CAN CommunicationBCS000ZQ
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only. For details, refer to LAN-49,
"CAN System Specification Chart" .
Input/Output Signal of TCMBCS000ZR
*1: Spare for vehicle speed sensor·A/T (revolution sensor)
*2: Spare for accelerator pedal position signal
*3: If these input and output signals are different, the TCM triggers the fail-safe function.
*4: Used as a condition for starting self-diagnostics; if self-diagnostics are not started, it is judged that there is some kind of error.
*5: Input by CAN communications.
*6: Output by CAN communications.Control itemLine
pressure
controlVehicle
speed
controlShift
controlLock-up
controlEngine
brake
controlFail-safe
functionSelf-diag-
nostics
function
InputAccelerator pedal position signal
(*5)XXXXX(*3) XX
Vehicle speed sensor A/T
(Revolution sensor)XXXXX(*3) XX
Vehicle speed sensor MTR
(*1)XXXX X
Closed throttle position signal
(*5)(*2) X(*2) XXX(*4) X
Wide open throttle position signal
(*5)(*2) X (*2) X (*4) X
Turbine revolution sensor (Power
train revolution sensor)XX X XX
Engine speed signal X X X X
PNP switch XXXXX(*3) X(*4) X
Stop lamp switch signal
(*5)XX (*4) X
A/T fluid temperature sensors X X X X X X
3rd position switch signal
(*5)XXXX (*4) X
TCM power supply voltage signal X X X X
Out-
putShift solenoid valve A/B X (*3) X X
Line pressure solenoid X (*3) X X
Torque converter clutch solenoid
valveX(*3) XX
Overrun clutch solenoid valve X X (*3) X X
A/T CHECK indicator lamp
(*6)X

A/T CONTROL SYSTEM
AT-29
D
E
F
G
H
I
J
K
L
MA
B
AT

AT LOW FLUID TEMPERATURE

A/T fluid viscosity and frictional characteristics of the clutch facing change with A/T fluid temperature.
Clutch engaging or band-contacting pressure is compensated for, according to A/T fluid temperature, to
stabilize shifting quality.

The line pressure is reduced below 60°C (140°F) to prevent
shifting shock due to low viscosity of A/T fluid when temperature
is low.

Line pressure is increased to a maximum irrespective of the
throttle opening when A/T fluid temperature drops to −10°C
(14°F). This pressure rise is adopted to prevent a delay in clutch
and brake operation due to extreme drop of A/T fluid viscosity at
low temperature.
Shift ControlBCS000ZT
The shift is regulated entirely by electronic control to accommodate vehicle speed and varying engine opera-
tions. This is accomplished by electrical signals transmitted by the revolution sensor and the ECM (accelerator
pedal position sensor). This results in improved acceleration performance and fuel economy.
CONTROL OF SHIFT SOLENOID VALVES A AND B
The TCM activates shift solenoid valves A and B according to sig-
nals from the accelerator pedal position sensor and revolution sen-
sor to select the optimum gear position on the basis of the shift
schedule memorized in the TCM.
The shift solenoid valve performs simple ON-OFF operation. When
set to “ON”, the drain circuit closes and pilot pressure is applied to
the shift valve.
RELATION BETWEEN SHIFT SOLENOID VALVES A AND B AND GEAR POSITIONS
SCIA4829E
SCIA4830E
SAT008J
Gear position 1 2 3 4
Shift solenoid valve A ON (Closed) OFF (Open) OFF (Open) ON (Closed)
Shift solenoid valve B ON (Closed) ON (Closed) OFF (Open) OFF (Open)

AT-30
A/T CONTROL SYSTEM

CONTROL OF SHIFT VALVES A AND B
Pilot pressure generated by the operation of shift solenoid valves A and B is applied to the end face of shift
valves A and B.
The figure above shows the operation of shift valve B. When the shift solenoid valve is “ON”, pilot pressure
applied to the end face of the shift valve overcomes spring force, moving the valve upward.
Lock-up ControlBCS000ZU
The torque converter clutch piston in the torque converter is locked to eliminate torque converter slip to
increase power transmission efficiency. The solenoid valve is controlled by an ON-OFF duty signal sent from
the TCM. The signal is converted to an oil pressure signal which controls the torque converter clutch piston.
CONDITIONS FOR LOCK-UP OPERATION
When vehicle is driven in 3rd and 4th gear position, vehicle speed and throttle opening are detected. If the
detected values fall within the lock-up zone memorized in the TCM, lock-up is performed.
TORQUE CONVERTER CLUTCH SOLENOID VALVE CONTROL
Lock-up Control System Diagram
SAT009J
Selector lever “D” position “3” position
Gear position D
4 , D333
Vehicle speed sensor More than set value
accelerator pedal position sensor Less than set opening
Closed throttle position signal OFF
A/T fluid temperature sensor More than 20°C (68°F)
SCIA5623E

