2004 CHEVROLET EPICA Owners Manual

Driver Seat Height Adjuster
Your vehicle may have a manual driver seat height
adjuster.
To adjust the height of
the driver’s seat cushion,
turn the knobs located
on the outboard side of
the seat cushion.
Turn the front knob to adjust the height of the front
portion of the seat cushion. Turn the rear knob to adjust
the height of the rear portion of the seat cushion.
Power Seat
If your vehicle has this feature, the eight–way power
seat controls are located on the outboard side of
the driver’s seat cushion.
This control allows you to move the seat up, down,
forward or rearward. It will also move the front or rear
of the seat cushion up or down, and tilt the seatback
forward or rearward.
To adjust the power seat, do the following:
Move the seat forward
or rearward by pushing
and holding the switch
toward the front or rear
of the vehicle.
1-3

Raise or lower the front
of the seat cushion by
pushing the front part of
the switch up or down.
Raise or lower the rear of the seat cushion by pushing
the rear part of the switch up or down.
Raise or lower the entire seat cushion by pushing the
entire switch up or down.Adjust the angle of the
seatback by pushing the
upper switch forward
or rearward.
When the seat reaches the desired position, release
the switch.
1-4

Manual Lumbar
To adjust the driver’s
front seat lumbar support,
use the lever located
on the outboard side of
the driver’s seatback.
Push the lever down to adjust the support for the lower
part of the seatback.
Pull the lever up to return the support to its original
position.
Heated Seats
Your vehicle may have heated front seats.
The buttons are located
on the center console
above the ashtray.
There is a button for the driver’s seat and a button for
the passenger’s seat. Press the appropriate button
to turn on the heated seat feature. The indicator light
in the button will illuminate while the feature is on.
Press the appropriate button again to turn off the
heated seat feature.
1-5

Reclining Seatbacks
To adjust the seatback,
lift the lever located on
the outboard side of
the seat cushion and
move the seatback
to where you want it.
Release the lever and push rearward on the seatback
to make sure it is locked.
Pull up on the lever without pushing on the seatback
and the seatback will go to an upright position.But do not have a seatback reclined if your vehicle
is moving.
1-6

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts can’t do their job
when you’re reclined like this.
The shoulder belt can’t do its job because it
won’t be against your body. Instead, it will be
in front of you. In a crash you could go into it,
receiving neck or other injuries.
The lap belt can’t do its job either. In a crash
the belt could go up over your abdomen.
The belt forces would be there, not at your
pelvic bones. This could cause serious internal
injuries.
CAUTION: (Continued)
CAUTION: (Continued)
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety
belt properly.
1-7

Head Restraints
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position reduces
the chances of a neck injury in a crash.Pull up the head restraint in order to adjust the position
upward.
Push in the release button on the head restraint in order
to adjust the position downward.
1-8

The front head restraints
also tilt forward.
To tilt the head restraint, first put it in its upright position
by pushing it forward fully and releasing it. Then slowly
move the head restraint forward until it is in the desired
position.
To remove the head restraint, pull the head restraint all
the way up. Then push in the release button and lift
the head restraint from the guide sleeve.
Replace the head restraint and reset it in the original
position before driving.Rear Seats
Rear Seat Operation
Your vehicle has a split folding rear seatback with a
center armrest. You can fold down either side of
the seatback to increase cargo space.
Folding the Seatback
To fold down the seatback, do the following:
1. Make sure that the front seats are not reclined.
If they are, the rear seatbacks will not fold down
all of the way.
2. Press down on the
release button located
on top of the rear
seatback.
1-9

3. Fold the rear seatback forward and down.
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won’t provide the
protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.To return the seatback to the upright position, do the
following:
1. Lift up the seatback and push it to its original
position. Ensure that the safety belts are not twisted
or caught under the seat cushion.
2. Push down firmly on the top of the seatback until it
latches securely in the fully upright position.
Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Don’t let anyone ride where he or she can’t
wear a safety belt properly. If you are in a
crash and you’re not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
CAUTION: (Continued)
1-10
