CIGARETTE LIGHTER
WW-53
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
Removal and Installation of Cigarette LighterAKS007AB
REMOVAL
1. Remove A/T console finisher. Refer to IP-12, "(F) A/T Console
Finisher" in “IP” section.
2. Remove instrument ashtray and hazard switch. Refer to IP-17,
"A/T CONSOLE FINISHER" in “IP” section.
3. Pull out the cigarette lighter.
4. Use a screwdriver to undo ashtray finisher hooks.
5. Remove screws and remove socket.
INSTALLATION
Install in the reverse order of removal.
SKIA5092E
SKIA5091E
