DRIVING YOUR HYUNDAI
2- 2 C040A01A-AAT KEY POSITIONS WARNING: The engine should not be turned off or thekey removed from the ignition key cylinderwhile the vehicle is in motion. The steeringwheel is locked by removing the key.
C020A01A-AAT BEFORE STARTING THE ENGINEBefore you start the engine, you should always:
1. Look around the vehicle to be sure there are
no flat tires, puddles of oil, water or other indications of possible trouble.
2. After entering the car, check to be sure the parking brake is engaged.
3. Check that all windows, and lights are clean.
4. Check that the interior and exterior mirrors are clean and in position.
5. Check your seat, seatback and headrest to be sure they are in their proper positions.
6. Close all the doors.
7. Fasten your seat belt and be sure that all other occupants have fastened theirs.
8. Turn off all lights and accessories that are not needed.
9. When you turn the ignition switch to "ON", check that all appropriate warning lights areoperating and that you have sufficient fuel.
10. Check the operation of warning lights and all bulbs when key is in the "ON" position. o To start the engine, insert the ignition key and
turn it to the "START" position. Release it assoon as the engine starts. Do not hold the keyin the "START" position for more than 15seconds.
NOTE:For safety, the engine will not start if the shiftlever is not in "P" or "N" Position (AutomaticTransaxle).
C030A01A-GAT COMBINATION IGNITION SWITCH To Start the Engine
o If your Hyundai is equipped with a manual transaxle, place the shift lever in neutral and depress the clutch pedal fully.
o If your Hyundai has an automatic transaxle, place the shift lever in "P" (park). o "START"The engine is started in this position. It will crankuntil you release the key. NOTE: Do not hold the key in the "START" positionfor more than 15 seconds.
o "ON" When the key is in the "ON" position, the ignition is on and all accessories may be turned on. If theengine is not running, the key should not be leftin the "ON" position. This will discharge thebattery and may also damage the ignition sys-tem.
o "ACC" With the key in the "ACC" position, some electri-cal accessories (radio, etc.) may be operated.
o "LOCK" The key can be removed or inserted in thisposition.To protect against theft, the steering wheel locksby removing the key. NOTE: To unlocking the steering wheel, insert thekey, and then turn the steering wheel and keysimultaneously.
C040A01E
LOCK
ACC
ON
START

DRIVING YOUR HYUNDAI 2- 3
C050A01A-AAT STARTING WARNING: Never run the engine in a closed or poorlyventilated area any longer than is needed tomove your car in or out of the area. Thecarbon monoxide gas emitted is odorlessand can cause serious injury or death.
C050B01A-GAT Normal Conditions:The Starting Procedure:
1. Insert key, and fasten the seat belt.
2. Depress the clutch pedal fully and place the
gearshift lever (manual transaxle) in neutralor the selector lever (automatic transaxle) in"P" (park) position.
3. After turning the ignition key to the "ON" position, make certain all warning lights andgauges are functioning properly before start-ing the engine.
WARNING:Be sure that the clutch is fully depressedwhen starting a manual transaxle vehicle.Otherwise, there is the potential to causedamage to the vehicle or injury to someoneinside or outside the vehicle as a result of theforward or backward movement of the ve-hicle that will occur if the clutch is not de-pressed when the vehicle is started.
4. Turn the ignition key to the "Start" position and release it when the engine starts.
C070C01A-AAT To remove the ignition key
1. Turn the ignition key to the "ACC" position.
2. Simultaneously push and turn the ignition key
counterclockwise from the "ACC" position tothe "LOCK" position.
3. The key can be removed in the "LOCK" position.
C050A01E
LOCK
ON
STARTC070C01E
LOCK ACC
ON
START

