
With CONSULT-II
Check front door switches (“DOOR SW-DR” and “DOOR SW-AS” ) in “DATA MONITOR” mode with CON-
SULT-II.
Without CONSULT-II
Check voltage between BCM connector and ground.
OK or NG
OK >> Front door switch is OK.
NG >> GO TO 2.3 (G/Y) - 12 (G/Y) : Continuity should exist.
LIIA1268E
Monitor item Condition
DOOR SW-DROPEN : ON
CLOSE : OFF
DOOR SW-ASOPEN : ON
CLOSE : OFF
PIIA2464E
Item ConnectorTerminals (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (-)
Front RH M18 12 (R/L)
GroundOPEN 0
CLOSE Battery voltage
Front LH M19 47 (SB)OPEN 0
CLOSE Battery voltage
LIIA0946E

POWER WINDOW SYSTEM
GW-51
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
2. CHECK FRONT DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front door switch LH or RH and BCM.
3. Check continuity between front door switch connector B8 (LH) or B108 (RH) terminal 2 and BCM connec-
tor M19 terminal 47 (LH) or connector M18 terminal 12 (LH).
4. Check continuity between front door switch connector B8 (LH)
or B108 (RH) terminal 2 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR SWITCH
Check continuity between each front door switch terminal 2 and body ground part of front door switch.
OK or NG
OK >> Replace BCM.
NG >> Replace malfunctioning front door switch.Front LH
2 (SB) - 47 (SB) : Continuity should exist.
Front RH
2 (R/L) - 12 (R/L) : Continuity should exist.
2 (SB or R/L) - Ground : Continuity should not exist.
LIIA0947E
Terminal Door switch Continuity
2Body ground part
of front door
switchPushed No
Released Yes
LIIA0948E

GW-52
POWER WINDOW SYSTEM
Revision: August 20072004 QX56
Front Door Lock Assembly LH (Key Cylinder Switch) CheckEIS002V7
1. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) INPUT SIGNAL
With CONSULT-II

Check front door lock assembly LH (key cylinder switch) (“KEY
CYL LK SW”) in “DATA MONITOR” mode for “POWER DOOR
LOCK SYSTEM” with CONSULT-II. Refer to GW-34, "
DATA
MONITOR" .

Check front door lock assembly LH (key cylinder switch) (“KEY
CYL UN-SW”) in “DATA MONITOR” mode for “POWER DOOR
LOCK SYSTEM” with CONSULT-II. Refer to GW-34, "
DATA
MONITOR" .
Without CONSULT-II
Check voltage between main power window and door lock/unlock switch connector and ground.
OK or NG
OK >> Front door lock assembly LH (key cylinder switch) is OK.
NG >> GO TO 2.
2. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch and front door lock assembly (key cylinder
switch).
3. Check continuity between main power window and door lock/
unlock switch connector D7 terminals 4, 6 and front door lock
assembly LH (key cylinder switch) connector D14 terminals 1, 6.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.“KEY CYL LK-SW” should be “ON” when key inserted
in door key cylinder is turned to lock.
LIIA0047E
“KEY CYL UN-SW” should be “ON” when key inserted
in door key cylinder is turned to unlock.
LIIA0050E
ConnectorTerminals (Wire color)
Key position Voltage (V)
(Approx.)
(+) (–)
D76 (R)
GroundNeutral / Unlock 5
Lock 0
4 (L)Neutral / Lock 5
Unlock 0
LIIA1448E
6 (R) - 6 (R) : Continuity should exist.
4 (L) - 1 (L) : Continuity should exist.
LIIA1571E

POWER WINDOW SYSTEM
GW-53
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
3. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) GROUND
Check continuity between front door lock assembly LH (key cylinder switch) connector D14 terminal 5 and
ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH)
Check continuity between front door lock assembly LH (key cylinder switch) terminals 1, 6 and 5.
OK or NG
OK >> Replace main power window and door lock/unlock
switch.
NG >> Replace front door lock assembly LH (key cylinder
switch). 5 (B) - Ground : Continuity should exist.
LIIA1572E
Terminals Key position Continuity
6
5Neutral / Unlock No
Lock Yes
1Neutral / Lock No
Unlock Yes
LIIA1573E

GW-54
POWER WINDOW SYSTEM
Revision: August 20072004 QX56
Power Window Serial Link Check Front LH and RHEIS002V8
1. CHECK SERIAL LINK OUTPUT SIGNAL
With CONSULT-II
Check door lock and unlock switch (“LOCK SW DR/AS”, “UNLK SW DR/AS”) in DATA MONITOR mode for
“MULTI REMOTE ENT” with CONSULT-II. Refer to GW-34, "
DATA MONITOR" .

