PARKING, LICENSE PLATE AND TAIL LAMPS
LT-197
C
D
E
F
G
H
I
J
L
MA
B
LT


to unified meter and A/C amp. terminal 21.
With the ignition switch in the ON or START position, power is supplied

to ignition relay (located in IPDM E/R),

through 10A fuse [No. 1, located in fuse block (J/B)]

to BCM terminal 38,

through 10A fuse [No. 14, located in fuse block (J/B)]

to combination meter terminal 8,

through 10A fuse [No. 12, located in fuse block (J/B)]

to unified meter and A/C amp. terminal 22.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 6, located in fuse block (J/B)]

to BCM terminal 11.
Ground is supplied

to BCM terminal 52

to combination meter terminals 10, 11 and 12, and

to unified meter and A/C amp. terminals 29 and 30

through grounds M71 and M72,

to IPDM E/R terminals 38 and 60

through grounds E1 and E31.
PARKING, LICENCE PLATE AND TAIL LAMPS OPERATION
When the lighting switch is in 1ST position, BCM detects the LIGHTING SWITCH 1ST POSITION (ON) by
BCM combination switch reading function. And then, BCM sends position light request signal (ON) through
CAN communication.
When receiving position light request signal (ON), IPDM E/R turns ON tail lamp relay in IPDM E/R. And then,
parking, license plate and tail lamps go ON. IPDM E/R supplies power

through IPDM E/R terminal 22

to front combination lamp RH and LH terminals 7

to license plate lamp RH and LH terminals 1 and

to rear combination lamp RH and LH terminals 3.
Ground is supplied at all times

to front combination lamp RH and LH terminals 4

through grounds E1 and E31,

to license plate lamp RH and LH terminals 2

through grounds B214 and B217,

to rear combination lamp RH and LH terminals 2

through grounds M71 and M72 (with rear view camera)

through grounds B16 and B17 (without rear view camera).
With power and ground supplied, the parking, license plate and tail lamps illuminate.
Unified meter and A/C amp. receives position light request signal (ON) through CAN communication, make tail
lamp indicator go ON in combination meter.
COMBINATION SWITCH READING FUNCTION
Refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
EXTERIOR LAMP BATTERY SAVER CONTROL
When any of the 1ST/2ND position with exterior lamp ON, the ignition switch is turned to OFF. The driver's
door is opened to get out of the car and then closed, BCM turns OFF exterior lamp with door lock operation of
the remote keyless entry system or Intelligent Key system in order to prevent battery from running by forget-
ting about turning OFF the exterior lamp.
This setting can be changed by CONSULT-II. Refer to LT- 1 9 , "
WORK SUPPORT" .

LT-206
PARKING, LICENSE PLATE AND TAIL LAMPS

Terminals and Reference Values for IPDM E/RBKS001QQ
How to Perform Trouble DiagnosesBKS001QR
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to LT- 1 9 6 , "
System Description" .
3. Perform the Preliminary Check. Refer to LT- 2 0 6 , "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Do the parking, license and tail lamps operate normally? If YES, GO TO 6. If NO, GO TO 4.
6. INSPECTION END
Preliminary CheckBKS001QS
CHECK POWER SUPPLY AND GROUND CIRCUIT
1. CHECK FUSES AND FUSIBLE LINK
Check for blown fuses and fusible link.
Refer to LT-200, "Wiring Diagram — TAIL/L —" .
OK or NG
OK >> GO TO 2.
NG >> If fuse or fusible link is blown, be sure to eliminate cause of malfunction before installing new fuse
or fusible link. Refer to PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
Terminal
No.Wire
colorSignal nameMeasuring condition
Reference value
Ignition
switchOperation or condition
22 R/LParking, license
plate and tail lampsON Lighting switchOFF Approx. 0 V
1ST, 2ND or AUTO (When
headlamp is turned ON)Battery voltage
38 B Ground ON — Approx. 0 V
48 L CAN− H— — —
49 P CAN− L— — —
60 B Ground ON — Approx. 0 V
Unit Power source Fuse and fusible link No.
BCMBatteryM
17
Ignition switch ACC or ON position 6
Ignition switch ON or START position 1
IPDM E/R Battery 71