DRIVING YOUR HYUNDAI
2- 6 C090B01A-AAT The function of each position is as follows: o P (Park): Use to hold the vehicle in place when parked orwhile starting the engine. Whenever parking thecar, apply the parking brake and shift the selectorlever to the "P" (Park) position. CAUTION: Never place the selector lever in the "P"(Park) position unless the vehicle is fullystopped. Failure to observe this caution willcause severe damage to the transaxle. C090C01A-AAT o R(Reverse): Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector lever to"R" position. C090D02O-AAT o N (Neutral): In the "N" position, the transaxle is in neutral, which means that no gears are engaged. Theengine can be started with the shift lever in "N"position, although this is not recommended ex-cept if the engine stalls while the car is moving.
HGK174
C090A04Y-GAT AUTOMATIC TRANSAXLE The highly efficient Hyundai automatic transaxle has four forward speeds and one reverse speed.The individual speeds are selected automatical-ly, depending on the position of the speed selec-tor lever. The selector lever has 2 gates; the maingate and the manual gate. NOTE: For information on manual gate operation,refer to "Sports Mode". In the main gate, the selector lever has 4 posi- tions, and is equipped with a button to avoidinadvertent wrong selection. NOTE:
Depress the brake pedal and push the button when shifting.Push the button when shifting.The selector lever can be shifted freely.
The first few shifts on a new vehicle, or if the battery has been disconnected, may be some-what abrupt. This is a normal condition, andthe shifting sequence will adjust after shiftsare cycled a few times by the T.C.M (Trans-mission Control Module). CAUTION: Never shift into "R" or "P" position while thevehicle is moving.
The indicator lights in the instrument cluster indicate the selector lever position when theignition is switched "ON". During "D" or sportsmode operation, the gear currently in use dis-plays in the numeral indicator.
C090A02L

DRIVING YOUR HYUNDAI 2- 7
C090F02GK-GAT Sports Mode
HGK175
Whether the vehicle is stationary or in motion, sports mode is selected by pushing the selectorlever from the "D" position into the manual gate.To return to "D" range operation, push the selec-tor lever back into the main gate.In sports mode, moving the selector lever back-wards and forwards can make rapid gearshiftssimple. In contrast to a manual transaxle, thesports mode allows gearshifts with the accelera-tor pedal depressed.UP (+) : Push the lever forward once to shift up
one gear.DOWN (-) : Pull the lever backwards once to shift
down one gear.
C090E01O-AAT
o D(Drive):Use for normal driving. The transaxle will auto- matically shift through a four gear sequence.
CAUTION:
o In sports mode, the driver must execute
shifts in accordance with prevailing roadconditions, taking care to keep the enginespeed below the red zone.
o For engine protection, upward shifts are made automatically when the engine rpmreaches the red zone.
o By rapidly moving the selector lever back- wards (-) twice it is possible to skip onegear by using the sports mode. Sincesudden engine braking and/or rapid ac-celeration can cause a loss of traction,however, downshifts must be made care-fully in accordance with the vehicle'sspeed.
NOTE:
o In sports mode, only the four forward gears can be selected. To reverse or parkthe vehicle, move the selector lever to the"R" or "P" position as required.
o In sports mode, downward shifts are made automatically when the vehicle slowsdown. When the vehicle stops, 1st gear isautomatically selected.
o To maintain the required levels of vehicle performance and safety, the system maynot execute certain gearshifts when theselector lever is operated.
C090H01L-GAT NOTE:
o For smooth and safe operation, depressthe brake pedal when shifting from "Neu- tral" position or "Park" position to a for-ward or reverse gear.
o The ignition key must be in the "ON" position and the brake pedal fully de-pressed in order to move the shift leverfrom the "P" (Park) position to any of theother positions.
o It is always possible to shift from "R", "N", "D" position to "P" position. The vehiclemust be fully stopped to avoid transaxledamage.
o Before driving away from a stop on a
slippery road, push the selector lever for-ward into the +(UP) position. This causesthe transaxle to shift into 2nd gear whichis better for smooth driving away on aslippery road. Push the selector lever tothe -(DOWN) side to shift back to 1st gear.

