2003 SUBARU BAJA Owners Manual

xv
–
CONTINUED –
HBF050BB
1 Moonroof (page 2-30)
2 Interior lights (page 6-2)
3 Sun visors (page 6-3) 4
Map light (page 6-3)
5 Inside mirror (page 3-28)

xvi
HBF051BB
1 Cup holder (page 6-7)
2 Center console (page 6-5)
3 Glove box (page 6-5)
4 Cigarette lighter (page 6-9) 5
Ashtray (page 6-12)
6 Rear center console (page 6-6)

xvii
–
CONTINUED –
Cargo bed/spare tire/jack
1 Cargo lamp (page 6-20)
2 Cargo tie-down hooks (page 6-16)
3 Temporary spare tire (page 9-9) 4
Switchback door (page 2-26)
5 Jack/Maintenance tools (page 9-3)
6 Cargo bed extender (page 6-17) HBF052BB
HBF053BB

xviii
Instrument panel
HBF021BB
1 Door locks (page 2-3)
2 Outside mirror (page 3-30)
3 Light control lever (page 3-17)
4 Combination meter (page 3-7)
5 Wiper control lever (page 3-22)
6 Hazard warning flasher switch(page 3-6)
7 Climate control (page 4-1)
8 Gear shift lever (MT) (page 7-11)/Selector lever
(AT) (page 7-14) 9
Audio (page 5-1)
Q Cruise control (page 7-28)
W Horn (page 3-33)
E SRS airbag (page 1-39)
R Tilt steering (page 3-32)
T Fuse box (page 11-49)
Y Hood lock release (page 11-5)
U Power door locking switch(page 2-21)
I Power window (page 2-21)

xix
–
CONTINUED –
Light control and wiper control levers/switches
HBF023CB
1 Parking light switch (page 3-21)
2 Windshield wiper (page 3-22)
3 Mist (page 3-24)
4 Windshield washer (page 3-24)
5 Wiper control lever (page 3-24)
6 Illumination brightness
control (page 3-20) 7
Light control lever (page 3-17)
8 Headlight ON/OFF (page 3-17)
9 Headlight flasher High/Lowbeam change (page 3-17)
Q Turn signal (for lane change)(page 3-19)
W Turn signal (page 3-19)

xx
Combination meter Overview
HBF054BB
1 SRS airbag system warning light (page 3-10)
2 Brake system warning light (page 3-14)
3 Seatbelt warning light (page 3-10)
4 Turn signal indicator light (page3-16)
5 Door ajar warning light (page 3-15)
6 High beam indicator light (page 3-16)
7 CHECK ENGINE warning light/Malfunction indicator lamp (page 3-11)
8 Charge warning light (page 3-12)
9 OIL pressure warning light (page 3-12)
Q AT OIL temperature warning light(page 3-13)
W Front-wheel drive warning light (page 3-15) E
Temperature gauge (page 3-9)
R Clock setting knob (page 3-17)
T Clock (page 3-17)
Y Outside temperature indicator (page 3-8)
U Tachometer (page 3-8)
I Switchback door indicator (page3-15)
O Security system indicator lamp(page 3-16)
P Shift position indicator (page 3-16)
A Cargo lamp indicator (page 3-16)
S Trip meter A/B selection and trip
meter reset knob (page 3-7)
D Trip meter (page 3-7)
F Odometer (page 3-7)
G Speedometer (page 3-7)
H Low fuel warning light (page 3-15)
J Fuel gauge (page 3-9)
K ABS warning light (page 3-13)

xxi
–
CONTINUED –
Warning and indicator light
Mark
NamePage
Seatbelt warning light3-10
AIRBAGSRS airbag system warning light3-10
CHECK ENGINE warning light/ Malfunction indicator lamp3-11
Charge warning light3-12
Oil pressure warning light3-12
AT OIL temperature warning light (if equipped)3-13
orABS warning light3-13
orBrake system warning light3-14
Door ajar warning light3-15
Low fuel warning light3-15
Front-wheel drive warning light (if equipped)3-15
Switchback door indicator3-15
Security system indicator light (if equipped)3-16
Cargo lamp indicator3-16
Turn signal indicator lights3-16
High beam indicator light3-16
