Page 1081 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual PASSENGER HEATED SEAT MODULE C3 - GREEN 4 WAY CAV CIRCUIT FUNCTION 1 P87 16LG/OR SEAT TEMP SENSOR INPUT 2 P89 20LG/BR SEAT SENSOR 5 VOLT SUPPLY 3 Z848 18BK/OR GROUND 4 P88 16LG/LB SEAT CUSHION HEATER

Page 1082 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual PASSENGER POWER SEAT SWITCH - GREEN 10 WAY CAV CIRCUIT FUNCTION 1 Z848 14BK/OR GROUND 2 P44 14LG/VT PASSENGER RECLINER UP SWITCH SENSE 3 P16 14LG/WT PASSENGER HORIZONTAL REARWARD SWITCH SENSE 4 P42 14

Page 1083 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual PASSENGER SEAT BELT TENSIONER-2WAY CAV CIRCUIT FUNCTION 1 R54 18LB/YL PASSENGER SEAT BELT TENSIONER LINE 2 2 R56 18LB/DG PASSENGER SEAT BELT TENSIONER LINE 1 POWER FOLDING MIRROR SWITCH (EXPORT) - BLA

Page 1084 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual POWER LIFTGATE MODULE C2 - 20 WAY CAV CIRCUIT FUNCTION 1 Q90 20TN/VT LIFTGATE HALL EFFECT SUPPLY 2- - 3 Q151 22TN/DB LIFTGATE ENGAGE/DISENGAGE SWITCH SENSE 4- - 5 Q76 22OR/LB PINCH SENSOR SIGNAL 6- -

Page 1085 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual POWER MIRROR SWITCH - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 P70 20TN/LB RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 1 P70 20TN/LB (MEMORY) RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 2- - 3- - 4- - 5- - 6 P73 2

Page 1086 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual POWER WINDOW SWITCH (LHD LOWLINE) - BLACK 8 WAY CAV CIRCUIT FUNCTION 1 F304 16WT/PK FUSED WINDOW CIRCUIT BREAKER OUTPUT 2 Z421 12BK/BR GROUND 3 Z421 12BK/BR GROUND 4- - 5 Q26 12OR/GY MASTER WINDOW SWI

Page 1087 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual POWERTRAIN CONTROL MODULE C1 (SBEC) - GRAY/BLACK 40 WAY CAV CIRCUIT FUNCTION 1- - 2 K18 16DB/OR IGNITION COIL NO. 3 DRIVER 3 K17 16DB/TN IGNITION COIL NO. 2 DRIVER 4- - 5 V32 18VT/YL SPEED CONTROL ON/

Page 1088 of 2177

DODGE TOWN AND COUNTRY 2003 Service Manual POWERTRAIN CONTROL MODULE C2 (NGC) - BLACK 38 WAY CAV CIRCUIT FUNCTION 1- - 2- - 3- - 4- - 5- - 6- - 7- - 8- - 9 K17 18DB/TN COIL CONTROL NO. 2 10 K19 18DB/DG COIL CONTROL NO. 1 11 K14 16 BR/TN INJECT