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-207
C
D
E
F
G
H
I
J
L
MA
B
LT

2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
CONSULT-II Functions (BCM)BKS001QT
Refer to LT- 1 8 , "CONSULT-II Functions (BCM)" .
CONSULT-II Functions (IPDM E/R)BKS001QU
Refer to LT- 2 0 , "CONSULT-II Functions (IPDM E/R)" .
Terminals Ignition switch position
(+)
(−)OFFACCON
BCM
connectorTerminal
M311
GroundApprox. 0 VBattery
voltageBattery
voltage
38 Approx. 0 V Approx. 0 VBattery
voltage
M442Battery
voltageBattery
voltageBattery
voltage
55 Battery
voltageBattery
voltageBattery
voltage
PKIA5204E
BCM connector Terminal
GroundContinuity
M4 52 Yes
PKIA6256E

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-209
C
D
E
F
G
H
I
J
L
MA
B
LT

4. CHECK CIRCUIT BETWEEN IPDM E/R AND PARKING, LICENSE PLATE, TAIL LAMPS
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector, front combination lamp RH and LH connectors, rear combination lamp
RH and LH connectors and licence plate lamp RH and LH connectors.
3. Check continuity between IPDM E/R harness connector and
front combination lamp harness connector.
4. Check continuity between IPDM E/R harness connector (A) and
rear combination lamp harness connector (B).
5. Check continuity between IPDM E/R harness connector (A) and
license plate lamp harness connector (B).
6. Check continuity between IPDM E/R harness connector (A) and
ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
IPDM E/R
connectorTerminalHeadlamp
typeFront combination
lamp connectorTerminal Continuity
E7 22XenonRH E15
7 Yes LH E29
HalogenRH E47
LH E46
PKIA6295E
AB
Continuity
Connector Terminal Connector Terminal
E7 22RH B24
3Yes
LH B33
PKID0284E
AB
Continuity
Connector Terminal Connector Terminal
E7 22RH T3
1Yes
LH T4
A
GroundContinuity
Connector Terminal
E7 22 No
PKID0108E

LT-210
PARKING, LICENSE PLATE AND TAIL LAMPS

5. CHECK IPDM E/R OUTPUT VOLTAGE
With CONSULT-II
1. Connect IPDM E/R connector.
2. Select “IPDM E/R” on CONSULT-II and select “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Select “TAIL LAMP” on “SELECT TEST ITEM” screen.
4. Touch “ON” screen.
5. When parking, license plate and tail lamps is operating, check
voltage between IPDM E/R harness connector and ground.
Without CONSULT-II
1. Connect IPDM E/R connector.
2. Start auto active test. Refer to PG-21, "
Auto Active Test" .
3. When parking, license plate and tail lamps is operating, check voltage between IPDM E/R harness con-
nector and ground.
OK or NG
OK >> GO TO 6.
NG >> Replace IPDM E/R. Refer to PG-28, "
Removal and Installation of IPDM E/R" .
Terminal
Voltage
(Approx.) (+)
(-)
IPDM E/R connector Terminal
E7 22 Ground Battery voltage
PKIA6294E
Terminal
Voltage
(Approx.) (+)
(-)
IPDM E/R connector Terminal
E7 22 Ground Battery voltage

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-213
C
D
E
F
G
H
I
J
L
MA
B
LT