When door lock and unlock switch is turned to LOCK

When door lock and unlock switch is turned to UNLOCK
Without CONSULT-II
1. Remove key from ignition switch, and the door of driver side and passenger side is closed.
2. Check the signal between BCM connector and ground with oscilloscope when door lock and unlock
switch (front LH and front RH) is turned “LOCK” or “UNLOCK”.
3. Make sure signals which are shown in the figure below can be
detected during 10 second just after door lock and unlock switch
(front LH and front RH) is turned “LOCK” or “UNLOCK”.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK BCM OUTPUT SIGNAL
Check power window serial link (“POWER WINDOW DOWN”) in “ACTIVE TEST” mode with CONSULT-II.
Refer to GW-34, "
ACTIVE TEST" .
When “ACTIVE TEST” is executed, is the window of driver side and
passenger side lowered?
YES or NO
YES >> Further inspection is necessary. Refer to GW-36, "Tro u-
ble Diagnoses Symptom Chart" .
NO >> Replace BCM.LOCK SW DR/AS : ON
UNLK SW DR/AS : ON
LIIA0172E
ConnectorTerminals (Wire color)
Signal
(+) ( – )
M18 22 (W/V) Ground
LIIA0391E
PIIA2344E
PIIA3080E

POWER WINDOW SYSTEM
GW-55
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
3. CHECK POWER WINDOW SWITCH GROUND
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch and power window and door lock/unlock
switch RH.
3. Check continuity between main power window and door lock/unlock switch connector D8 terminal 17 and
ground.
4. Check continuity between power window and door lock/unlock switch RH connector D105 terminal 11 and
ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.17 (B) - Ground : Continuity should exist.
LIIA0392E
11 (B) - Ground : Continuity should exist.
LIIA1270E

GW-56
POWER WINDOW SYSTEM
Revision: August 20072004 QX56
4. CHECK POWER WINDOW SERIAL LINK CIRCUIT
1. Disconnect BCM.
2. Check continuity between BCM connector M18 terminal 22 and main power window and door lock/unlock
switch connector D7 terminal 14.
3. Check continuity between BCM connector M18 terminal 22 and power window and door lock/unlock
switch RH connector D105 terminal 16.
OK or NG
OK >> Replace main power window and door lock/unlock
switch or power window and door lock/unlock switch
RH.
NG >> Repair or replace harness.
Rear Power Window Control Unit LH or RH Power Supply and Ground Circuit
Check
EIS0038W
1. CHECK POWER WINDOW POWER SUPPLY CIRCUIT
1. Disconnect rear power window control unit LH or RH.
2. Turn ignition switch ON.
3. Check voltage between rear power window control unit LH or RH connector D209 (LH), D309 (RH) termi-
nal 13 and ground.
OK or NG
OK >> GO TO 2
NG >> GO TO 322 (W/V) - 14 (LG/W) : Continuity should exist.
LIIA0394E
22 (W/V) - 16 (LG/W) : Continuity should exist.
LIIA1271E
13 (W/R) - Ground : Battery voltage
LIIA1346E

POWER WINDOW SYSTEM
GW-57
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
2. CHECK POWER WINDOW GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear power window control unit LH or RH connector D209 (LH), D309 (RH) ter-
minal 15 and ground.
OK or NG
OK >> Rear power window control unit LH or RH power supply
and ground circuit is OK. Refer to GW-36, "
Trouble
Diagnoses Symptom Chart" .
NG >> Repair or replace harness.
3. CHECK REAR POWER WINDOW CONTROL UNIT LH OR RH POWER SUPPLY CIRCUIT
1. Disconnect BCM.
2. Check continuity between BCM connector M20 terminal 69 and rear power window control unit LH or RH
connector D209 (LH), D309 (RH) terminal 13.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M20 terminal 69 and ground.
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> Replace BCM.15 (B) - Ground : Continuity should exist.
LIIA2043E
69 (W/R) - 13 (W/R) : Continuity should exist.
LIIA1352E
69 (W/R) - Ground : Battery voltage
WIIA0508E
