2004 DODGE SPRINTER lock

32 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLETo lock manually:
Move the handle down until it is in the vertical
position.
Automatic locking:
If the left-hand door is closed, it will be automatically
locked as soon as the right-hand door has been closed.
NOTE: If an open tailgate is locked before being
closed, then only the tailgate will be locked.
Please note anti-theft alarm system: The anti-theft
alarm system will be triggered when the doors are
manually unlocked. Cancel alarm by pressing
buttonŒ. The anti-theft alarm system will not be
activated when the doors are manually locked.Opening Angle 270°
To open:
Unhinge the door check strap.
Open the door 270° and press the door stay against the
outer sidewalls. The doors will be kept in this position
by retaining plates.Freightliner-all.book Pag e 32 Monday , December 1, 2003 2:54 PM

34 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLETo Unlock the Door from the Passenger Area
To unlock, turn key to left (1)
To open door (2)
To close door and lock (3)To Unlock the Door from the Cargo Area (Optional)
To unlock, press latch in direction (1)
To open door (2)
To close door and lock (3)Freightliner-all.book Pag e 34 Monday , December 1, 2003 2:54 PM

38 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLESeat Belt Warning Lamp and A irbag MalfunctionWhen the key is in position 2 in the ignition lock, the
warning lamp < lights up for about 6 seconds; this
takes place whether or not the driver’s seat belt is
fastened.
The warning lamp< must go out after about
6seconds.
If the warning lamp< flashes after about 6 seconds,
the malfunction indicator lamp1 is defective.
The fault should be repaired as soon as possible by an
authorized Sprinter Dealer.
NOTE: When the key is turned to position 2 in the
ignition lock, a warning buzzer sounds for about
6 seconds if the driver’s safety belt is not pressed into
the belt buckle. The buzzer stops as soon as the safety
belt is fastened. Press the safety belt into the belt
buckle.
Fastening and RemovingBelt tongue (1)
Belt buckle (2)
Release button (3)
Freightliner-all.book Pag e 38 Monday , December 1, 2003 2:54 PM

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2
Fastening Seat Belts
1. Pull the seat belt over the body. The seat belt must
not be twisted or you could be injured.
2. Press the tongue into the buckle and make sure that
it is heard to engage.
3. The seat belt must be tight across the body. Check
this immediately after fastening the seat belt, and at
regular intervals during the trip.
If necessary, tension the lap belt by pulling the
shoulder strap up in front of the body.Removing Seat Belts
1. Press the release button in the belt buckle.
2. Guide the seat belt back to its rest position.
Seat Belt Warning System
When the key is turned to position 2 in the ignition
lock, a warning buzzer sounds for about 6 seconds if
the driver’s safety belt is not pressed into the belt
buckle. The buzzer stops as soon as the safety belt is
fastened. Press the safety belt into the belt buckle.
WARNING!
A lap belt worn too high can increase the risk of
internal injury in a collision. The belt forces won’t
be at the strong hip and pelvic bones, but across
your abdomen. Always wear the lap part as low as
possible and keep it snug.A twisted belt cannot do it’s job as well. In a
collision it could even cut into you. Be sure the belt
is straight. If you cannot straighten a belt in your
vehicle, take it to your dealer and have it fixed.
WARNING!
A frayed or torn belt could rip apart in a collision
and leave you with no protection. Inspect the belt
system periodically, checking for cuts, frays, or
loose parts. Damaged parts must be replaced im-
mediately. Do not disassemble or modify the sys-
tem. Seat belt assemblies must be replaced after a
collision if they have been damaged (bent retrac-
tor, torn webbing, etc.).
Freightliner-all.book Pag e 39 Monday , December 1, 2003 2:54 PM

40 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLEBelt Height AdjustmentBelt height adjustment button 4
Do not adjust the belt height while the vehicle is
moving.
To lower:
Press the button and move the belt sash guide down.
To raise:
Move the belt sash guide up.
The shoulder strap must pass between the neck and the
shoulder.
A IRBA G A ND BELT TENSIONERSThe vehicle is equipped with an airbag for the driver
and the front seat passenger as well as belt tensioners
for the driver and the front passenger. The system is
known as a Supplemental Restraint System (SRS). It
has been designed to work together with the seat belt
and to supplement.SRS Malfunction Indicator LampWhen the key is in position 2 in the ignition lock, the
malfunction indicator lamp1 will light up in the
instrument cluster for about 4 seconds as a function
check.
WARNING!
Do not put anything on or around the front airbag
covers or attempt to manually open them. You
may damage the airbags and you could be injured
because the airbags are not there to protect you.
These protective covers for the airbag cushions are
designed to open only when the airbags are inflat-
ing.
Freightliner-all.book Pag e 40 Monday , December 1, 2003 2:54 PM

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2
Driver’s A irbagThe driver’s airbag is located within the padded center
of the steering wheel.
WARNING!
If the malfunction indicator lamp1 does not
light up when the key is in position 2 in the igni-
tion lock, if it flickers or lights up while the vehi-
cle is moving, there might be a problem in the
airbag system. There is then a danger that the air-
bag will not deploy in the event of an accident or
will deploy when it should not do so. Have the ve-
hicle inspected and repaired by an authorized
Sprinter Dealer without delay.
Freightliner-all.book Pag e 41 Monday , December 1, 2003 2:54 PM

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2
Belt TensionersThe belt tensioners are located on the three-point seat
belts of the driver’s and front passenger seats.
The belt tensioners will not operate unless the key has
been turned to position 1 or 2 in the ignition lock.
The airbag and / or belt tensioners are designed to only
trigger in certain frontal impacts as not all accidents
call for airbag and / or belt tensioner deployment.
WARNING!
To reduce the risk of injury when the front airbag
inflates, it is very important for the passenger to
always be in a properly seated position and to
wear the seat belt. Since the airbag inflates with
considerable speed and force, a proper seating po-
sition will help to keep you in a safe distance from
the airbag.
Do not place any pieces on the top of the
mounting lid above the airbag. If the airbag is
activated the pieces could be thrown into the
passenger compartment. This could result in
severe personal injuries and death.
Freightliner-all.book Pag e 43 Monday , December 1, 2003 2:54 PM

52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Speed Control (Optional) . . . . . . . . . . . . . . . . . . . . 71

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73Manual Sun Roof (Optional) . . . . . . . . . . . . . . . 74Electric Sun Roof (Optional) . . . . . . . . . . . . . . . . 74Mechanical Sun Roof Operation . . . . . . . . . . . . 75

Ashtray/Cigar Lighter . . . . . . . . . . . . . . . . . . . . . . . 76

Electrical Outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Cup Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Glove Compartment . . . . . . . . . . . . . . . . . . . . . . . . . 79Glove Compartment Lockable (Optional) . . . . 79

Compartments in Front Doors . . . . . . . . . . . . . . . . 79
