2004 INFINITI FX35 bulb

LT-124
STEP LAMP
Revision: 2004 November 2004 FX35/FX45
STEP LAMPPFP:26420
Front Door Step LampAKS007DO
BULB REPLACEMENT, REMOVAL AND INSTALLATION
1. Remove door finisher. Refer to EI-35, "Removal and Installation"
in “EI” section.
2. Insert a screwdriver in lens and remove lens.
3. Remove bulb.
4. Install in the reverse order of removal.
Rear Door Step LampAKS007DP
BULB REPLACEMENT, REMOVAL AND INSTALLATION
1. Remove door finisher. Refer to in “EI” section.
2. Insert a screwdriver in lens and remove lens.
3. Remove bulb.
4. Install in the reverse order of removal.Step lamp : 12V - 5W
SKIA5564E
Step lamp : 12V - 5W
SKIA5565E

LT-126
BACK-UP LAMP
Revision: 2004 November 2004 FX35/FX45
Bulb ReplacementAKS007DR
Refer to LT- 1 4 7 , "Bulb Replacement" in “REAR COMBINATION LAMP”.
Removal and InstallationAKS007DS
Refer to LT- 1 4 7 , "Removal and Installation" in “REAR COMBINATION LAMP”.

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-143
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
6. CHECK GROUND
1. Turn ignition switch OFF.
2. Check continuity between front side maker lamp harness con-
nector and ground.
3. Check continuity between clearance lamp harness connector
and ground.
4. Check continuity between license plate lamp harness connector
and ground.
5. Check continuity between rear combination lamp harness con-
nector and ground.
OK or NG
OK >> Check bulb.
NG >> Repair harness or connector.
Terminals
Continuity Front side marker lamp
Ground Connector Terminal (Wire color)
RH E22
2 (B) Yes
LH E42
PKIA5244E
Te r m i n a l s
Continuity Clearance lamp
Ground Connector Terminal (Wire color)
RH E23
3 (B) Yes
LH E43
SKIA5881E
Terminals
Continuity License plate lamp
Ground Connector Terminal (Wire color)
RH D111
2 (B) Yes
LH D110
PKIA5246E
Te r m i n a l s
Continuity Rear combination lamp (Side marker)
Ground Connector Terminal (Wire color)
RH B219
2 (B) Yes
LH B57
PKIA5247E

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-145
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
5. CHECK TURN SIGNAL LAMPS CIRCUIT
1. Disconnect rear combination lamp RH and LH connector.
2. Check continuity between rear combination lamp control unit
harness connector B65 terminal 11 (W) and rear combination
lamp LH harness connector B57 terminal 3 (W).
3. Check continuity between rear combination lamp control unit
harness connector B65 terminal 10 (BR) and rear combination
lamp LH harness connector B57 terminal 4 (BR).
4. Check continuity between rear combination lamp control unit
harness connector B65 terminal 9 (LG) and rear combination lamp RH harness connector B219 terminal 3
(LG).
5. Check continuity between rear combination lamp control unit harness connector B65 terminal 8 (Y) and
rear combination lamp RH harness connector B219 terminal 4 (Y).
OK or NG
OK >> Replace rear combination lamp control unit or rear combination lamp, and then check if turn signal
lamps is illuminated.
NG >> Repair harness or connector.
Parking, License Plate and Tail Lamps Do Not Turn OFF (After Approx. 10 Min-
utes)
AKS007E4
1. CHECK IPDM E/R
1. Turn ignition switch ON. Turn the combination switch (lighting switch) to the OFF position. Turn ignition
switch OFF.
2. Verify that the parking, license plate, and tail lamps turn ON and OFF after approximately 10 minutes.
OK or NG
OK >> Ignition relay malfunction. Refer to PG-19, "Function of Detecting Ignition Relay Malfunction" .
NG >> INSPECTION END
License Plate LampAKS007E5
BULB REPLACEMENT, REMOVAL AND INSTALLATION
1. Remove screws and remove license plate lamp from back door.
2. Disconnect license plate lamp connector.11 (W) – 3 (W) : Continuity should exist.
10 (BR) – 4 (BR) : Continuity should exist.
9 (LG) – 3 (LG) : Continuity should exist.
8 (Y) – 4 (Y) : Continuity should exist.
SKIA5910E
SKIA5567E

