8W-51 REAR LIGHTING
Component Page
Backup Lamp Switch............... 8W-51-3, 5
Brake Lamp Switch.................. 8W-51-7
Center High Mounted Stop Lamp-
Aftermarket...................... 8W-51-7
Center High Mounted Stop Lamp/Cargo
Lamp........................... 8W-51-7
Fender Lamp-Front Left............... 8W-51-4
Fender Lamp-Front Right............. 8W-51-4
Fender Lamp-Rear Left............... 8W-51-4
Fender Lamp-Rear Right.............. 8W-51-4
Front Control Module......... 8W-51-2, 3, 5, 6, 7
Fuse 15........................ 8W-51-2, 3, 7
Fuse 24............................ 8W-51-7
Fuse 32............................ 8W-51-3
Fuse 33............................ 8W-51-7
Fuse 34............................ 8W-51-2
Fuse 38............................ 8W-51-3Component Page
G103........................ 8W-51-2, 3, 5, 6
G104........................ 8W-51-2, 3, 5, 6
G202.............................. 8W-51-7
Integrated Power Module...... 8W-51-2, 3, 5, 6, 7
License Lamp-Left................... 8W-51-2
License Lamp-Right.................. 8W-51-3
Park Lamp Relay................ 8W-51-2, 3, 7
Park/Turn Signal Lamp-Left Front....... 8W-51-2
Park/Turn Signal Lamp-Right Front..... 8W-51-3
Tail/Stop/Turn Signal Lamp-Left...... 8W-51-2, 5
Tail/Stop/Turn Signal Lamp-Right....... 8W-51-6
Tailgate Lamp Assembly............. 8W-51-2, 4
Trailer Tow Connector................ 8W-51-7
Trailer Tow Connector- Add On....... 8W-51-5, 7
Transmission Range Sensor............ 8W-51-5
Transmission Solenoid/TRS Assembly.... 8W-51-5
DR8W-51 REAR LIGHTING 8W - 51 - 1

8W-80 CONNECTOR PIN-OUTS
Component Page
4WD Switch (Manual Transfer Case)..... 8W-80-5
A/C Compressor Clutch............... 8W-80-5
A/C Pressure Transducer.............. 8W-80-5
A/C Pressure Transducer (Diesel)........ 8W-80-5
A/C-Heater Control C1................ 8W-80-6
A/C-Heater Control C2................ 8W-80-6
Accelerator Pedal Position Sensor
(5.7L/Diesel M/T Normal Build)....... 8W-80-6
Adjustable Pedal Motor............... 8W-80-7
Adjustable Pedal Switch............... 8W-80-7
Airbag Control Module................ 8W-80-7
Airbag Control Module-Left Side Impact . . 8W-80-8
Airbag Control Module-Right Side Impact . 8W-80-8
Airbag-Driver Squib 1................ 8W-80-8
Airbag-Left Curtain Squib............. 8W-80-8
Airbag-Passenger Squib 1............. 8W-80-9
Airbag-Right Curtain Squib............ 8W-80-9
Ambient Temperature Sensor........... 8W-80-9
Amplifier Audio C1................... 8W-80-9
Amplifier Audio C2.................. 8W-80-10
Automatic Day/Night Mirror (Except
Base).......................... 8W-80-10
Backup Lamp Switch (3.7L/4.7L/5.7L/
8.0L)........................... 8W-80-10
Battery Temperature Sensor........... 8W-80-11
Blend Door Actuator (Single-Zone)...... 8W-80-11
Blower Motor...................... 8W-80-11
Blower Motor Resistor Block.......... 8W-80-11
Boost Pressure Sensor (Diesel)......... 8W-80-11
Brake Fluid Level Switch............. 8W-80-12
Brake Lamp Switch................. 8W-80-12
Brake Transmission Shift Interlock
Solenoid........................ 8W-80-12
C100 (Diesel)...................... 8W-80-12
C100 (Diesel)...................... 8W-80-13
C100 (Gas)........................ 8W-80-13
C100 (Gas)........................ 8W-80-13
C106 (5.7L)........................ 8W-80-14
C106 (5.7L)........................ 8W-80-14
C107 (5.7L)........................ 8W-80-15
C107 (5.7L)........................ 8W-80-15
C108 (Diesel)...................... 8W-80-15
C108 (Diesel)...................... 8W-80-16
C110 (Diesel)...................... 8W-80-16
C110 (Diesel)...................... 8W-80-16
C112 (Diesel)...................... 8W-80-17
C112 (Diesel)...................... 8W-80-17
C115 (Diesel)...................... 8W-80-17
C115 (Diesel)...................... 8W-80-17
C116 (Diesel)...................... 8W-80-17
C116 (Diesel)...................... 8W-80-18
C117 (Diesel)...................... 8W-80-18Component Page
C117 (Diesel)...................... 8W-80-18
C130............................. 8W-80-18
C130............................. 8W-80-20
C200............................. 8W-80-22
