ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 205
DAEWOO V–121 BL4
7. Lower the vehicle.
8. Connect the transaxle wiring harness and the PNP
switch electrical connector.
9. Refill the transaxle fluid. Refer to ”Transaxle Fluid
Level Checking Procedure” in this section.
10. Connect the negative battery cable.
LEFT TRANSAXLE MOUNTING
BRACKET
Tools Required
DW110–060 Engine Support Fixture
Removal Procedure
1. Remove the battery. Refer to Section 1E, Engine
Electrical.
2. Install the engine support fixture DW110–060.
3. Remove the left transaxle mounting bolts.
4. Remove the left transaxle mount bracket cage bolts
and nut.
5. Remove the transaxle mounting bracket.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 211
DAEWOO V–121 BL4
12. Install the upper transaxle–to–engine bolts.
Tighten
Tighten the upper transaxle–to–engine bolts to 75
NSm (55 lb–ft).
13. Install the clips to the shift control cable and con-
nect the shift cable.
14. Install the park/neutral position switch electrical
connector.
15. Connect the transaxle wiring harness to the trans-
axle.
16. Remove the engine support fixture DW110–060.
17. Install the battery. Refer to Section 1E, Engine
Electrical.
18. Add the transaxle fluid. Refer to ”Transaxle Fluid
Level Checking Procedure” in this section.
19. Connect the negative battery cable.

SECTION : 5A2
AISIN AUTOMATIC TRANSAXLE
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical erminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS5A2–3 . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 5A2–3. . . . . . . . . . . . . . . . . . . .
Transaxle Gear Ratio 5A2–3. . . . . . . . . . . . . . . . . . . . . .
Fluid Capacity 5A2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Line Pressure Specification 5A2–3. . . . . . . . . . . . . . . .
Fastener Tightening Specifications 5A2–4. . . . . . . . . .
SPECIAL TOOLS5A2–5 . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools Table 5A2–5. . . . . . . . . . . . . . . . . . . . . . .
SCHEMATIC DIAGRAMS5A2–8 . . . . . . . . . . . . . . . . . . .
Transmission Control Module (1 of 4) 5A2–8. . . . . . . .
Transmission Control Module (2 of 4) 5A2–9. . . . . . . .
Transmission Control Module (3 of 4) 5A2–10. . . . . . .
Transmission Control Module (4 of 4) 5A2–11. . . . . . .
Shift Mode Diagram 5A2–12. . . . . . . . . . . . . . . . . . . . . .
COMPONENT LOCATOR5A2–17 . . . . . . . . . . . . . . . . . .
Shift Select Control 5A2–17. . . . . . . . . . . . . . . . . . . . . .
Automatic Transaxle Components 5A2–18. . . . . . . . .
Bearing and Races Installation Position
Direction 5A2–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS5A2–25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Connector View 5A2–25. . . . . . . . . . . . . . . . .
Wiring Harness and Connector Inspection 5A2–27. . .
Road Test 5A2–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Function Check 5A2–28. . . . . . . . . . . . . . . . . . . . . . . . . .
Unit Inspection 5A2–30. . . . . . . . . . . . . . . . . . . . . . . . . .
On–Vehicle Repair (Matrix Chart) 5A2–34. . . . . . . . . .
DIAGNOSIS TROUBLE CODE DIAGNOSIS5A2–36 .
Diagnosis Trouble Code Chart 5A2–36. . . . . . . . . . . . .
DTC P0562 System Voltage Low 5A2–37. . . . . . . . . .
DTC P0563 System Voltage High 5A2–40. . . . . . . . . .
DTC P0601 Internal Control Module Memory
Checksum Error 5A2–43. . . . . . . . . . . . . . . . . . . . . . .
DTC P0604 Internal Transmission Control Module
(TCM) Random Access Memory (RAM)
Error 5A2–45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DTC P0705 Transmission Range (TR) Switch
Circuit Malfunction 5A2–47. . . . . . . . . . . . . . . . . . . . .
DTC P0712 Transmission Fluid Temperature
(TFT) Sensor Circuit Low Input 5A2–50. . . . . . . . . .