DRIVING YOUR HYUNDAI
2- 8 C130A01A-AAT GOOD BRAKING PRACTICES WARNING: Nothing should be carried on top of the shelfpanel behind the rear seat. If there were anaccident or a sudden stop, such objects couldmove forward and cause damage to the ve-hicle or injure the occupants.
o After being parked, check to be sure the
parking brake is not engaged and that the parking brake indicator light is out beforedriving away.
o Driving through water may get the brakes wet. They can also get wet when the car iswashed. Wet brakes can be dangerous! Yourcar will not stop as quickly if the brakes arewet. Wet brakes cause the car to pull to one
side. To dry the brakes, apply the brakeslightly until the braking action returns to nor-mal, taking care to keep the car under controlat all times. If the braking action does notreturn to normal, stop as soon as it is safe todo so and call your Hyundai dealer for assis-tance.
o Don't coast down hills with the car out of gear. This is extremely hazardous. Keep the car ingear at all times, use the brakes to slow down,then shift to a lower gear so that enginebraking will help you maintain a safe speed.
o Don't "ride" the brake pedal. Resting your foot on the brake pedal while driving can be dan-gerous because it can result in the brakes
overheating and losing their effectiveness. It
C090I01L-GAT CAUTION:
o Shift into "R" and "P" position only when
the vehicle has completely stopped.
o Do not accelerate the engine in reverse or any of the forward positions with the brakes applied.
o Always apply the footbrake when shifting from "P" or "N", to "R", "D"position.
o Do not use the "P" (Park) position in place of the parking brake. Always set the park-ing brake, shift the transaxle into "P" (Park)position and turn off the ignition whenyou leave the vehicle, even momentarily.Never leave the vehicle unattended whilethe engine is running.
o Check the automatic transaxle fluid level regularly, and add fluid as necessary.
C090N02O-AAT Good Driving Practices
o Never move the gear selector lever from "P" or "N" to any other position with the acceler- ator pedal depressed.
o Never move the gear selector lever into "P" when the vehicle is in motion.
o Be sure the car is completely stopped before you attempt to shift into "R".
o Never take the car out of gear and coast down a hill. This may be extremely hazardous.Always leave the car in gear when moving.
o Do not "ride" the brakes. This can cause them to overheat and malfunction. Instead, whenyou are driving down a long hill, slow down and shift to a lower gear. When you do this,engine braking will help slow the car.
o Slow down before shifting to a lower gear. Otherwise, the lower gear may not be en-gaged.
o Always use the parking brake. Do not depend on placing the transaxle in "P" to keep the carfrom moving.
o Exercise extreme caution when driving on a slippery surface. Be especially careful whenbraking, accelerating or shifting gears. On aslippery surface, an abrupt change in vehiclespeed can cause the drive wheels to losetraction and the vehicle to go out of control.
WARNING:
o Avoid high cornering speeds.
o Do not make quick steering wheel move- ments, such as sharp lane changes orfast, sharp turns.
o Always wear your seat belts. In a collision crash, un unbelted person issignificantly more likely to die than a per-son wearing a seatbelt.
o The risk of rollover is greatly increased if you lose control of your vehicle at high-way speeds.
o Loss of control often occurs if two or more wheels drop off the roadway and the driveroversteers to reenter the roadway.
o In the event your vehicle leaves the road- way, do not steer sharply. Instead, slowdown before pulling back into the travellanes.
o Never exceed posted speed limits.

DRIVING YOUR HYUNDAI
2- 12 C160G01A-GAT To Keep Locks from FreezingTo keep the locks from freezing, squirt an ap- proved de-icer fluid or glycerine into the keyopening. If a lock is covered with ice, squirt it withan approved de-icing fluid to remove the ice. Ifthe lock is frozen internally, you may be able tothaw it out by using a heated key. Handle theheated key with care to avoid injury. NOTE: The proper temperature for using the immo-bilizer key is from -40°C to 80°C. If you heatthe immobilizer key over 80°C to open thefrozen lock, it may cause damage to thetransponder in its head. C160H01A-AAT Use Approved Anti-Freeze in Window Washer System To keep the water in the window washer system from freezing, add an approved anti-freeze solu-tion in accordance with instructions on the con-tainer. Window washer anti-freeze is availablefrom Hyundai dealers and most auto parts out-lets. Do not use engine coolant or other types ofanti-freeze as these may damage the finish.
C160B01A-GAT Snowy or Icy ConditionsTo drive your vehicle in deep snow, it may be necessary to use snow tires or to install tirechains on your tires. If snow tires are needed, itis necessary to select tires equivalent in size andtype to the original equipment tires. Failure to doso may adversely affect the safety and handlingof your car. Speeding, rapid acceleration, sud-den brake applications, and sharp turns arepotentially very hazardous practices. Duringdeceleration, use engine braking to the fullestextent. Sudden brake applications on snowy oricy roads may cause skids to occur. You need tokeep sufficient distance between the vehicle infront and your vehicle. Also, apply the brakegently. It should be noted that installing tire chainson the tire will provide a greater driving force, butwill not prevent side skids. NOTE: Tire chains are not legal in all provinces.Check province laws before fitting tire chains. C160C01A-AAT Use High Quality Ethylene Glycol Coolant Your Hyundai is delivered with high quality ethyl- ene glycol coolant in the cooling system. It is theonly type of coolant that should be used becauseit helps prevent corrosion in the cooling system,lubricates the water pump and prevents freezing.Be sure to replace or replenish your coolant in
C160D01F-AAT Check Battery and Cables Winter puts additional burdens on the battery system. Visually inspect the battery and cablesas described in Section 6 (See page 6-18). Thelevel of charge in your battery can be checkedby your Hyundai dealer or a service station. C160E01A-AAT Change to "Winter Weight" Oil if Necessary In some climates it is recommended that a lower viscosity "winter weight" oil be used during coldweather. See Section 9 for recommendations. Ifyou aren't sure what weight oil you should use,consult your Hyundai dealer. C160F01F-GAT Check Spark Plugs and Ignition Sys- tem Inspect your spark plugs as described in Section 6 (See page 6-8) and replace them if necessary.Also check all ignition wiring and components tobe sure they are not cracked, worn or damagedin any way.
accordance with the maintenance schedule inSection 5. Before winter, have your coolant test-ed to assure that its freezing point is sufficient forthe temperatures anticipated during the winter.