AT-34
TROUBLE DIAGNOSIS

TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartBCS000ZX
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If DTC “CAN COMM CIRCUIT” is displayed with other DTCs, first perform the trouble diagnosis for
“CAN COMMUNICATION LINE”. Refer to AT- 1 3 3
.
Fail-safeBCS000ZY
The TCM has an electronic Fail-safe mode. This allows the vehicle to be driven even if a major electrical input/
output device circuit is damaged.
Under Fail-safe, the vehicle always runs in third gear, even with a shift lever position of “1”, “2”, “3” or “D”. The
customer may complain of sluggish or poor acceleration.
Always follow the AT- 3 7 , "
WORK FLOW" .
The SELF-DIAGNOSIS results will be as follows:

The first SELF-DIAGNOSIS will indicate damage to the vehicle speed sensor or the revolution sensor.

During the next SELF-DIAGNOSIS, performed after checking the sensor, no damages will be indicated.
FAIL-SAFE FUNCTION
The following fail-safe functions allow vehicles to be driven even when sensor, switch or solenoid malfunction
occurs.
Vehicle Speed Sensor 1 (Revolution Sensor)
Vehicle speed sensor 2 signal is input from combination meter.
Accelerator Pedal Position Sensor Signal
TCM controls the throttle opening angle to a predetermined fixed position to enable driving if a malfunctioning
signal is input to TCM.
Park/Neutral Position (PNP) Switch
When the multiple PNP switch signals are input to TCM, the priority of selector lever position becomes “D”·“3”,
“N”, “R”, “2” and “1” in order by internal TCM determination.
The use of 4th gear is inhibited until normal operation resumes. Because the hydraulic circuit of the control
valve is switched by manual valve according to the selector lever position, however, actual operating condition
of vehicle becomes as follows.
Priority Detected items
1 CAN communication line
2 Except above
Actual lever position PNP switch input signal Running status
“P” “P” position and other position signals P
“R” “R” position and other position signals R
“N” “N” position and other position signals N
“D”·“3” “D” position and other position signals D
1 ⇔D2 ⇔D3
“2”“2” position and other position signals (Except “1” position) 21 ⇔22 ⇔23
“2” position and “1” position signals 21 ⇔22
“1”“1” position and other position signals (Except “2” position) 11 ⇔12 ⇔13
“1” position and “2” position signals 11 ⇔12

AT-36
TROUBLE DIAGNOSIS

How to Perform Trouble Diagnoses for Quick and Accurate RepairBCS000ZZ
INTRODUCTION
The TCM receives a signal from the vehicle speed sensor, accelera-
tor pedal position sensor or PNP switch and provides shift control or
lock-up control via A/T solenoid valves.
Input and output signals must always be correct and stable in the
operation of the A/T system. The A/T system must be in good oper-
ating condition and be free of valve seizure, solenoid valve malfunc-
tion, etc.
It is much more difficult to diagnose a malfunction that occurs inter-
mittently rather than continuously. Most intermittent malfunctions are
caused by poor electric connections or improper wiring. In this case,
careful checking of suspected circuits may help prevent the replace-
ment of good parts.
A visual check only, may not find the cause of the malfunctions. A
road test with CONSULT-II or a circuit tester connected should be
performed. Follow the AT- 3 7 , "
WORK FLOW" .
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a drivability complaint. The customer
can supply good information about such malfunctions, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A “DIAGNOSTIC WORKSHEET” like the
example (AT- 3 8 , "
DIAGNOSTIC WORKSHEET" ) should be used.
Start your diagnosis by looking for “conventional” malfunctions first.
This will help troubleshoot drivability malfunctions on an electroni-
cally controlled engine vehicle.
Also check related Service bulletins for information.
SAT631IA
SAT632I
SEF234G

