2003 Hyundai Grandeur Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 11
WARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main
switch on the driver's door andthe individual door window switch in opposing directions atthe same time. If this is done, the window will stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety. HXG029
Close
Open
HXG179
B080B01L-AAT Adjusting Seat Forward and Rearward
B080A01A-AAT ADJUSTABLE FRONT SEATS
In order to prevent operation of the passenger front and rear windows, awindow lock switch(2) is provided on the armrest of the driver's door. To disable the power windows, press thewindow lock switch. To revert to nor- mal operation, press the window lock switch a second time. NOTE:
The power windows can be oper- ated for 30 seconds after the igni-tion key is turned to the "ACC" or "LOCK" positions, or removed from the ignition switch.If the front doors are opened during this 30 second period, the power windows can no longer be operatedwithout the ignition key turned to the "ON" position.
HXG129-1
!WARNING:
Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control or an accident which may cause death,serious injury, or property damage.
!

1- 12 FEATURES OF YOUR HYUNDAI
To move the seat toward the front or rear, pull the lock release lever up- ward. This will release the seat on itstrack so you can move it forward or rearward to the desired position. When you find the position you want, releasethe lever and slide the seat forward or rearward on its track until it locks into the desired position and cannot bemoved further.
HXG103
B080C01A-AAT Adjusting Seatback Angle
To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at theoutside edge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback intoposition, release the recliner control lever. WARNING:
To minimize risk of severe injury in the event of a collision or a suddenstop, both the driver and passen- ger seatbacks should always be in an upright position while the ve-hicle is in motion. The protection provided by the seat belts and airbags in a frontal collision may bereduced significantly when the seatbacks are reclined. There is greater risk that the driver and pas-senger will slide under the belt which may result in serious injury if a crash occurs when the seatbacksare reclined. The seat belt cannot provide full protection to an occupant if theseatback is reclined.
!
WARNING:
To ensure the seat is locked se- curely, attempt to move the seat forward or rearward without usingthe lock release lever.!

FEATURES OF YOUR HYUNDAI 1- 13
B080E01L-AAT Lumbar Support Control To adjust the lumbar support, turn the handle on the outboard or left side of the seat. To increase the amount of lumbar support, pull the lever forward.To decrease it, push the lever toward the rear.
1. Minimum support
2. Maximum support HXG108
2
1
B080G01L
WARNING:
o For maximum effectiveness in case of an accident the headrestshould be adjusted so the top of the headrest is at the same heightas the top of the occupant's ears. For this reason, the use of a cush- ion that holds the body awayfrom the seatback should not be recommended.
o Do not operate vehicle with the headrests removed as injury tothe occupants may occur in the event of an accident. Headrestsmay provide protection against neck injuries when properly ad- justed.
!HXG200J
Lock Knob
B080D01L-GAT Adjustable Headrests Headrests are designed to help re- duce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. If equipped with a hori- zontally adjustable type of headrest,pull on the top.

1- 14 FEATURES OF YOUR HYUNDAI
B090A03L-AAT POWER SEAT (If installed) The front seat can be adjusted appro- priately by using the control knobs onthe left side of the seat. Before driving, adjust the seat to the proper position so as to easily control the steeringwheel, pedals and switches on the instrument panel.
HXG180
1
2
B090B01L-AAT Adjusting Seat Forward and Rearward Pull the control knob forward or back- ward to move the seat forward or back-ward to the desired position. Release the knob and then the seat will remain at that position.
1. Seat Back Reclining Control Knob
2. Seat Cushion Forward, Rearward
and Height Adjusting Control Knob
WARNING:
o Never attempt to adjust the seat while the vehicle is moving. Thiscould result in loss of control oran accident causing death, seri- ous injury, or property damage.
o Do not sit or lean unnecessarily
close to the airbag.
CAUTION:
Do not operate two knobs at the same time.
!
!
B080F01S-AAT Seat Cushion Height Adjustment (Driver's Seat Only)
To raise or lower the front part of the seat cushion, turn the front knob for-ward or rearward. To raise or lower the rear part of the seat cushion, turn the rear knob forward or rearward. HXG106

