38 THINGS TO KNOW BEFORE STARTING YOUR VEH ICLESeat Belt Warning Lamp and A irbag MalfunctionWhen the key is in position 2 in the ignition lock, the
warning lamp < lights up for about 6 seconds; this
takes place whether or not the driver’s seat belt is
fastened.
The warning lamp< must go out after about
6seconds.
If the warning lamp< flashes after about 6 seconds,
the malfunction indicator lamp1 is defective.
The fault should be repaired as soon as possible by an
authorized Sprinter Dealer.
NOTE: When the key is turned to position 2 in the
ignition lock, a warning buzzer sounds for about
6 seconds if the driver’s safety belt is not pressed into
the belt buckle. The buzzer stops as soon as the safety
belt is fastened. Press the safety belt into the belt
buckle.
Fastening and RemovingBelt tongue (1)
Belt buckle (2)
Release button (3)
Freightliner-all.book Pag e 38 Monday , December 1, 2003 2:54 PM

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2
Driver’s A irbagThe driver’s airbag is located within the padded center
of the steering wheel.
WARNING!
If the malfunction indicator lamp1 does not
light up when the key is in position 2 in the igni-
tion lock, if it flickers or lights up while the vehi-
cle is moving, there might be a problem in the
airbag system. There is then a danger that the air-
bag will not deploy in the event of an accident or
will deploy when it should not do so. Have the ve-
hicle inspected and repaired by an authorized
Sprinter Dealer without delay.
Freightliner-all.book Pag e 41 Monday , December 1, 2003 2:54 PM

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3
Lamp switch (3)
CSide lamps, license plate and instrument
lighting
õLow beam headlamps, high beam
headlamps
ƒMarker lamps, right, combination switch
up (1)
Marker lamps, left, combination switch
down (2)High beam headlamps (lamp switch positionõ) (4)
Headlamp flasher (also when turn signals are on) (5)
NOTE: When the key is in the ignition lock in the 0
position and the driver’s or passenger’s door is open, a
warning buzzer sounds, if the vehicle exterior lighting
(except for the marker lamps) has been switched on.
On vehicles with automatic switching-off of high
beam, with the key in 0 position and the lamp switch
position õ on low and high beam, parking lamps
are automatically switched on. When the driver’s or
passenger’s door is opened, a warning buzzer also
sounds.
For high beam (4) and headlamp flasher (5), the
indicator lamp A in the combination instrument
lights up.Freightliner-all.book Pag e 67 Monday , December 1, 2003 2:54 PM

98 UNDERSTANDING YOUR INSTRUMENT PANELCoolant Level Indicator LampWhen the key is turned to position 2 in the ignition
lock, the coolant level indicator lamp
/ in the
instrument cluster lights up for about 2 seconds. It
must go out when the engine is running.
If the coolant level indicator lamp
/ remains on or lights
up again when the engine is running, the coolant level
is too low.
Do not drive on. Switch the engine off and add coolant.If a large quantity of coolant is being lost, or if smaller
amounts are lost at regular intervals, have the engine
cooling system examined by an authorized Sprinter
Dealer.
CAUTION!
Never run the engine if the coolant level is too
low. This could cause the engine to overheat,
leading in turn to engine damage.
WARNING!
Driving when your engine is badly overheated
can cause some fluids which may have leaked into
the engine compartment to catch fire. You could
be seriously burned. Steam from an overheated
engine can cause serious burns and can occur just
by opening the engine hood. Stay away from the
engine if you see or hear steam coming from it.
Turn off the engine, get out of the vehicle and do
not stand near the vehicle until it cool downs.
Freightliner-all.book Pag e 98 Monday , December 1, 2003 2:54 PM