TROUBLE DIAGNOSIS
AT-39
D
E
F
G
H
I
J
K
L
MA
B
AT

Diagnostic Worksheet
1.❏ Read the Fail-safe and listen to customer complaints.AT- 3 4, AT- 3 8
2.❏ Check A/T fluidAT- 1 4❏ Leakage (Follow specified procedure)
❏ Fluid condition
❏ Fluid level
3.❏ Perform “STALL TEST” and “LINE PRESSURE TEST”.AT- 4 3
,
AT- 4 6
❏ “STALL TEST” — Mark possible damaged components/others.
❏ Torque converter one-way clutch
❏ Reverse clutch
❏ Forward clutch
❏ Overrun clutch
❏ Forward one-way clutch❏ Low & reverse brake
❏ Low one-way clutch
❏ Engine
❏ Line pressure is low
❏ Clutches and brakes except high clutch and
brake band are OK
❏ “LINE PRESSURE TEST” — Suspected parts:
4.❏ Perform “Road Test”.AT- 4 8
4-1.“Check Before Engine is Started”AT- 4 8
❏ AT-173, "A/T CHECK Indicator Lamp Does Not Come On" .
❏ Perform self-diagnostics. Enter checks for detected items. AT- 6 9
, AT- 7 6 .
❏ AT-133, "
CAN COMMUNICATION LINE" .
❏ AT-80, "
VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)" .
❏ AT-86, "
VEHICLE SPEED SENSOR MTR" .
❏ AT-120, "
TURBINE REVOLUTION SENSOR" .
❏ AT-90, "
SHIFT SOLENOID VALVE A" .
❏ AT-95, "
SHIFT SOLENOID VALVE B" .
❏ AT-100, "
OVERRUN CLUTCH SOLENOID VALVE" .
❏ AT-105, "
TORQUE CONVERTER CLUTCH SOLENOID VALVE" .
❏ AT-110, "
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POWER
SOURCE)" .
❏ AT-116, "
ENGINE SPEED SIGNAL" .
❏ AT-136, "
A/T 1ST GEAR FUNCTION" .
❏ AT-140, "
A/T 2ND GEAR FUNCTION" .
❏ AT-143, "
A/T 3RD GEAR FUNCTION" .
❏ AT-146, "
A/T 4TH GEAR FUNCTION" .
❏ AT-151, "
A/T TCC S/V FUNCTION (LOCK-UP)" .
❏ AT-126, "
LINE PRESSURE SOLENOID VALVE" .
❏ AT-156, "
CONTROL UNIT (RAM)" .
❏ AT-157, "
CONTROL UNIT (ROM)" .
4-2.“Check at Idle”AT- 4 8
❏ AT-175, "Engine Cannot Be Started in “P” and “N” Position" .
❏ AT-176, "
In “P” Position, Vehicle Moves Forward or Backward When Pushed" .
❏ AT-176, "
In “N” Position, Vehicle Moves" .
❏ AT-177, "
Large Shock. “N” → “R” Position" .
❏ AT-179, "
Vehicle Does Not Creep Backward in “R” Position" .
❏ AT-181, "
Vehicle Does Not Creep Forward in “D”, “3”, “2” or “1” Position" .