LT-146
PARKING, LICENSE PLATE AND TAIL LAMPS
Revision: 2004 November 2004 FX35/FX45
3. Insert a flat head or suitable tool and remove housing.
4. Remove bulb from it's socket.
5. Install in the reverse order of removal.
Front Parking (Clearance) LampAKS007E6
BULB REPLACEMENT
For bulb replacement, refer to LT- 3 5 , "Bulb Replacement" in “HEAD LAMP-XENON TYPE-”.
REMOVAL AND INSTALLATION
For front parking (clearance) lamp removal and installation procedures, refer to LT- 3 6 , "Removal and Installa-
tion" in “HEAD LAMP -XENON TYPE-”.
Tail LampAKS007E7
BULB REPLACEMENT
For bulb replacement, refer to LT- 1 4 7 , "Bulb Replacement" in “REAR COMBINATION LAMP”.
REMOVAL AND INSTALLATION
For tail lamp removal and installation procedures, refer to LT- 1 4 7 , "Removal and Installation" in “REAR COM-
BINATION LAMP”.
Front Side Marker LampAKS007E8
BULB REPLACEMENT
For bulb replacement, refer to LT- 3 5 , "Bulb Replacement" in “HEAD LAMP-XENON TYPE-”.
REMOVAL AND INSTALLATION
For head lamp removal and installation procedures, refer to LT- 3 6 , "Removal and Installation" in “HEAD
LAMP-XENON TYPE-”.
Rear Side Marker LampAKS007E9
BULB REPLACEMENT
For bulb replacement, refer to LT- 1 4 7 , "Bulb Replacement" in “REAR COMBINATION LAMP”.
REMOVAL AND INSTALLATION
For rear side marker lamp removal and installation procedures, refer to LT- 1 4 7 , "Removal and Installation" in
“REAR COMBINATION LAMP”.
Rear Combination Lamp Control UnitAKS007O3
REMOVAL AND INSTALLATION
Refer to LT- 1 0 7 , "Removal and Installation of Rear Combination Lamp Control Unit" in “TURN SIGNAL AND
HAZARD WARNING LAMPS”.License plate lamp : 12V - 5W
SKIA5568E

REAR COMBINATION LAMP
LT-147
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
REAR COMBINATION LAMPPFP:26554
Bulb ReplacementAKS007FP
REAR FENDER SIDE (REAR SIDE MARKER LAMP BULB)
1. Remove rear combination lamp.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb.
BACK DOOR SIDE (BACK-UP LAMP)
1. Remove rear combination lamp.
2. Turn bulb socket counterclockwise and unlock it.
3. Remove bulb.
Removal and InstallationAKS007FQ
REMOVAL
Rear Fender Side
1. Remove bumper side cover A. Refer to EI-18, "Removal and
Installation" in “EI” section.
2. Disconnect rear combination lamp connector.
3. Remove rear combination lamp mounting bolts.
4. Pull rear combination lamp toward side of the vehicle and
remove from the vehicle.
SKIA5569E
SKIA5570E
Stop/tail lamp (rear fender side) : LED (Replace together with rear combination
lamp assembly.)
Rear side marker lamp (rear fender side) : 12V - 3.8W
Back-up lamp (back door side) : 12V - 18W
Rear turn signal lamp (rear fender side) : LED (Replace together with rear combination
lamp assembly.)
SKIA5571E

VANITY MIRROR LAMP
LT-149
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: 2004 November 2004 FX35/FX45
VANITY MIRROR LAMPPFP:96400
Bulb ReplacementAKS007EC
1. Insert a thin screwdriver in the lens end and remove lens.
2. Remove bulb together with substrate.
3. Install in the reverse order of removal.Vanity mirror lamp : 12V - 1.32W
PKIA1137E

LT-150
MAP LAMP
Revision: 2004 November 2004 FX35/FX45
MAP LAMPPFP:26430
Bulb ReplacementAKS007ED
1. Remove lens using clip driver or suitable tool.
2. Remove bulb.
3. Install in the reverse order of removal.
Removal and InstallationAKS007EE
REMOVAL
1. Insert a clip driver or suitable tool back of map lamp and pull
down it to disengage metal clip.
2. Pull down map lamp in direction shown by the arrow in the fig-
ure.
3. Disconnect map lamp connector and remove map lamp.
INSTALLATION
Install in the reverse order of removal.Map lamp : 12V - 8 W
PKIA2846E
PKIA2847E
