2003 SUBARU BAJA Owners Manual

Climate control4-9
–
CONTINUED –
Bi-level heating
HB5014AA
This setting allows you to direct air of different temperatures from the
instrument panel and foot outlets. The air from the foot outlets is
slightly warmer than from the instrument panel outlets.
1. Set the air inlet selection button to the “OFF” position.
2. Set the air flow control dial to “
”.
3. Set the temperature control dial to the desired temperature level.
4. Set the fan speed control dial to the desired speed.
Setting the temperature control dial fully turned to the red area or blue
area decreases the temperature difference between the air from the
instrument panel outlets and the air from the foot outlets. Ventilation
WARNING
Continued operation in the “ON” position may fog up the win-
dows. Switch to the “OFF” position as soon as the outside dusty
condition clears.

4-10
HB5015AA
To force outside air through the instrument panel outlets:
1. Set the air inlet selection button to the “OFF” position.
2. Set the air flow control dial to “
”.
3. Set the temperature control dial all the way left.
4. Set the fan speed control dial to the desired speed.
When driving on a dusty road, set the air inlet control button to the
“ON” position.
Air conditioner operation Cooling or dehumidifying
HB5016BB
For cooling and dehumidification of the passenger compartment, air
flows through the instrument panel outlets:

Climate control4-11
–
CONTINUED –
1. Set the air inlet selection button to the “OFF” position.
2. Set the air flow control dial to “
”.
3. Set the air conditioner button to the “ON” position.
4. Set the temperature control dial to the blue area.
5. Set the fan speed control dial at the desired speed. Defrosting or defogging
HB5011BB
To direct warm air to the windshield and front door windows:
1. Set the air outlet control dial to “
”.
2. Set the temperature control dial to the red area.
3. Set the fan speed control dial at the highest speed.

4-12
Operating tips for heater and air conditionerCleaning ventilator grille
HBF046BA
Always keep the front ventilator inlet grille free of snow, leaves, or oth-
er obstructions to ensure efficient heating and defrosting. Since the
condenser is located in front of the radiator, this area should be kept
clean because cooling performance is impaired by any accumulation
of insects and leaves on the condenser. Efficient cooling after parking in direct sunlight
After parking in direct sunlight, drive with the windows open for a few
minutes to allow outside air to circulate into the heated interior. This
results in quicker cooling by the air conditioner. Keep the windowsclosed during the operation of the air conditioner for maximum cool-
ing efficiency. Lubrication oil circulation in the refrigerant circuit
Operate the air conditioner compressor at a low engine speed (at idle
or low driving speeds) a few minutes each month during the off-sea-
son to circulate its oil. Checking air conditioning system before summer season
Check the air conditioner unit for refrigerant leaks, hose conditions,
and proper operation each spring. This check is best performed by
your SUBARU dealer.

Climate control4-13
–
CONTINUED –
Cooling and dehumidifying in high humidity and low tempera- ture weather condition
Under certain weather conditions (high relative humidity, low tempera-
tures, etc.) a small amount of water vapor emission from the air outlets
may be noticed. This condition is normal and does not indicate any
problem with the air conditioning system. Air conditioner compressor shut-off when engine is heavily loaded
To improve acceleration and gas mileage, the air conditioner com-
pressor is designed to temporarily shut off during air conditioner op-
eration whenever the accelerator is fully depressed such as duringrapid acceleration or when driving on a steep upgrade. Refrigerant for your climate control system
Your air conditioner uses ozone friendly refrigerant HFC134a. There-
fore, the method of adding, changing or checking the refrigerant is
different from the method for CFC12 (freon). Consult your SUBARU
dealer for service. Repairs needed as a result of using the wrong
refrigerant are not covered under warranty.
Air filtration system (if equipped) If your vehicle ’s air conditioning system is equipped with a optional air
filtration system, replace the filter element according to the replacement
schedule shown below. This schedule should be followed to maintain the
filter’ s dust collection ability. Under extremely dusty conditions, the filter
should be replaced more frequently. Have your filter checked or
replaced by your SUBARU dealer.
Replacement schedule: Every 12 months or 9,300 miles (15,000 km) whichever comes first
NOTE The filter can influence the air conditioning, heating and defroster performance if not properly maintained.

4-14

5
Audio Antenna system5-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 5-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio set 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AM/FM radio with CD player 5-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In-dash 6 CD auto changer (if equipped) 5-13 . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions to observe when handling a compact disc (CD) 5-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-2
Antenna systemPillar mounted antenna
HB5070BA
Pull the antenna out to extend it to its full length. FM reception
Although FM is normally static free, reception can be affected by the
surrounding area, atmospheric conditions, station strength and trans-
mitter distance. Buildings or other obstructions may cause momentary
static, flutter or station interference. If reception continues to be unsat-
isfactory, switch to a stronger station.
Installation of accessories
Always consult your SUBARU dealer before installing a citizen band ra- dio or other transmitting device in your vehicle. Such devices may cause
the electronic control system to malfunction if they are incorrectly
installed or if they are not suited for the vehicle.