AT-40
TROUBLE DIAGNOSIS

4. 4-3.“Cruise Test”AT- 5 0
Part 1
❏ AT-182, "
Vehicle Cannot Be Started From D1" .
❏ AT-184, "
A/T Does Not Shift: D1 → D2 or Does Not Kickdown: D4 → D2" .
❏ AT-186, "
A/T Does Not Shift: D2 → D3" .
❏ AT-188, "
A/T Does Not Shift: D3 → D4" .
❏ AT-191, "
A/T Does Not Perform Lock-up" .
❏ AT-193, "
A/T Does Not Hold Lock-up Condition" .
❏ AT-195, "
Lock-up Is Not Released" .
❏ AT-195, "
Engine Speed Does Not Return To Idle (Light Braking D4 → D3 )" .
Part 2AT- 5 1
❏ AT-182, "Vehicle Cannot Be Started From D1" .
❏ AT- 1 8 4 , "
A/T Does Not Shift: D1 → D2 or Does Not Kickdown: D4 → D2" .
❏ AT-186, "
A/T Does Not Shift: D2 → D3" .
❏ AT-188, "
A/T Does Not Shift: D3 → D4" .
Part 3AT- 5 2
❏ AT-197, "A/T Does Not Shift: D4 → 33 , When A/T Selector Lever “D” → “3”" .
❏ AT-203, "
Vehicle Does Not Decelerate By Engine Brake (D4 → 33 )" .
❏ AT-198, "
A/T Does Not Shift: 33 → 22 , When Selector Lever “3” → “2” Position" .
❏ AT-205, "
Vehicle Does Not Decelerate By Engine Brake (33 → 22 )" .
❏ AT-200, "
A/T Does Not Shift: 22 → 11 , When Selector Lever “2” → “1” Position" .
❏ AT-208, "
Vehicle Does Not Decelerate By Engine Brake (22 → 11 )" .
❏ Perform self-diagnostics. Enter checks for detected items. AT- 6 9
, AT- 7 6 .
❏ AT-133, "
CAN COMMUNICATION LINE" .
❏ AT-80, "
VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)" .
❏ AT-86, "
VEHICLE SPEED SENSOR MTR" .
❏ AT-120, "
TURBINE REVOLUTION SENSOR" .
❏ AT-90, "
SHIFT SOLENOID VALVE A" .
❏ AT-95, "
SHIFT SOLENOID VALVE B" .
❏ AT-100, "
OVERRUN CLUTCH SOLENOID VALVE" .
❏ AT-105, "
TORQUE CONVERTER CLUTCH SOLENOID VALVE" .
❏ AT-110, "
BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POWER
SOURCE)" .
❏ AT-116, "
ENGINE SPEED SIGNAL" .
❏ AT-136, "
A/T 1ST GEAR FUNCTION" .
❏ AT-140, "
A/T 2ND GEAR FUNCTION" .
❏ AT-143, "
A/T 3RD GEAR FUNCTION" .
❏ AT-146, "
A/T 4TH GEAR FUNCTION" .
❏ AT-151, "
A/T TCC S/V FUNCTION (LOCK-UP)" .
❏ AT-126, "
LINE PRESSURE SOLENOID VALVE" .
❏ AT-156, "
CONTROL UNIT (RAM)" .
❏ AT-157, "
CONTROL UNIT (ROM)" .
5.❏ For self-diagnosis NG items, inspect each component. Repair or replace the damaged parts.
6.❏ Perform “Road Test”.AT- 4 8
7.❏ Perform the Diagnostic Procedures for all remaining items marked NG. Repair or replace the damaged parts.
Refer to the Symptom Chart when you perform the procedures. (The chart also shows some other possible
symptoms and the component inspection orders.)AT- 5 5
8.❏ Erase DTC from TCM and ECM memories.AT- 6 9AT- 7 9

TROUBLE DIAGNOSIS
AT-47
D
E
F
G
H
I
J
K
L
MA
B
AT

5. Start engine and measure line pressure at idle and stall speed.
CAUTION:

Keep the brake pedal pressed all the way down during
measurement.

When measuring line pressure at stall speed, refer to AT-
43, "STALL TEST" .
Line Pressure
Judgement of Line Pressure Test
SAT493G
Engine speed rpmLine pressure kPa (bar, kg/cm2 , psi)
“D”, “3”, “2” and “1” positions “R” position
Idle 500 (5.00, 5.1, 73) 778 (7.78, 7.9, 113)
Stall 1,233 (12.33, 12.6, 179) 1,918 (19.18, 19.6, 278)
Judgement Suspected parts
At idleLine pressure is low in all positions.

Oil pump wear

Control piston damage

Pressure regulator valve or plug sticking

Spring for pressure regulator valve damaged

Fluid pressure leakage between oil strainer and pressure regulator valve

Clogged strainer
Line pressure is low in particular posi-
tion.

Fluid pressure leakage between manual valve and particular clutch

For example, line pressure is:
− Low in “R” and “1” positions, but
− Normal in “D”, “3” and “2” positions.
Therefore, fluid leakage exists at or around low and reverse brake circuit.
Refer to AT-18, "
CLUTCH AND BAND CHART" .
Line pressure is high.

Accelerator pedal position signal malfunction

A/T fluid temperature sensor damaged

Line pressure solenoid valve sticking

Short circuit of line pressure solenoid valve circuit

Pressure modifier valve sticking

Pressure regulator valve or plug sticking

Open in dropping resistor circuit
At stall
speedLine pressure is low.

Accelerator pedal position signal malfunction

Line pressure solenoid valve sticking

Short circuit of line pressure solenoid valve circuit

Pressure regulator valve or plug sticking

Pressure modifier valve sticking

Pilot valve sticking