Parking, License Plate and Tail Lamps Do Not Go OFFBKS002FT
1. CHECK IPDM E/R FUNCTION
Make sure that lighting switch is OFF. And then check if ignition switch is ON or OFF when parking, license
plate, and tail lamps go OFF.
Check results
Lamps go OFF when ignition switch is ON>>Replace IPDM E/R. Refer to PG-28, "Removal and Installation
of IPDM E/R" .
Lamps go OFF when ignition switch is OFF>>GO TO 2.
Lamps do not go OFF when ignition switch is ON and OFF.>>GO TO 4.
2. CHECK BCM INPUT SIGNAL
1. Select “BCM” on CONSULT-II, and select “HEAD LAMP” on “SELECT TEST ITEM” screen.
2. Select “DATA MONITOR” on “SELECT DIAG MODE” screen.
Make sure that “IGN ON SW” turns ON-OFF according to igni-
tion switch operation.
OK or NG
OK >> Replace BCM, refer to BCS-16, "Removal and Installa-
tion of BCM" or IPDM E/R, refer to PG-28, "Removal
and Installation of IPDM E/R" .
NG >> GO TO 3.
3. CHECK BCM POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
OK or NG
OK >> Replace BCM. Refer to BCS-16, "Removal and Installation of BCM" .
NG >> Repair harness or connector.When ignition switch is in
the ON position: IGN ON SW ON
When ignition switch is in
the OFF or ACC position: IGN ON SW OFF
PKID0285E
Terminal Ignition switch position
(+)
(−)OFFACCON
BCM
connectorTerminal
M3 38 Ground Approx. 0 V Approx. 0 VBattery
voltage
PKID0110E

LT-244
ILLUMINATION

ILLUMINATIONPFP:27545
System DescriptionBKS001RI

BCM (Body Control Module) controls illumination lamp operation.

IPDM E/R (Intelligent Power Distribution Module Engine Room) operates illumination lamps according to
CAN communication signals from BCM.
OUTLINE
Power is supplied at all times

to ignition relay (located in IPDM E/R), from battery direct,

through 50A fusible link (letter M, located in fuse and fusible link box)

to BCM terminal 55,

through 15A fuse [No. 17, located in fuse block (J/B)]

to BCM terminal 42 and

to combination meter terminal 7,

through 15A fuse (No. 71, located in IPDM E/R)

to tail lamp relay (located in IPDM E/R) and

to CPU (central processing unit) in IPDM E/R

through 15A fuse (No. 78, located in IPDM E/R)

to CPU in IPDM E/R,

through 10A fuse [No. 19, located in fuse block (J/B)]

to unified meter and A/C amp. terminal 21.
With the ignition switch in the ON or START position, power is supplied

to ignition relay (located in IPDM E/R),

through 10A fuse [No. 1, located in fuse block (J/B)]

to BCM terminal 38,

through 10A fuse [No. 12, located in fuse block (J/B)]

to unified meter and A/C amp. terminal 22,

through 10A fuse [No. 14, located in fuse block (J/B)]

to combination meter terminal 8.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 6, located in fuse block (J/B)]

to BCM terminal 11.
Ground is supplied

to BCM terminal 52

to unified meter and A/C amp. terminals 29 and 30, and

to combination meter terminals 10, 11, and 12

through grounds M71 and M72,

to IPDM E/R terminals 38 and 60

through grounds E1 and E31.
ILLUMINATION OPERATION BY LIGHTING SWITCH
When the lighting switch is in 1ST position, BCM detects the LIGHTING SWITCH 1ST POSITION (ON) by
BCM combination switch reading function. And then, BCM sends position light request signal (ON) through
CAN communication and MR output signal.
When receiving position light request signal (ON), IPDM E/R turns ON tail lamp relay in IPDM E/R. And then
supplies power

through IPDM E/R terminal 22

to glove box lamp terminal 1

to A/T device illumination terminal 1 (with A/T)

to CVT device illumination terminal 1 (with CVT)

to rear sunshade front switch (illumination) terminal 5 (with rear sunshade)