DTC P0713 Transmission Fluid Temperature
(TFT) Sensor Circuit High Input 5A2–53. . . . . . . . . .
DTC P0717 Input Shaft Speed (ISS) Sensor
Circuit No Signal 5A2–56. . . . . . . . . . . . . . . . . . . . . . .
DTC P0722 Ouput Shaft Speed (OSS) Sensor
Circuit No Signal 5A2–59. . . . . . . . . . . . . . . . . . . . . . .
DTC P0727 Engine Speed Input Circuit No
Signal 5A2–62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC P0741 Torque Converter Clutch (TCC)
Circuit Stuck Off 5A2–65. . . . . . . . . . . . . . . . . . . . . . .
DTC P0742 Torque Converter Clutch (TCC)
Circuit Stuck On 5A2–67. . . . . . . . . . . . . . . . . . . . . . .
DTC P0743 Torque Converter Clutch (TCC)
Electrical 5A2–69. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC P0748 Pressure Control Solenoid (PCS)
Electrical 5A2–72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC P0751 Shift Solenoid 1 (SS1) Stuck Off 5A2–75
DTC P0753 Shift Solenoid 1 (SS1) Electrical 5A2–77
DTC P0756 Shift Solenoid 2 (SS2) Stuck Off 5A2–80
DTC P0758 Shift Solenoid 2 (SS2) Electrical 5A2–82
DTC P0785 Timing Solenoid (ST) Electrical 5A2–85.
DTC P1781 Engine Torque Signal Error 5A2–88. . . . .
DTC P1791 Throttle Position Signal Error 5A2–91. . .
DTC P1792 Engine Coolant Temperature (ECT)
Signal Error 5A2–93. . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC U2105 Can Error 5A2–95. . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR5A2–97 . . . . . . . . . . . . .
ON–VEHICLE SERVICE 5A2–97. . . . . . . . . . . . . . . . . . .
Transaxle Fluid Level Checking Procedure 5A2–97. .
Fluid Drain Procedure 5A2–97. . . . . . . . . . . . . . . . . . . .
Locating Fluid Leaks 5A2–98. . . . . . . . . . . . . . . . . . . . .
Case Porosity Repair 5A2–98. . . . . . . . . . . . . . . . . . . . .
Fluid Cooler Flushing 5A2–99. . . . . . . . . . . . . . . . . . . . .
Control Cable Adjustment 5A2–99. . . . . . . . . . . . . . . . .

AISIN AUTOMATIC TRANSAXLE 5A2 – 27
DAEWOO V–121 BL4
WIRING HARNESS AND
CONNECTOR INSPECTION
1. Reproducing test
Perform symptom simulation test on the basis of
user’s condition. Refer to the below factors.
S Occuring–road condition, speed, accelerate,
reduce speed, straight, curve, air temperature,
weather, etc.
2. Inspect the connection condition of between con-
nectors.
Inspect the failure between connectors by visual
check and contact pressure check.
S Connector disconnected
S Terminals rusted
S Terminals deformation or loose fit
3. Inspect the Continuity of the wiring harness.
Disconnect both ends connector of wiring har-
ness, measure resistance between one connec-
tor terminal and other.
S Normal : 1Ω or less (No open circuit)
S Abnormal :
Ω (Open circuit)
Notice : Measure the resistance while slightly shaking
wire harness vertically and horizontally.
It is rare case wiring harness is broken at the middle of it,
and most cases occur at the connector.
4. Inspect the short circuit of the wiring harness.
Disconnect the connectors of the wiring harness
at both ends, measure resistance between the
applicable terminals of the connector and body
earth.
S Normal : 1M Ω or higher (No short circuit)
S Abnormal : Low resistance (Short circuit)Measure the resistance between one terminal
an another terminal in the same connector.(Ex-
cept between power supply or between earth).
S Normal : 1M Ω or higher (No short circuit)
S Abnormal : Low resistance (Short circuit)
Notice : Measure the wiring harness while slightly shaking
vertically and horzontally.
It is usual case of the short circuit that wiring harness is
crowded body and clamping failure.
