2004 INFINITI FX35 bulb

PERSONAL LAMP
LT-151
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
PERSONAL LAMPPFP:26415
Bulb ReplacementAKS007FT
1. Remove personal lamp. Refer to LT- 1 5 1 , "Removal and Installa-
tion" .
2. Remove screw from personal lamp.
3. Insert a screwdriver or similar tool and remove lens.
4. Remove bulb.
5. Install in the reverse order of removal.
Removal and InstallationAKS007FU
REMOVAL
1. Use a clip driver or similar tool to press metal clip, and remove personal lamp.
2. Disconnect personal lamp connector.
INSTALLATION
Install in the reverse order of removal.Personal lamp : 12V - 8W
SKIA5577E
SKIA5578E

LT-152
LUGGAGE ROOM LAMP
Revision: 2004 November 2004 FX35/FX45
LUGGAGE ROOM LAMPPFP:26410
Bulb ReplacementAKS007FV
1. Remove luggage room lamp. Refer to LT- 1 5 2 , "Removal and
Installation" .
2. Remove screw from luggage room lamp.
3. Insert a suitable tool and remove lens.
4. Remove bulb.
5. Install in the reverse order of removal.
Removal and InstallationAKS007FW
REMOVAL
1. Use a clip driver or similar tool to press metal clip, and remove luggage room lamp.
2. Disconnect luggage room lamp connector.
INSTALLATION
Install in the reverse order of removal.Luggage room lamp : 12V - 8W
SKIA6197E
SKIA5579E

IGNITION KEY HOLE ILLUMINATION
LT-153
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
IGNITION KEY HOLE ILLUMINATIONPFP:48476
Bulb Replacement, Removal and InstallationAKS007FR
1. Remove combination meter. Refer to DI-26, "Removal and
Installation" in “DI” section.
2. Remove screw and remove NATS antenna amp.
3. Pull out ring and turn bulb socket to left to release lock.
4. Install in the reverse order of removal.Key cylinder illumination : 12V - 1.4W
SKIA5575E

LT-154
GLOVE BOX LAMP
Revision: 2004 November 2004 FX35/FX45
GLOVE BOX LAMPPFP:68520
Bulb Replacement, Removal and InstallationAKS007FS
1. Remove instrument passenger lower panel. Refer to IP-13, "(J)
Instrument Passenger Lower Panel" in “IP” section.
2. Turn bulb socket left to release lock and remove it.
3. Install in the reverse order of removal.Glove box lamp : 12V - 1.4W
SKIA5576E

ASHTRAY ILLUMINATION
LT-155
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
ASHTRAY ILLUMINATIONPFP:25860
Bulb Replacement and Removal and InstallationAKS007NZ
1. Remove A/T console finisher. Refer to IP-12, "(F) A/T Console Finisher" in “IP” section.
2. Remove instrument ashtray and hazard switch. Refer to IP-17,
"A/T CONSOLE FINISHER" in “IP” section.
3. Use a screwdriver to undo ashtray finisher hooks.
4. Turn bulb socket on circuit board to left to undo lock. Remove
bulb socket.
5. Install in the reverse order of removal.
Ashtray and cigarette
lighter illumination: 12V - 1.4W
PKIA2850E

LT-156
CIGARETTE LIGHTER ILLUMINATION
Revision: 2004 November 2004 FX35/FX45
CIGARETTE LIGHTER ILLUMINATIONPFP:25331
Bulb Replacement and Removal and InstallationAKS007O0
Refer to LT- 1 5 5 , "Bulb Replacement and Removal and Installation" in “ASHTRAY ILLUMINATION”.

INTERIOR ROOM LAMP
LT-181
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
Ignition key Hole illumination Control Does Not OperateAKS007FH
1. CHECK EACH SWITCH
Select “BCM” on CONSULT-II. With “INT LAMP” data monitor to
make sure switches listed in display item list turn ON-OFF linked
with switch operation. Refer to LT- 1 7 5 , "
Display Item List" for
switches and their functions.
OK or NG
OK >> GO TO 2.
NG >> Inspect malfunctioning switch system.
2. ACTIVE TEST
1. Select “BCM” on CONSULT-II. Select “INT LAMP”.
2. Select “IGN ILLUM” active test to make sure lamp operates.
OK or NG
OK >> Replace BCM. Refer to BCS-15, "Removal and Installa-
tion of BCM" .
NG >> GO TO 3.
3. CHECK IGNITION KEY HOLE ILLUMINATION INPUT
1. Turn ignition switch OFF.
2. Check voltage between ignition key hole illumination harness
connector M24 terminal 1 (R/B) and ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 6.
4. CHECK IGNITION KEY HOLE ILLUMINATION BULB
1. Disconnect ignition key hole illumination connector.
2. Check continuity between ignition key hole illumination terminal
1 and 2.
OK or NG
OK >> GO TO 5.
NG >> Replace ignition key hole illumination. Refer to LT- 1 5 3 ,
"Bulb Replacement, Removal and Installation" .
SKIA5930E
Ignition key hole illumination should operate.
SKIA3992E
1 (R/B) – Ground : Battery voltage should exist.
PKIA5260E
1 – 2 : Continuity should exist.
PKIA7894E

INTERIOR ROOM LAMP
LT-183
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
3. CHECK STEP LAMP CIRCUIT
1. Disconnect BCM connector and front door driver side step lamp
connector.
2. Check continuity between BCM harness connector M4 terminal
47 (Y/R) and front door driver side step lamp harness connector
D9 terminal 2 (SB).
OK or NG
OK >> Replace BCM if turn signal lamps does not work after
setting the connector again. Refer to BCS-15, "
Removal
and Installation of BCM" .
NG >> Repair harness or connector.
4. CHECK STEP LAMP CIRCUIT
1. Disconnect BCM connector and step lamp connector.
2. Check continuity between BCM harness connector M4 terminal
41 (R/B) and front door driver side step lamp harness connector
D9 terminal 1 (R).
OK or NG
OK >> Replace BCM if turn signal lamps does not work after
setting the connector again. Refer to BCS-15, "
Removal
and Installation of BCM" .
NG >> Repair harness or connector.
All Interior Room Lamps Do Not OperateAKS007FJ
1. CHECK POWER SUPPLY CIRCUIT
1. All interior room lamps switch are OFF.
2. Turn ignition switch ON.
3. Check voltage between BCM harness connector M4 terminal 41
(R/B) and ground.
OK or NG
OK >> Repair harness or connector. In a case of making a
short circuit, be sure to disconnect battery negative
cable after repairing harness, and then reconnect.
NG >> Replace BCM. Refer to BCS-15, "
Removal and Installa-
tion of BCM" .
Bulb ReplacementAKS007FK
ROOM LAMP
1. Remove room lamp. Refer to LT- 1 8 4 , "Removal and Installation"
.
2. Insert a suitable tool and remove lens.
3. Remove the bulb.
4. Install in the reverse order of removal.47 (Y/R) – 2 (SB) : Continuity should exist.
PKIA5265E
41 (R/B) – 1 (R) : Continuity should exist.
PKIA5266E
41 (R/B) – Ground : Battery voltage should exist.
PKIA5267E
Room lamp :12V - 8W
PKIA2848E
