72 UNDERSTANDING THE FEATURES OF YOUR VEHICLESetting momentary speed
Briefly push speed control lever up (1) or down (2).
Cancel speed control
Push speed control lever forwards (3) or step on the
brake pedal.
Increase set speed
Push up speed control lever (1) briefly – speed increase
of 0.6 mph (1 km/h) each time.
To increase speed steadily = hold the speed control
lever in the push-up position.Decrease set speed
Push down speed control lever (2) briefly – speed
decrease of 0.6 mph (1 km/h) each time.
To decrease speed steadily, hold the speed control
lever in the push-down position.
Resume set speed (after shutting off)
Push speed control lever back (4).
With the accelerator pedal the set speed can be
increased (for passing).
When the accelerator pedal is released again, the set
speed regulates itself again.
With the key in position 0 or 1 in the ignition lock the
set speed is cancelled.
WARNING!
Leaving the Speed Control on when not in se is
dangerous. You could accidently set the system or
cause it to go faster than you want. You could lose
control and have an accident. Always turn the
system off when you are not using it.
Freightliner-all.book Pag e 72 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73
3
NOTE: On uphill and downhill grades it may not be
possible to maintain speed.
SUNROOF
WARNING!
The speed control does not adapt itself automati-
cally to road conditions; therefore do not use
cruise control on icy roads. There is a risk of skid-
ding and loss of vehicle control. This could cause
an accident resulting in severe personal injuries,
death and property damage.
WARNING!
In an accident, there is a greater risk of being
thrown from a vehicle with an open sun roof. You
could also be seriously injured or killed. Always
fasten your seatbelt properly and make sure all
passengers are properly secured too.
Do not allow small children to operate the electric
sun roof.
Never allow fingers or other body parts, or any
object to project through the sun roof opening.
Injury may result.
Make certain that no one gets caught when the
electric sun roof is closed. The key should be
removed from the ignition lock even if the vehicle
will only be left for a short time to prevent
situations such as children or unauthorized
persons opening and closing the electric sun roof
and becoming caught.
Freightliner-all.book Pag e 73 Monday , December 1, 2003 2:54 PM

74 UNDERSTANDING THE FEATURES OF YOUR VEHICLEManual Sun Roof (Optional)
– To open, turn the handwheel counterclockwise.
Maximum opening = turn until the stop is reached.– To close, turn the handwheel clockwise until the stop
is reached.
Electric Sun Roof (Optional)See Section 4, Understanding Your Instrument Panel,
for switch locations.
Place the key in position 2 in the
ignition lock.
To open the sun roof:
Keep switch pressed upward until
the sun roof has reached the desired
position or the end position.
To close the sun roof:
Keep switch pressed downward until the sun roof has
reached the desired position or is completely closed.
WARNING!
Never allow fingers or other body parts, or any ob-
ject to project through the sun roof opening. Inju-
ry may result.
Freightliner-all.book Pag e 74 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3
Mechanical Sun Roof OperationThe sun roof does not open or close:
Check electrical fuse. Electrical fuses refer to “Electrical
Fuses“.
If the fuse works correctly, the sun roof can also be
closed or opened manually.
Remove cover (1) at the front frame of the sun roof.
Remove tool (2) from the cover (1) and insert.
Open manually:
Press in tool (2) and turn counterclockwise (3).
Close manually:
Press in tool (2) and turn clockwise (4).
Have malfunctions rectified by an authorized Sprinter
Dealer.Freightliner-all.book Pag e 75 Monday , December 1, 2003 2:54 PM

76 UNDERSTANDING THE FEATURES OF YOUR VEHICLEA SHTRA Y/CIGA R LIGHTERAshtray in the driver’s compartment.
Ashtray (1)
Cigar lighter (2)To open the ashtray (1):
Pull the ashtray (1) out until it locks into place.
To close the ashtray (1):
Push the ashtray (1) forward over the working point
until it reaches the stop.
To switch on the cigar lighter (2):
Press in the cigar lighter (2),
it will automatically spring back as soon as the filament
begins to glow.Freightliner-all.book Pag e 76 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79
3
GLOVE COMPARTMENT
Glove Compartment Lockable (Optional)Locked (1)
Unlocked (2)
Open (3)
COM PA RTM ENTS IN FRONT DOORSLocked (1)
Unlocked (2)