WHAT TO DO IN AN EMERGENCY 3-1
3. WHAT TO DO IN AN
EMERGENCY
D010A01A-AAT IF THE ENGINE WILL NOT START WARNING: If the engine will not start, do not push or pullthe car to start it. This could result in acollision or cause other damage. In addition,push or pull starting may cause the catalyticconverter to be overloaded and create a firehazard. D010B02A-AAT If Engine Doesn't Turn Over or Turns Over Slowly
D010B01GK
1. If your car has an automatic transaxle, be sure the gear selector lever is in "N" or "P" and the emergency brake is set. 2. Check the battery connections to be sure
they are clean and tight.
3. Turn on the interior light. If the light dims or goes out when you operate the starter, thebattery is discharged.
4. Check the starter connections to be sure they are securely tightened.
5. Do not push or pull the vehicle to start it. See instructions for "Jump Starting" on the follow-ing pages.
D010C01A-AAT If Engine Turns Over Normally but Does Not Start
1 Check fuel level.
2 With the key in the off position, Check all connectors at ignition coils and spark plugs.Reconnect any that may be disconnected orloose.
3 Check the fuel line in the engine room.
4 If engine still refuses to start, call a Hyundai dealer or seek other qualified assistance.
D010D01A-AAT If Engine Stalls While Driving
1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Try to start the engine again. If your vehicle will not start, contact a Hyundai dealer or seekother qualified assistance. D020A02A-AAT JUMP STARTING
HGK184
Battery
WARNING: The gas produced by the battery during thejump-start operation is highly explosive. Ifthese instructions are not followed exactly,serious personal injury and damage to thevehicle may occur! If you are not sure how tofollow this procedure, seek qualified assis-
3
HGK184A
DOHC
V6Battery

WHAT TO DO IN AN EMERGENCY
3-8 D080A02A-GAT IF YOUR CAR MUST BE TOWED CAUTION: Your car can be damaged if towed incorrect-ly! If your car has to be towed, it should be done by your Hyundai dealer or a commercial tow truckservice. This will help assure that your car is notdamaged in towing. Also, professionals are gen-erally aware of local laws governing towing. Inany case, rather than risk damage to your car, itis suggested that you show this information to thetow truck operator. Be sure that a safety chainsystem is used and that all local laws are ob-served.
D080B01A-AAT Towing a Car with a Manual Transaxle
o If the car is being towed with the rear wheels
on the ground, be sure the parking brake is released.
o If the car is being towed with the front wheels on the ground, be sure that the transaxle is inneutral. Also, be sure that the ignition key is inthe "ACC" position. This is necessary toprevent damage to the steering lock mecha-nism, which is not designed to hold the frontwheels straight while the car is being towed.
o If any of the loaded wheels or suspension components are damaged, a towing dollymust be used.
o OK FOR AUTOMATIC OR MANUAL
TRANSAXLE EQUIPPED VEHICLE o OK FOR AUTOMATIC OR MANUAL
TRANSAXLE EQUIPPED VEHICLEWITH NO DAMAGE
D080A01GKHGK199
D060J01FC-GAT After Changing Wheels If you have a tire gauge, remove the valve cap and check the air pressure. If the pressure islower than recommended, drive slowly to thenearest service station and inflate to the correctpressure. If it is too high, adjust it until it is correct.Always reinstall the valve cap after checking oradjusting tire pressure. If the cap is not replaced,air may leak from the tire. If you lose a valve cap,buy another and install it as soon as possible.After you have changed wheels, always securethe flat tire in its place in the luggage compart-ment and return the jack and tools to their properstorage locations.
HGK195
