DODGE TOWN AND COUNTRY 2003 Service Manual 8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch................ 8W-30-28
A/C Compressor Clutch Relay...... 8W-30-4, 18, 28
A/C Pressure Sensor............. 8W-30-11, 25, 35
Accelerator

8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch................ 8W-30-28
A/C Compressor Clutch Relay...... 8W-30-4, 18, 28
A/C Pressure Sensor............. 8W-30-11, 25, 35
Accelerator Pedal Position Sensor........ 8W-30-42
Adjustable Pedals Module.............. 8W-30-27
Adjustable Pedals Relay............... 8W-30-27
Adjustable Pedals Switch.............. 8W-30-27
Ambient Temperature Sensor............ 8W-30-9
Auto Shut Down Relay . 8W-30-4, 8, 13, 17, 20, 22, 23
Battery................ 8W-30-2, 6, 14, 17, 28, 36
Battery Temperature Sensor.......... 8W-30-9, 35
Body Control Module............. 8W-30-5, 19, 29
Boost Pressure Sensor................. 8W-30-35
Brake Lamp Switch........... 8W-30-7, 21, 31, 41
Cabin Heater Assist.................. 8W-30-32
Camshaft Position Sensor......... 8W-30-9, 23, 34
Clockspring................. 8W-30-5, 18, 33, 40
Clutch Pedal Interlock Switch............ 8W-30-4
Clutch Pedal Upstop Switch............ 8W-30-40
Controller Antilock Brake.............. 8W-30-19
Crank Case Ventilation Heater.......... 8W-30-29
Crankshaft Position Sensor....... 8W-30-10, 23, 34
Data Link Connector............. 8W-30-3, 19, 32
Dosing Pump....................... 8W-30-32
ECM/PCM Relay.......... 8W-30-28, 30, 34, 36, 38
EGR Solenoid.................... 8W-30-20, 38
Engine Control Module . . 8W-30-28, 29, 30, 31, 32, 33,
34, 35, 36, 37, 38, 39, 40, 41, 42
Engine Coolant Temp Sensor...... 8W-30-11, 25, 35
Engine Oil Pressure Sensor............. 8W-30-31
Engine Oil Pressure Switch........... 8W-30-7, 21
EVAP/Purge Solenoid............... 8W-30-4, 18
Front Control Module.......... 8W-30-2, 5, 18, 19,
20, 26, 32, 40, 27
Fuel Heater........................ 8W-30-39
Fuel Heater Relay................. 8W-30-29, 39
Fuel Injector No. 1.............. 8W-30-13, 22, 37
Fuel Injector No. 2.............. 8W-30-13, 22, 37
Fuel Injector No. 3.............. 8W-30-13, 22, 37
Fuel Injector No. 4.............. 8W-30-13, 22, 37
Fuel Injector No. 5................... 8W-30-22
Fuel Injector No. 6................... 8W-30-22
Fuel Pressure Sensor................. 8W-30-41
Fuel Pressure Solenoid................ 8W-30-30
Fuel Pump Module.............. 8W-30-5, 19, 29
Fuel Pump Relay.................. 8W-30-5, 19
Fuse 15...................... 8W-30-14, 32, 39
Fuse 16............... 8W-30-4, 8, 13, 17, 20, 22,
23, 28, 30, 34, 36, 38
Fuse 17............... 8W-30-2, 5, 17, 19, 29, 39
Fuse 18......................... 8W-30-28, 27
Fuse 26........................... 8W-30-41
Fuselink........................... 8W-30-36
Component Page
G100....................... 8W-30-2, 6, 14, 17
G101.................... 8W-30-2, 6, 14, 17, 28
G103.............. 8W-30-7, 16, 20, 21, 28, 29, 32
G200............................. 8W-30-27
G300.................... 8W-30-4, 7, 21, 31, 40
G302...................... 8W-30-5, 19, 29, 39
Generator..................... 8W-30-4, 17, 29
Glow Plug No. 1..................... 8W-30-36
Glow Plug No. 2..................... 8W-30-36
Glow Plug No. 3..................... 8W-30-36
Glow Plug No. 4..................... 8W-30-36
Glow Plug Relay..................... 8W-30-36
Idle Air Control Motor.............. 8W-30-12, 24
Ignition Coil...................... 8W-30-8, 23
Ignition Switch................... 8W-30-16, 26
Inlet Air Temperature Sensor......... 8W-30-10, 24
Input Speed Sensor................... 8W-30-14
Integrated Power Module..... 8W-30-2, 3, 4, 5, 8, 13,
14, 16, 17, 18, 19, 20, 22,
23, 26, 28, 29, 30, 32, 34,
36, 38, 39, 40, 41, 27
Knock Sensor.................... 8W-30-12, 25
Leak Detection Pump................. 8W-30-26
Left Speed Control Switch......... 8W-30-5, 18, 33
Lift Pump Motor..................... 8W-30-39
Lift Pump Relay..................... 8W-30-39
Manifold Absolute Pressure Sensor..... 8W-30-11, 25
Mass Air Flow Sensor................. 8W-30-30
Natural Vacuum Leak Detection Assembly . . 8W-30-16
Output Speed Sensor................. 8W-30-14
Oxygen Sensor 1/1 Upstream.......... 8W-30-6, 20
Oxygen Sensor 1/2 Downstream........ 8W-30-6, 20
Power Mirror Switch.................. 8W-30-27
Powertrain Control Module . . 8W-30-2, 3, 4, 5, 6, 7, 8,
9, 10, 11, 12, 13, 14, 15, 16,
17, 19, 21, 22, 23, 24, 25, 26
Powertrain Control Module............. 8W-30-18
Powertrain Control Module............. 8W-30-20
Radiator Fan Relay................. 8W-30-8, 18
Radiator Fan Relay No. 1.............. 8W-30-41
Radiator Fan Relay No. 2.............. 8W-30-41
Radiator Fan Relay No. 3.............. 8W-30-41
Right Speed Control Switch........ 8W-30-5, 18, 33
Solenoid/Pressure Switch Assy........ 8W-30-14, 15
Speed Control Servo................ 8W-30-7, 21
Starter Motor Relay.............. 8W-30-5, 19, 29
Throttle Position Sensor............ 8W-30-10, 24
Transmission Control Module........... 8W-30-24
Transmission Control Relay............. 8W-30-14
Transmission Range Sensor.......... 8W-30-15, 24
Vehicle Speed Sensor............... 8W-30-12, 38
Water In Fuel Sensor................. 8W-30-40
RS8W-30 FUEL/IGNITION SYSTEM8W-30-1
