2003 MERCEDES-BENZ C CLASS COUPE Owners Manual

33
Getting started
Adjusting
Manual seat
1 Seat fore and aft adjustment
2 Seat cushion tilt
3 Seat height
4 Backrest tilt Seat fore and aft adjustment

Lift handle
1.

Slide seat to the desired position.

Allow handle 1 to reengage. Check for
proper engagement before driving.

Check for proper engagement before
driving.
Adjust to a comfortable seating position
that still allows you to reach the accelera-
tor/brake pedal safely. The position
should be as far rearward as possible, con-
sistent with ability to properly operate con-
trols.
Seat cushion tilt

Turn handwheel 2 forward or backward
until your upper legs are lightly sup-
ported. Seat height

Pull handle
3 up to raise seat cushion.
Push handle 3 down to lower seat
cushion
Backrest tilt

Turn handwheel 4 forward or back-
ward.
Head restraint height
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
iWhen moving the seats, be sure that
there are no items in the footwell or be-
hind the seats. Otherwise you could
damage the seats.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint to support the back of
the head approximately at ear level.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.

34 Getting startedAdjusting1Release knob
Manually adjust the height of the head
restraint by pulling it upward. To lower
the head restraint, push release knob 1
and press down on the head restraint.
Head restraint tilt

Manually adjust the angle of the head
restraint. Push or pull on the lower
edge of the head restraint cushion.
More information can be found in the
“Controls in detail” section (
page 89) Power seat*

Turn the key in the starter switch to
position
1 or 2.
or

Open the driver’s or front passenger
door.
The seat adjustment switches are located
in each front door.
1 Head restraint height
2 Seat height
3 Seat cushion tilt
4 Seat fore and aft adjustment
5 Backrest tilt Seat fore and aft adjustment

Press the switch forward or backward
in the direction of arrow
4.
Adjust to a comfortable seating posi-
tion that still allows you to reach the
accelerator / brake pedal safely. The
position should be as far to the rear as
possible, consistent with ability to
properly operate controls.iWhen moving the seat, be sure that
there are no items in the footwell or be-
hind the seat. Otherwise you could
damage the seat.
With the memory function*
(page 93) you can store seat posi-
tions together with settings for the
steering wheel and the exterior rear
view mirrors.

35
Getting started
Adjusting
Seat height
Press the switch up or down in the
direction of arrow
2.
Seat cushion tilt

Press the switch up or down in the
direction of arrow 3 until your upper
legs are lightly supported.
Backrest tilt

Press the switch forward or back in
direction of arrow 5 until your arms are
slightly angled when holding the steer-
ing wheel.
Head restraint height

Press the switch up or down in the di-
rection of arrow 1. Head restraint tilt

Manually adjust the angle of the head
restraint. Push or pull on the lower
edge of the head restraint cushion.
More information can be found in the
“Controls in detail” section (
page 89). Folding the front seat backrest forward
1 Release lever
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint to support the back of
the head approximately at ear level.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
iIn addition to the front seat backrests,
the front seat cushions can also be
shifted forward to permit easy access
to the rear whenever the seat is located
in the rear half of its adjustment range.
Swivel backrest forward by pulling the
release lever until the seat moves in a
combined forward and upward move-
ment.

36 Getting startedAdjustingFolding backrest forward
Pull release lever1 forward and tilt the
seat backrest forward.

Vehicles with manual seat adjustment:
If necessary, press the head restraint
downward while tilting the backrest
forward. Folding backrest back

Fold and press the backrest rearward
until it engages in driving position.

Vehicles with manual seat adjustment:
If necessary, pull the head restraint out
while tilting the seat back.
More information can be found in the
“Controls in detail” section (
page 89). Rear seat head restraints
1 Lock button
iVehicles with power seat*: The head
restraints will automatically move
down.
iVehicles with power seat*: The head
restraint returns to its previous posi-
tions.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

37
Getting started
Adjusting
Folding head restraints back
Push lock button
1.
The head restraints will fold backward.
Placing head restraint upright

Pull the head restraint forward until it
locks into position.
Two different head restraint angle posi-
tions are available.
Head restraint height
1 Release knob Raising:

Pull up on head restraint.
If the head restraint is fully retracted,
press release knob
1 and pull the head
restraint out.
Lowering:

Push button 1.

Push down on head restraint.
Steering wheel
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint to support the back of
the head approximately at ear level.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing, or driving without the adjustment
locked could cause the driver to lose control
of the vehicle.
When leaving the vehicle, always remove the
key from the starter switch and lock your ve-
hicle.
The electrical steering wheel adjustment
feature* can also be operated with the driv-
er’s door open. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

38 Getting startedAdjustingSteering wheel adjustment, manual1 Release handle
To unlock the steering column, pull
handle 1 out until its stop limit.

Adjust the steering wheel to the de-
sired position.

To lock, press handle 1 all the way in
until it engages.
The steering wheel is once again
locked into position. Steering wheel adjustment, electrical*

Turn the key in the
starter switch to
position 1 or 2.
or

Open the driver’s door.
The switch is located on the steering col-
umn (lower left).
1 Steering column, lengthen or shorten
2 Steering column, height
!Do not drive the vehicle until you have
properly locked the steering column.
If the warning message
STEERING
WHEEL ADJUST - LOCK! is displayed
while the engine is running, the steer-
ing column is not locked (page 268).

39
Getting started
Adjusting
Steering column, lengthen or shorten
Move stalk forward or backward in the
direction of arrow
1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.
Steering column, height

Move stalk up or down in the direction
of arrow 2. Make sure that your legs
can move freely and that all the dis-
plays (including malfunction and indi-
cator lamps) on the instrument cluster
are clearly visible.
Mirrors
Adjust the inside and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions. Inside rear view mirror

Manually adjust the inside rear view
mirror.
More information can be found in the
“Controls in detail” section (
page 138).
iWith the memory function*
(page 93) you can store settings for
the steering wheel together with set-
tings for the exterior rear view mirrors
and seat positions.
Warning!
G
In the case of an accident liquid electrolyte
may escape the mirror housing if the mirror
glass breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.

40 Getting startedAdjustingExterior rear view mirrorsThe buttons are located above the exterior
lamp switch.
1 Adjustment button
2 Passenger side mirror
3 Driver’s side mirror

Make sure that the ignition is switched
on.
All the lights in the instrument cluster
light up.

Press button 3 for the left mirror or
button 2 for the right mirror.

Push adjustment button 1 up, down,
left or right according to the setting de-
sired.
More information can be found in the
“Controls in detail” section (
page 138).
Warning!
G
Exercise care when using the passenger
side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
side rear view mirror or glance over your
shoulder before changing lanes. !Electrolyte drops coming into contact
with the vehicle paint finish can only be
completely removed while in their
liquid state by applying plenty of water.
iWith the memory function*
(page 93) you can store settings for
the exterior rear view mirrors together
with seat positions and settings for the
steering wheel.
!If an exterior rear view mirror housing
is forcibly pushed forward or backward,
reposition it by applying firm pressure
until it snaps into place. The mirror
housing is now properly positioned and
you can adjust the mirror normally.
