2004 Hyundai Coupe Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 57
B970C02E-GAT Automatic Operation
HGK020
The FATC (Full Automatic Temperature Control) system automatically controls heating and cool-ing as follows:
1. Push the "AUTO" switch. The indicator light will illuminate confirming that the Face, Floor and/or Bi-Level modes as well as the blowerspeed and, air conditioner will be controlledautomatically. 2. Push the "TEMP" button to set the desired
temperature.The temperature will increase to the maxi-mum 32°C(90°F) by pushing on the button.Each push of the button will cause the tem-perature to increase by 0.5°C(1°F).The temperature will decrease to the mini-mum 17°C(62°F) by pushing on the button.Each push of the button will cause the tem-perature to decrease by 0.5°C(1°F).
G280A01GK
Photo sensor
HGK014
NOTE: Never place anything over the sensor whichis located on the instrument panel to ensurebetter control of the heating and coolingsystem.
NOTE: If the battery has been discharged or discon-nected, the temperature mode will reset tocentigrade degrees.This is a normal condition and you can changethe temperature mode from centigrade tofarenheit as follows;Press the TEMP button down 3 seconds ormore with the button held down. Thedisplay shows that the unit of temperature isadjusted to centigrade or fahrenheit.(°C °F or °F °C)
OUTSIDETEMP

FEATURES OF YOUR HYUNDAI
1- 58 B980B01Y-AAT Fan Speed Control Switch
HGK015
The fan speed can be set to the desired speed by pressing the appropriate fan speed control but-ton. The higher the fan speed is, the more air isdelivered. Pressing the "OFF" button turns offthe fan.
B980A01Y-AAT MANUAL OPERATION The heating and cooling system can be con- trolled manually as well by pushing buttons otherthan the "AUTO" button. In this state, the systemsequentially works according to the order ofbuttons selected.The function of the buttons which are not select-ed will be controlled automatically.Press the "AUTO" button in order to convert toautomatic control of the system.
Pressing the button displays the ambienttemperature on the display.
OUTSIDE
TEMP
B995A01Y-GAT AMBIENT TEMPERATURE SWITCH
HGK009
B670C01GK-AAT Air Intake Control Switch (Without A.Q.S)
HGK008-1
This is used to select fresh outside air or recircu- lation inside air.To change the air intake control mode, (Freshmode, Recirculation mode) push the control but-ton. FRESH MODE ( ) : The indicator light on the button goes on when the air intake control is infresh mode. RECIRCULATION MODE ( ) : The indica- tor light on the button is illuminated when the airintake control is in recirculation mode. With the "Fresh" mode selected, air enters the vehicle from the outside and is heated or cooledaccording to the function selected.

FEATURES OF YOUR HYUNDAI 1- 59
Exhaust gas cutoff mode :
Air enters the vehicle from the outside. But if exhaust gas enters the vehicle from the outside, the exhaust gas cutoff mode ( ) is automa tically converted to the mode, to
prevent exhaust gas from entering the vehicle. NOTE:
o It should be noted that prolonged opera- tion of the heating system in recirculationmode ( ) will give rise to misting ofthe windshield and side windows and theair within the passenger compartment willbecome stale. In addition, prolonged useof the air conditioning with the recircula-
tion mode ( ) selected may result in the air within the passenger compartmentbecoming excessively dry.
o When the ignition switch is turned "ON" the air intake control will change to "Fresh" mode (regardless of the switch position).This is normal operation. The air intakecontrol operates in "AUTO" mode whenturning the ignition to the ON position ifthe "AUTO" mode was used before shut-ting off the engine.
CAUTION:If the windows fog up with the Recirculationor A.Q.S mode selected, set the air intakecontrol to the Fresh air position or A.Q.Scontrol to "OFF".
With the "Recirculation" mode selected, air from within the passenger compartment will be drawnthrough the heating system and heated or cooledaccording to the function selected. NOTE:
o It should be noted that prolonged opera- tion of the heating system in "recircula-tion" mode will give rise to fogging of thewindshield and side windows and the airwithin the passenger compartment willbecome stale. In addition, prolonged useof the air conditioning with the "Recircu-lation" mode selected may result in the airwithin the passenger compartment be-coming excessively dry.
o When the ignition switch is turned "ON" the air intake control will change to " "mode (regardless of switch position). Thisis normal operation. The air intake controloperates in "AUTO" mode when turningthe ignition to the ON position if the"AUTO" mode was used before shuttingoff the engine.
This is used to select fresh outside air or recircu- late inside air automatically.
: OFF
:ON Fresh mode :
Air enters the vehicle from the outside and is heated or cooled according to the function se- lected.
Recirculation mode :
Air from within the passenger compartment will be drawn through the heating system and heated or cooled according to the function selected.
B980C01GK-GAT Air Intake Control Switch (With A.Q.S) (If Installed)
HGK010-1

FEATURES OF YOUR HYUNDAI
1- 60
This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or wind-shield. Four symbols are used to represent Face,Bi-Level, Floor and Floor-Defrost air position.
B980D01Y-AAT Heating and Cooling System OffPress the "OFF" button to stop the operation of the heating and cooling system.
B980E01GK-GAT Air Flow Control
HGK019
HGK021
HGK022
Face-Level
When selecting the "Face" mode, the indicator light will come on, causing air to be dischargedthrough the face level vents.
Bi-Level
When selecting the "Bi-Level" mode, the indica-tor light will come on and the air will be dischargedthrough the face vents and the floor vents. This makes it possible to have cooler air from thedashboard vents and warmer air from the flooroutlets at the same time.
Floor-Level
When selecting the "Floor-Level" mode, the indi-cator light will come on and the air will be dis-charged through the floor vents, windshield de-froster nozzle, side defroster nozzle, side venti-lator.
HGK023
HGK024

