2003 MINI COOPER Owners Manual

127
OVERVIEW REPAIRSOPERATION CONTROLS DATA INDEX
TOWINGTow-startingIt is not possible to start the engine of a
vehicle equipped with an automatic trans-
mission by towing or pushing.
For instructions on jump starting, refer to
page 124.
Never attempt to use your vehicle to push
another car, since damage to the energy-
absorbing bumpers could result.Towing a vehicle
Only tow vehicles with Continuously
Variable automatic Transmission
(CVT) with the front wheels raised or on a
special transport vehicle, otherwise the
transmission can be damaged.<
1. Place gear selector lever in neutral or idle
2. Towing speed:
Max. 45 mph / 70 km/h
3. Towing distance:
Max. 95 miles / 150 km
4. Leave the ignition key at position 1 to
ensure that the brake lamps, turn sig-
nals, horn and windshield wipers remain
operative, and to prevent the steering
lock detent from engaging
5. Switch on the hazard-warning system,
observe country-specific regulations.
Find some means of identifying the vehicle
in tow, for instance, place a sign or warning
triangle in the rear window.
Make sure that the ignition key
remains in position 1 even when the
electrical system has failed to prevent the
steering lock from engaging.
The steering and brakes are without power
assist when the engine is off. This means
that increased effort is required for steer-
ing and braking.<
Towing with a commercial tow truck >Do not tow with sling-type equipment
>Use a wheel-lift or flatbed carrier
>Please comply with applicable towing
laws.
Never allow passengers to ride in a
towed vehicle for any reason.<
ba.book Seite 127 Montag, 5. August 2002 8:09 20
ProCarManuals.com

128
ba.book Seite 128 Montag, 5. August 2002 8:09 20
ProCarManuals.com

OVERVIEW
CONTROLS
OPERATION, CARE, MAINTENANCE
OWNER SERVICE PROCEDURES
INDEX TECHNICAL DATA
129
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
Data
ba.book Seite 129 Montag, 5. August 2002 8:09 20
ProCarManuals.com

130
ENGINE DATA
MINI COOPER MINI COOPER S
Displacement
Number of cylinders cu in / cmµ97.52 / 1,598
497.52 / 1,598
4
Maximum output
at engine speed bhp / kW
rpm 115 / 85
6,000163 / 120
6,000
Maximum torque
at engine speedlb ft / Nm
rpm110 / 149
4,500155 / 210
4,000
Compression ratioε
10.6 8.3
Stroke
Borein / mm
in / mm3.38 / 85.8
3.03 / 773.38 / 85.8
3.03 / 77
Fuel-injection system Digital electronic engine-management system
ba.book Seite 130 Montag, 5. August 2002 8:09 20
ProCarManuals.com

131
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
DIMENSIONS
All measuring units in inches / millimeters. Smallest turning circle dia. 35 ft / 10.66 m.
ba.book Seite 131 Montag, 5. August 2002 8:09 20
ProCarManuals.com

132
WEIGHTS
MINI COOPER MINI COOPER S
Curb weight
with manual transmission
with Continuously Variable automatic
Transmission (CVT)lbs / kg
lbs / kg2,526 / 1,146
2,557 / 1,1602,678 / 1,215
–
Approved gross vehicle weight
with manual transmission
with Continuously Variable automatic
Transmission (CVT)lbs / kg
lbs / kg3,340 / 1,515
3,373 / 1,5303,494 / 1,585
–
Approved front axle load lbs / kg 1,918 / 870 1,962 / 890
Approved rear axle load lbs / kg 1,609 / 730 1,698 / 770
Approved roof load – with special MINI roof rack lbs / kg 165 / 75 165 / 75
Cargo area volume cu ft / liters 5.3 / 150 5.3 / 150
ba.book Seite 132 Montag, 5. August 2002 8:09 20
ProCarManuals.com

133
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
CAPACITIES
Notes
Fuel tank
Reserve gal. / liters approx. 13.2 / 50
approx. 2.1 / 8Fuel quality, see page 83
Windshield/
Headlamp washer reservoirquarts / liters approx. 2.1 / 2.0
approx. 2.6 / 2.5 More details, see page 94
Cooling system including heater circuit quarts / liters 5.6 / 5.3 MINI COOPER
6.3 / 6.0 MINI COOPER SMore details, see page 96
Engine with oil filter change quarts / liters 4.7 / 4.5 MINI COOPER
4.7 / 4.5 MINI COOPER SHigh Performance Synthetic Oil:
for more details, see page 95
Manual transmission quarts / liters approx. 2.1 / 2.0 MINI COOPER
approx. 1.8 / 1.7 MINI COOPER SContact your MINI Dealer
for more details
Continuously Variable automatic
Transmission (CVT)quarts / liters approx. 4.2 / 4.0 MINI COOPER Contact your MINI Dealer
for more details