UNDERSTANDING YOUR INSTRUMENT PANEL 99
4
Engine Control Unit Indicator LampWhen the key is in position 2 in the ignition lock, the
engine control unit indicator lamp± will light up in
the instrument cluster. It must go out when the engine
is running.If the engine control unit indicator lamp
±
remains on
or lights up again while the vehicle is moving, the fuel tank
was run empty or a fault has developed in the engine
control unit. The engine’s power output may be reduced.
Refuel and bleed the fuel system or have the cause
traced and rectified by an authorized Sprinter Dealer.
Indicator Lamp Symbolsv
Acceleration skid control (ASR), or electronic
stability program (ESP),
or slippery surface warning.
1
Airbag malfunction (USA only).
A
High beam on.
#
Battery not being charged.
Water in fuel filter.
2
Brake pads worn.
ù
Engine oil level too low.
/
Coolant level too low.
;
Brake fluid level too low and electronic brake
force distribution (EBV) malfunction (USA only)
.
Freightliner-all.book Pag e 99 Monday , December 1, 2003 2:54 PM

UNDERSTANDING YOUR INSTRUMENT PANEL 105
4
Engine Oil Level – Display in Instrument Cluster
(Vehicles with ASSYST Maintenance Computer only)If the : indicator lamp lights up briefly when the
engine is running, the engine oil level has dropped to
the minimum mark. Check the engine oil level without
delay and add oil to the upper mark on the dipstick. If no engine oil is added and the engine oil level drops
further, a warning buzzer will also sound and
will appear in the multi-function indicator. 2.0 quarts
(about 2.1 liters) of oil must be added.
CAUTION!
If the : indicator lamp lights up, the warning
symbol in the multi-function indicator appears
and the warning buzzer sounds, the operating
safety of the engine is endangered (possibility of
engine damage).
A sudden decrease or absence of oil pressure may
indicate a mechanical failure. Bring the vehicle to
a safe stop, and investigate the cause to prevent
further damage. Do not operate the engine until
the cause has been determined and corrected.
Sy mb
N00.00-2384-00
qt
Freightliner-all.book Pag e 105 Monday, December 1, 2003 2:54 PM

108 UNDERSTANDING YOUR INSTRUMENT PANELENGINE OIL LEVEL INDICATOR IN INSTRUMENT
CLUSTER
(VEHICLES WITHOUT ASSYST MAINTENANCE
COMPUTER)If the : indicator lamp lights up when the engine is
running, the engine oil level has dropped to the
minimum mark. Check the engine oil level without
delay and add engine oil up to the upper mark on the
dipstick.
If there is no engine oil in the oil sump, a warning
buzzer will sound if the key is turned to position 2 in
the ignition lock or if the vehicle is being driven, and
the warning
will appear in the multi-function indicator. About 2
quarts (1.9 liters) of oil must be added.
Check the engine oil level without delay and add
engine oil to the upper mark on the dipstick.
Sy mb
N00.00-2384-00
qt
CAUTION!
If the : indicator lamp lights up, the warning
symbol in the multi-function indicator appears
and the warning buzzer sounds, the operating
safety of the engine is endangered (possibility of
engine damage).
Safely pull off the road and turn off the engine (do
not restart the engine). Determine the cause of the
problem. If there are no obvious signs of leakage,
add engine oil. The engine oil level must be
between the lower and upper marks on the
dipstick. Only add engine oil up to the upper
mark – do not overfill.
If the engine oil level is above maximum, there is
a danger of damage to the engine or catalytic
converter.
Freightliner-all.book Pag e 108 Monday, December 1, 2003 2:54 PM

116 UNDERSTANDING YOUR INSTRUMENT PANELTo switch on:
Press switch (1), the indicator lamp (2) in the switch
lights up.
To switch off:
Press switch (1) again, the indicator lamp (2) goes out.
NOTE: Run the air conditioning at least once a month
for about 10 minutes.
It is possible that the air conditioning will
automatically switch off at outside temperatures below
41 °F (+5 °C). Dehumidification is then also not
possible.
Condensation may emerge from the underside of the
vehicle.
The air conditioner only uses the refrigerant R-134a.
This refrigerant does not damage the earth’s ozone
layer.
Climate Control (on Vehicles with A ir Conditioning)1. Set the airflow control (2) to position 1 to 4.
Position 4 gives maximum cooling.
2. Set the temperature switch (1) as required (The
interior temperature is regulated by the
Tempmatik. If the interior temperature falls below
the preset temperature, warm air is automatically
supplied).
3. Set the air distribution control (3) to h.
4. To switch on air conditioning, press switch (4).
WARNING!
While driving, deactivate the air conditioning
only temporarily to prevent window fogging.