FEATURES OF YOUR HYUNDAI 1- 61
B760A01E
The air conditioner filter is located in front of the blower unit behind the glove box.It operates to decrease the amount of pollutantsentering the car. CAUTION:
o Replace the filter every 20,000 km (12,000miles) or once a year.If the car is being driven in severe condi-tions such as dusty, rough roads, morefrequent air conditioner filter inspectionsand changes are required.
o When the air flow rate is decreased, it must be checked at authorized dealer.
Evaporator coreBlower fan
Heater core
B760A04GK-GAT AIR CONDITIONER FILTER (IN FRONT OF BLOWER UNIT) (If Installed)
Outside air
Filter
Inside air
Inside air
Floor-Defrost Level
When selecting the "Floor-Defrost" mode, the indicator light will come on and the air will bedischarged through the windshield defrost nozzle,the floor vents, side defroster nozzle, side venti-lator. B980F01E-GAT Defrost Switch When the "Defrost" button is pressed, the " " mode will be automatically selected and the airwill be discharged through the windshield defrostvents. To assist in defrosting, the air conditioningwill operate if ambient temperature is higher than3.5°C and automatically turns off if the ambienttemperature drops below 3.5°C.
HGK012
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air conditioning sys- tem, keep all windows closed to keep hot airout.
o When moving slowly, as in heavy traffic, shift to a lower gear. This increases engine speed,which in turn increases the speed of the airconditioning compressor.
o On steep grades, turn the air conditioner off to avoid the possibility of the engine over-heating.
o During winter months or in periods when the air conditioner is not used regularly, run theair conditioner once every month for a fewminutes. This will help circulate the lubricantsand keep your system in peak operatingcondition.

FEATURES OF YOUR HYUNDAI
1- 62
Mountains Buildings
Obstructed area Iron bridges
Unobstructed area
FM radio station
SSAR012A
Ionosphere
SSAR011A
AM receptionB750A02A-AAT STEREO SOUND SYSTEM How Car Audio Works
IonosphereFM reception
SSAR010A
AM and FM radio signals are broadcast from transmitter towers located around your city. Theyare intercepted by the radio antenna on your car.This signal is then received by the radio and sentto your car speakers.When a strong radio signal has reached yourvehicle, the precise engineering of your audiosystem ensures the best possible quality repro-duction. However, in some cases the signalcoming to your vehicle may not be strong andclear. This can be due to factors such as thedistance from the radio station, closeness ofother strong radio stations or the presence ofbuildings, bridges or other large obstructions inthe area. AM broadcasts can be received at greater dis-tances than FM broadcasts. This is because AMradio waves are transmitted at low frequencies.These long, low frequency radio waves canfollow the curvature of the earth rather thantravelling straight out into the atmosphere. Inaddition, they curve around obstructions so thatthey can provide better signal coverage.
FM broadcasts are transmitted at high frequen-cies and do not bend to follow the earth's surface.Because of this, FM broadcasts generally beginto fade at short distances from the station. Also,FM signals are easily affected by buildings, moun-tains, or other obstructions. These can result incertain listening conditions which might lead youto believe a problem exists with your radio. Thefollowing conditions are normal and do not indi-cate radio trouble:

FEATURES OF YOUR HYUNDAI 1- 63
SSAR014AB750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equip-ment. This does not mean that something iswrong with the audio equipment. In such a case,use the cellular phone at a place as far aspossible from the audio equipment. CAUTION: When using a communication system such acellular phone or a radio set inside the vehi-cle, a separate external antenna must befitted. When a cellular phone or a radio set isused with an internal antenna alone, it mayinterfere with the vehicle's electrical systemand adversely affect safe operation of thevehicle. WARNING: Don't use a cellular phone when you aredriving. Stop at a safe place to use a cellularphone.SSAR013A
o Station Swapping - As an FM signal weak-ens, another more powerful signal near the same frequency may begin to play. This isbecause your radio is designed to lock ontothe clearest signal. If this occurs, selectanother station with a stronger signal.
o Multi-Path Cancellation - Radio signals being received from several directions can causedistortion or fluttering. This can be caused bya direct and reflected signal from the samestation, or by signals from two stations withclose frequencies. If this occurs, select an-other station until the condition has passed.
o Fading - As your car moves away from the
radio station, the signal will weaken and soundwill begin to fade. When this occurs, wesuggest that you select another stronger sta-tion.
o Flutter/Static - Weak FM signals or large obstructions between the transmitter and yourradio can disturb the signal causing static orfluttering noises to occur. Reducing the treblelevel may lessen this effect until the distur-bance clears.

FEATURES OF YOUR HYUNDAI
1- 64
H240A01O-GAT STEREO RADIO OPERATION (H250) (If Installed)
H250A01GK
1. POWER ON/OFF, VOLUME Control Knob
5. BAND Selector4. TUNE/SEEK Select Button
7. SCAN Button
6. PRESET Buttons
2. BASS/BALANCE Control Knob (BASS/BAL)
3. TREBLE/FADER Control Knob (TREB/FAD)