FEATURES OF YOUR HYUNDAI 1- 15
HXG181
B090D01Y-AAT Adjusting Seatback Angle
Rotate the upper portion of the control knob forward or backward to recline the seatback to the desired position. Release the control knob and then the seatback will remain in that position. WARNING:
To minimize the risk of personalinjury in the event of a collision ora sudden stop, both the driver's and passenger's seatbacks should remain in an upright position whilethe car is in motion. The protection provided by the seat belts and airbags may be reduced signifi-cantly when the seatbacks are re- clined. There is a greater risk that the seat occupants will slide underthe belt resulting in serious injury if a crash occurs when the seatbacks are reclined. The seat belt cannot provide full protection to an occu- pant if the seatback is reclined.
!
B090C01Y-AAT Seat Cushion Height Adjustment
Move the front portion of the control knob up or down to raise or lower the front part of the seat cushion. Move the rear portion of the control knob up ordown to raise or lower the rear part of the seat cushion. HXG182

1- 16 FEATURES OF YOUR HYUNDAI
To memorize driving position
1. Turn the ignition key "ON".
2. Adjust the driver's seat, outside rear-
view mirrors and steering wheel col- umn (if installed the steering wheel electric tilt and telescopic) to thedesired position.
3. Push the "M" button on the I.M.S
until the signal beeps.
4. Within five seconds, push button "1" or "2" until the signal beeps twice.The beep sounds mean that thepositions are memorized in the I.M.S. To activate the memorized posi- tion When you push button "1" or "2", the driving position will be automatically adjusted to the position recorded forthat button. "AUTO" button function When the "AUTO" button is "ON", the system will move the driver's seat for- ward or rearward and steering wheelcolumn up/down or inward/outward, so you can comfortably enter and exit the vehicle.
o It will move driver's seat rearward
and steering wheel column up/down or inward/outward, when the igni- tion key is pulled out.
o It will move driver's seat forward
and steering wheel column to theoriginal position, when the ignition key is inserted.
o While the vehicle is moving back- ward, the outside rearview mirrorswill automatically move downwardto change the area visible with the outside mirrors.
! CAUTION:
In the following conditions, the I.M.S will not operate.
1. When the "1" or "2" button is not pushed within five seconds.
2. When the seat is being adjusted.
3. When the "STOP" button is
pushed.
B090E03L-GAT I.M.S (Integrated Memory Sys- tem) (If installed) The Integrated Memory System con- trols are located on the left side ofdriver's door. After adjusting the posi- tion of the driver's seat, outside rear- view mirrors and steering wheel col-umn (if installed the steering wheel electric tilt and telescopic), use the I.M.S to memorize them. Two differentdriving position profiles can be entered in the I.M.S. If you turn the ignition key to the "ON" position, the memorizedposition is adjusted automatically. HXG212

FEATURES OF YOUR HYUNDAI 1- 17
Driver's seat
B100A01Y-AAT SEAT WARMER (If installed)
HXG620
Passenger's seat
The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi- tion, push either of the switches towarm the driver's seat or the passenger's seat. During mild weather or under condi-tions where the operation of the seat warmer is not needed, keep the switches in the "OFF" position.
B140A03L
B140A01S-AAT REAR SEAT WARNING For the safety of all passengers, lug- gage or other cargo should not be piled higher than the top of the seatback. In addition, do not place objects on therear shelf as they may move forward during braking or in an accident and strike vehicle passengers.
NOTE: If the remote control outside rear- view mirror switch knob is placed in the middle position of the switch,the outside rearview mirrors will not operate while the vehicle is mov- ing backward. When the shift leveris moved the "R" position, only the passenger's outside rearview mir- ror will move downward.

1- 18 FEATURES OF YOUR HYUNDAI
FREE
LOCK
B120A01Y-GAT REAR SEATBACK SAFETY LOCK (If installed) If the rear seatback lock lever (located on the backside of the rear seatback) is in the "LOCK" position when the rear seatbacks are closed, it will not bepossible to fold the rear seatback by using the release lock lever. In this instance, move the lock lever to the"FREE" position and fold the rear seatback. The rear seatback lock le- ver is designed to provide protectionfrom unauthorized entry into the trunk. B120A03L
WARNING:
The purpose of the folding rear seatbacks is to allow you to carrylonger objects than could other- wise be accommodated. Never al- low passengers to sit on top of thefolded down seatback. This could result in injury in case of an acci- dent or a sudden braking as this isnot a designated seating position and seat belt restraint systems are not accessible when the seatbacksare folded down. B110A02L!B110A01L
B110A01L-GAT FOLDING REAR SEATBACKS
o To unlock the seatback, depress
the seatback locking button, then pull forward on the seatback panel.
o When you return the seatback to its
upright position, always be sure ithas locked into position by pulling and pushing on the top of theseatback.