5. Temporary connection failure of the connector.
It is thought that temporally the connection fail-
ure of the connector is cause when you can not
decide cause of DTC detection.
Therfore make sure to inspect and clean the
connector and delete the memorized DTC.
ROAD TEST
Road test is to diagnosis failure symptom accurately and
check the failure symptom after procedure.
Confirm whether below condition before road test. Oil tem-
perature is hot condition (50°C (122°F) ~ 80°C (176°F)).
1. D range test
S Check for up–shift, down–shift, kick–down and
lock–up operation at the shift point shown in the
shift schedule.
S Check for engine brake operation.
S Check for Check abnormal shock, noise and
harshness.
2. ”P” range test
Park vehicle on a gradient (more than 5°), shift
into the ”P” range and release parking brake.
Then, check to see no moving vehicle by opera-
tion of parking lock pawl.

5A2 – 28IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
FUNCTION CHECK
Confirm whether below condition before function check.
S Oil temperature is hot condition (50°C (122°F) ~
80°C (176°F)).
S Switch of A/C and light etc are off.
Stall Test
Stall test’ purpose is to inspect overall performance of A/T
and engine by measuring the stall speed in ”D” and ”R”
range.1. Chock 4 Wheels and apply parking brake fully, lock
vehicle perfectly.
2. Fully pressed on foot brake pedal with left foot.
3. Shift into ”D” and ”R” range, fully press on accelera-
tor pedal with right foot.
Quickly read stall speed at this time.
Standards
2390 ± 150 rpm
Notice : Do not continuously run longer than 5 sec be-
cause of extreme increasing oil temp.
Make sure to keep interval for more than 1 min between
stall tests.
Result of Stall Test
Cause of Failure
Lower than standards
both ”D” and ”R”Less engine power
Torque converter one way clutch failure
Higher than standards
only ”D”Lower line pressure
S Pressure control solenoid (PCS) failure
S Primary regulator valve failure
Forward clutch (C1) failure (Slipping)
No.2 One–way clutch (F2) failure
Higher than standards
only ”R”Lower line pressure
S Pressure control solenoid (PCS) failure
S Primary regulator valve failure
Reverse clutch (C3) failure (Slipping)
1st & reverse brake (B3) failure (Slipping)
Higher than standards
both ”D” and ”R”Lower line pressure
S Pressure control solenoid (PCS) failure
S Primary regulator valve failure
Oil pump failure
Oil strainer failure (clogging)
Oil leak for each range circuit
Time Lag Test
Time lag is time till slightly shock can be felt when shift le-
ver is shifted ”N”  ”D” and ”N”  ”R” while engine idling.
Time lag test can inspect hydraulic condition and clutch/
brake condition.
1. Chock 4 Wheels and apply parking brake fully, lock
vehicle perfectly.
2. Measure time lag by using stop watch from moment
when shift lever is shifted in ”N”  ”D” and ”N”
”R” until moment slightly shock can be felt.”N  D”less than 0.7 sec
”N”  ”R”less than 1.2 sec
Notice : Make sure to take 3 measurement and take the
average value.
Make sure to keep interval for more than 1 min between
time lag tests. (That purpose is to remove clutch/brake
pressure was left unfinished.)

AISIN AUTOMATIC TRANSAXLE 5A2 – 29
DAEWOO V–121 BL4
Result of Time Lag TestCause of Failure
Longer than standards ”N”  ”D”Lower line pressure
S Pressure control solenoid (PCS) failure
S Primary regulator valve failure
Forward Clutch (C1) failure (Slipping)
Timing solenoid failure
Oil leak for ”D” range circuit
Longer than standards ”N”  ”R”Lower line pressure
S Pressure control solenoid (PCS) failure
S Primary regulator valve failure
Reverse clutch (C3) failure (slipping)
1st & reverse brake (B3) failure (slipping)
Oil leak for ”R” range circuit
Hydraulic Test
Hydraulic test can inspect working condition inside A/T by
measuring line pressure in ”D” / ”R” range and ”idle” / ”stall”
condition.