C200............................. 8W-80-22
C201............................. 8W-80-22
C201............................. 8W-80-23
C202............................. 8W-80-23
C202............................. 8W-80-23
C206............................. 8W-80-23
C206 (SLT+)....................... 8W-80-24
C216............................. 8W-80-24
C216............................. 8W-80-24
C217............................. 8W-80-24
C217............................. 8W-80-25
C218............................. 8W-80-25
C218............................. 8W-80-25
C219............................. 8W-80-26
C219............................. 8W-80-28
C220............................. 8W-80-29
C220............................. 8W-80-30
C301............................. 8W-80-30
C301............................. 8W-80-31
C302............................. 8W-80-31
C302............................. 8W-80-31
C304............................. 8W-80-32
C304............................. 8W-80-32
C305............................. 8W-80-32
C305............................. 8W-80-33
C306............................. 8W-80-33
C306............................. 8W-80-33
C307 (Tail Lamp Jumper)............. 8W-80-34
C307 (Tail Lamp Jumper)............. 8W-80-34
C308............................. 8W-80-34
C308............................. 8W-80-35
C309............................. 8W-80-35
C309............................. 8W-80-35
C310 (Tail Lamp Jumper)............. 8W-80-36
C310 (Tail Lamp Jumper)............. 8W-80-36
C311 (Except SLT+)................. 8W-80-36
C311 (Except SLT+)................. 8W-80-36
C312............................. 8W-80-37
C312............................. 8W-80-37
C313............................. 8W-80-37
C313............................. 8W-80-38
C314............................. 8W-80-38
C314............................. 8W-80-38
C315 (Heated/Power Seat)............ 8W-80-38
C315............................. 8W-80-39
C316............................. 8W-80-39
C316............................. 8W-80-39
C317............................. 8W-80-39
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 1

Component Page
C317............................. 8W-80-40
C319............................. 8W-80-40
C319............................. 8W-80-40
C322............................. 8W-80-40
C322............................. 8W-80-41
C323............................. 8W-80-41
C323............................. 8W-80-41
C327............................. 8W-80-42
C327............................. 8W-80-42
C328............................. 8W-80-42
C328............................. 8W-80-42
Camshaft Position Sensor (Diesel)...... 8W-80-42
Camshaft Position Sensor (Gas)........ 8W-80-42
Capacitor......................... 8W-80-43
Center High Mounted Stop Lamp/Cargo
Lamp.......................... 8W-80-43
Cigar Lighter Outlet................. 8W-80-43
Clearance Lamp No. 1 (Heavy Duty).... 8W-80-43
Clearance Lamp No. 2 (Heavy Duty).... 8W-80-43
Clearance Lamp No. 3 (Heavy Duty).... 8W-80-44
Clearance Lamp No. 4 (Heavy Duty).... 8W-80-44
Clearance Lamp No. 5 (Heavy Duty).... 8W-80-44
Clockspring C1..................... 8W-80-44
Clockspring C2..................... 8W-80-44
Clockspring C3..................... 8W-80-45
Clockspring C4..................... 8W-80-45
Clockspring C5 (Remote Radio)........ 8W-80-45
Clutch Interlock Brake Switch......... 8W-80-45
Coil On Plug No. 1 (3.7L/4.7L/5.7L)..... 8W-80-45
Coil On Plug No. 2 (3.7L/4.7L/5.7L)..... 8W-80-46
Coil On Plug No. 3 (3.7L/4.7L/5.7L)..... 8W-80-46
Coil On Plug No. 4 (3.7L/4.7L/5.7L)..... 8W-80-46
Coil On Plug No. 5 (3.7L/4.7L/5.7L)..... 8W-80-46
Coil On Plug No. 6 (3.7L/4.7L/5.7L)..... 8W-80-47
Coil On Plug No. 7 (4.7L/5.7L)......... 8W-80-47
Coil On Plug No. 8 (4.7L/5.7L)......... 8W-80-47
Compass/Mini-Trip Computer
(Except Base).................... 8W-80-47
Condenser Fan..................... 8W-80-48
Controller Antilock Brake C1.......... 8W-80-48
Controller Antilock Brake C2 (ABS)..... 8W-80-48
Crankshaft Position Sensor........... 8W-80-49
Cylinder Lock Switch-Driver (Premium) . . 8W-80-49