PG-1
POWER SUPPLY, GROUND & CIRCUIT ELEMENTS
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION PG
A
B
PG

POWER SUPPLY, GROUND & CIRCUIT ELEMENTS
POWER SUPPLY ROUTING CIRCUIT ...................... 3
Schematic ................................................................ 3
Wiring Diagram — POWER — ................................. 4
BATTERY POWER SUPPLY — IGNITION SW.
IN ANY POSITION ................................................ 4
ACCESSORY POWER SUPPLY — IGNITION
SW. IN “ACC” OR “ON” ....................................... 10
IGNITION POWER SUPPLY — IGNITION SW.
IN “ON” AND/OR “START” ................................... 11
Fuse ....................................................................... 16
Fusible Link ............................................................ 16
Circuit Breaker ....................................................... 16
IPDM E/R (INTELLIGENT POWER DISTRIBUTION
MODULE ENGINE ROOM) ...................................... 17
System Description ................................................ 17
SYSTEMS CONTROLLED BY IPDM E/R ........... 17
FAIL-SAFE CONTROL ........................................ 17
IPDM E/R STATUS CONTROL ........................... 18
CAN Communication System Description .............. 18
CAN Communication Unit ...................................... 18
Function of Detecting Ignition Relay Malfunction ... 18
CONSULT-II Function (IPDM E/R) ......................... 19
CONSULT-II BASIC OPERATION ....................... 19
SELF-DIAG RESULTS ........................................ 19
DATA MONITOR ................................................. 19
ACTIVE TEST ..................................................... 20
Auto Active Test ..................................................... 21
DESCRIPTION .................................................... 21
OPERATION PROCEDURE ............................... 21
INSPECTION IN AUTO ACTIVE TEST MODE ... 22
Schematic .............................................................. 24
IPDM E/R Terminal Arrangement ........................... 25
Check IPDM E/R Power Supply and Ground Circuit ... 26
Inspection With CONSULT-II (Self-Diagnosis) ....... 27
Removal and Installation of IPDM E/R ................... 28
REMOVAL ........................................................... 28
INSTALLATION ................................................... 28GROUND ................................................................... 29
Ground Distribution ................................................. 29
MAIN HARNESS ................................................. 29
ENGINE ROOM HARNESS(LH) ......................... 33
ENGINE ROOM HARNESS(RH) ......................... 35
ENGINE CONTROL HARNESS/VQ ENGINE
MODELS ............................................................. 36
ENGINE CONTROL HARNESS/QR ENGINE
MODELS ............................................................. 37
BODY HARNESS ................................................ 38
BODY NO. 2 HARNESS ..................................... 40
HARNESS ................................................................. 42
Harness Layout ...................................................... 42
HOW TO READ HARNESS LAYOUT ................. 42
OUTLINE ............................................................. 43
MAIN HARNESS ................................................. 44
ENGINE ROOM HARNESS(LH) ......................... 47
ENGINE ROOM HARNESS(RH) ......................... 49
ENGINE CONTROL HARNESS(VQ ENGINE) ... 51
ENGINE CONTROL HARNESS(QR ENGINE) ... 53
BODY HARNESS ................................................ 55
BODY NO. 2 HARNESS ..................................... 57
ROOM LAMP HARNESS .................................... 59
TAIL HARNESS ................................................... 60
FRONT DOOR HARNESS .................................. 61
REAR DOOR HARNESS .................................... 62
Wiring Diagram Codes (Cell Codes) ...................... 63
ELECTRICAL UNITS LOCATION ............................ 67
Electrical Units Location ......................................... 67
ENGINE COMPARTMENT .................................. 67
PASSENGER COMPARTMENT ......................... 68
LUGGAGE COMPARTMENT .............................. 70
HARNESS CONNECTOR ......................................... 71
Description .............................................................. 71
HARNESS CONNECTOR (TAB-LOCKING
TYPE) .................................................................. 71
HARNESS CONNECTOR (SLIDE-LOCKING
TYPE) .................................................................. 72
HARNESS CONNECTOR (LEVER LOCKING
TYPE) .................................................................. 73