1. Chock 4 Wheels and apply parking brake fully, lock
vehicle perfectly.2. Install oil pressure gage adapter DW240–010–02 to
test hole for line pressure.
3. Fully pressed on foot brake pedal with left foot, shift
into ”D” and ”R” range and measure line pressure
”idle” / ”stall” condition.
Line pressure
Mpa (kgf/cm
2)
DR
Engine idle0.37 (3.9)
–0.14 (4.2)0.59 (6.0)
–0.68 (6.9)
Engine stall1.10 (11.3)
–1.23 (12.5)1.58 (16.2)
–1.83 (18.6)
Notice : Do not continuously run longer than 5 sec be-
cause of extreme increasing oil temp.
Make sure to keep interval for more than 1 min between
stall tests.
Make sure to check no oil leak after installing oil pressure
gage adapter.
Result of Hydraulic Test
Cause of Failure
Higher than standards
both ”D and ”R”Pressure control solenoid (PCS) failure
Primary regulator valve failure
Lower than standards
both ”D and ”R”Pressure control solenoid (PCS) failure
Primary regulator valve failure
Oil pump failure
Oil strainer failure (clogging)
Oil leak for each range circuit
Lower than standards
only ”D”D” hydraulic circuit failure
Forward clutch (C1) failure
Lower than standards
only ”R””R” hydraulic circuit failure
Reverse clutch (C3) failure
1st and reverse brake (B3) failure

5A2 – 36IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE DIAGNOSIS
DIAGNOSTIC TROUBLE CODE CHART
DTCDESCRIPTIONTYPEIlluminate
MILBlink
Hold
Lamp
P0562System Voltage LowBYe sNo
P0563System Voltage HighBYe sNo
P0601Internal Control Module Memory Checksum ErrorAYe sNo
P0604Internal Transmission Control Module (TCM) Random Access
Memory (RAM) ErrorBYe sNo
P0705Transmission Range (TR) Switch Circuit MalfunctionBYe sNo
P0712Transmission Fluid Temperature Sensor Circuit Low InputAYe sNo
P0713Transmission Fluid Temperature Sensor Circuit High InputAYe sNo
P0717Input Shaft Speed (ISS) Sensor Circuit No SignalAYe sNo
P0722Output Shaft Speed (OSS) sensor Circuit No SignalAYe sNo
P0727Engine Speed Input Circuit No SignalAYe sNo
P0741Torque Converter Clutch (TCC) Circuit Stuck OffBYe sNo
P0742Torque Converter Clutch (TCC) Circuit Stuck OnBYe sNo
P0743Torque Converter Clutch (TCC) ElectricalBYe sNo
P0748Pressure Control Solenoid (PCS) ElectricalAYe sNo
P0751Shift Solenoid 1 (SS1) Stuck OffBYe sNo
P0753Shift Solenoid 1 (SS1) ElectricalAYe sNo
P0756Shift Solenoid 2 (SS2) Stuck OffBYe sNo
P0758Shift Solenoid 2 (SS2) ElectricalAYe sNo
P0785Timing Solenoid (ST) ElectricalAYe sNo
P1781Engine Torque Signal ErrorAYe sNo
P1791Throttle Position Signal ErrorAYe sNo
P1792Engine Coolant Temperature (ECT) Signal ErrorDNoNo
U2105CAN ErrorAYe sNo
* Description of Type
S Type A : TCM will request the illumination of MIL and store DTC when TCM detects a failure on the first ignition
cycle.
S Type B : TCM will request the illumination of MIL and store DTC when TCM detects failures on two consecutive
ignition cycle.
S Type D : TCM will not request the illumination of MIL or hold lamp, but will store DTC when TCM detects a failure
on the first ignition cycle.

5A2 – 44IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0601 Internal Control Module Memory Checksum Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Inspect Trans-
mission Control
Module (TCM)
wiring harness
and connector
for signs of an
intermittent
condition. Re-
pair as neces-
sary.
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0601 displayed?–Replace the
Transmission
Control Module
(TCM)Inspect Trans-
mission Control
Module (TCM)
wiring harness
and connector
for signs of an
intermittent
condition. Re-
pair as neces-
sary.
