2003 SUBARU BAJA Owners Manual

Maintenance and service11-59
–
CONTINUED –
9. Install the cover by inserting the knobs into the places. Tail light (on the tailgate)
HBB087BAHBB086BA
1. Open the tailgate.
2. Remove the tailgate trim by loosening the installation screws.
3. Remove the tail light cover by loosening the installation screws.
HBB048BAHBB088BA
4. Remove the bulb socket from the tail light by turning it counterclock- wise.
5. Remove the bulb from the socket by pulling it.
6. Install a new bulb into the socket by pushing it.
7. Install the bulb socket into the tail light by turning it clockwise until itstops.
8. Install the tail light cover and the tailgate trim.

11-60
License plate light
HBB095BAHB2054BA
1. Remove the upper cover located above the license plate.
2. Push two release buttons and pull the license plate bracket up until itclicks.
3. Remove the two cover installation screws.
4. Push the license plate bracket back to the original position.
HBB092BA
5. Remove the screw from the side of the cover.
6. Remove the cover.

Maintenance and service11-61
–
CONTINUED –
HBB093BA
7. Remove the bulb socket from the license plate bracket by turning it
counterclockwise.
8. Pull the bulb out of the socket.
9. Install a new bulb in the socket by pushing it.10. Install the bulb socket into the license plate bracket.
11. Install the covers by reversing procedures for removal. Map light, dome light and door step light
HBB068BE

11-62
HSA005BB
HBS037AB
1. Remove the lens by prying the edge of the lens with a regular screw-
driver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the lens.

Maintenance and service11-63
–
CONTINUED –
High mount stop and cargo light assembly
HBB089BA
1. Remove the high mount stop light mounting screws.
HBB090BB
2. Remove the bulb socket from the light assembly by turning it counter- clockwise.

11-64
HBB048BA
3. Remove the bulb from the socket by pulling it.
4. Install a new bulb in the socket by pushing it.
5. Set the socket into the light assembly and turn it clockwise until itclicks.
6. Mount the light assembly with the mounting screws. Sport activity lights (if equipped)
HBB082AAHBB081BA
1. Remove front lamp screw and remove the lens and reflector.
2. Disconnect the two wires from the lamp electrical connector.
3. Squeeze the bulb retainer spring to remove.
4. Replace the bulb, then reset the retainer spring securely.
5. Reconnect the bulb wire to the electrical connector.
6. Install the lens and reflector in the housing and secure with the screw.

Maintenance and service11-65
–
CONTINUED –
NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer
replace these bulbs if necessary.

11-66