Cylinder Lock Switch-Passenger
(Premium)...................... 8W-80-49
Data Link Connector................ 8W-80-49
Data Link Connector................ 8W-80-50
Dome Lamp....................... 8W-80-50
Door Ajar Switch-Driver (Base)........ 8W-80-50
Door Ajar Switch-Left Rear (Base)...... 8W-80-50
Door Ajar Switch-Passenger (Base)...... 8W-80-50
Door Ajar Switch-Right Rear (Base)..... 8W-80-51
Door Lock Motor/Ajar Switch-Driver
(Except Base).................... 8W-80-51Component Page
Door Lock Motor/Ajar Switch-Left Rear
(Except Base).................... 8W-80-51
Door Lock Motor/Ajar Switch-Passenger
(Except Base).................... 8W-80-51
Door Lock Motor/Ajar Switch-Right Rear
(Except Base).................... 8W-80-52
Door Lock Switch-Passenger........... 8W-80-52
Door Window/Lock Switch............ 8W-80-52
Driver Blend Door Actuator
(Dual-Zone)...................... 8W-80-52
Driver Door Module C1.............. 8W-80-53
Driver Door Module C2.............. 8W-80-53
Driver Heated Seat Cushion........... 8W-80-53
Electric Brake Provision.............. 8W-80-53
Electronic Throttle Control Module
(5.7L).......................... 8W-80-54
Engine Control Module............... 8W-80-54
Engine Control Module............... 8W-80-55
Engine Coolant Temperature Sensor
(3.7L/4.7L/5.7L).................. 8W-80-56
Engine Coolant Temperature Sensor
(Diesel)......................... 8W-80-56
Engine Oil Pressure Switch........... 8W-80-57
Evap/Purge Solenoid (Except NGC)..... 8W-80-57
Evap/Purge Solenoid (NGC)........... 8W-80-57
Evaporator Temperature Sensor........ 8W-80-57
Fender Lamp-Front Left.............. 8W-80-58
Fender Lamp-Front Right............ 8W-80-58
Fender Lamp-Rear Left.............. 8W-80-58
Fender Lamp-Rear Right............. 8W-80-58
Fog Lamp-Left..................... 8W-80-58
Fog Lamp-Right.................... 8W-80-59
Fuel Control Actuator (Diesel)......... 8W-80-59
Fuel Heater (Diesel)................. 8W-80-59
Fuel Injector No. 1 (Diesel)............ 8W-80-59
Fuel Injector No. 1.................. 8W-80-59
Fuel Injector No. 2 (Diesel)............ 8W-80-60
Fuel Injector No. 2.................. 8W-80-60
Fuel Injector No. 3 (Diesel)............ 8W-80-60
Fuel Injector No. 3.................. 8W-80-60
Fuel Injector No. 4 (Diesel)............ 8W-80-60
Fuel Injector No. 4.................. 8W-80-61
Fuel Injector No. 5 (Diesel)............ 8W-80-61
Fuel Injector No. 5.................. 8W-80-61
Fuel Injector No. 6 (Diesel)............ 8W-80-61
Fuel Injector No. 6.................. 8W-80-61
Fuel Injector No. 7
(4.7L/5.7L/5.9L/8.0L)............... 8W-80-62
Fuel Injector No. 8
(4.7L/5.7L/5.9L/8.0L)............... 8W-80-62
Fuel Injector No. 9 (8.0L)............. 8W-80-62
Fuel Injector No. 10 (8.0L)............ 8W-80-62
Fuel Pump Module.................. 8W-80-63
Fuel Pump Motor (Diesel)............ 8W-80-63
Generator......................... 8W-80-63
8W - 80 - 2 8W-80 CONNECTOR PIN-OUTSDR

Component Page
Glove Box Lamp And Switch.......... 8W-80-63
Headlamp Switch................... 8W-80-63
Headlamp-Left..................... 8W-80-64
Headlamp-Right.................... 8W-80-64
Heated Seat Cushion-Passenger........ 8W-80-64
Heated Seat Switch-Driver............ 8W-80-64
Heated Seat Switch-Passenger......... 8W-80-65
Horn Switch....................... 8W-80-65
Horn-High Note.................... 8W-80-65
Horn-Low Note..................... 8W-80-65
Idle Air Control Motor (3.7L/5.9L/8.0L) . . 8W-80-65
Idle Air Control Motor (NGC).......... 8W-80-66
Ignition Coil (5.9L).................. 8W-80-66
Ignition Coil-Left (8.0L).............. 8W-80-66
Ignition Coil-Right (8.0L)............. 8W-80-66
Ignition Switch..................... 8W-80-67
Inlet Air Temperature/ Pressure Sensor
(Diesel)......................... 8W-80-67
Input Speed Sensor (3.7L/4.7L/5.7L)..... 8W-80-67
Instrument Cluster C1............... 8W-80-68
Instrument Cluster C2............... 8W-80-68
Instrument Cluster C3............... 8W-80-69
Intake Air Temperature Sensor........ 8W-80-69
Intake Air Temperature/Manifold Absolute
Pressure Sensor (Diesel)............ 8W-80-69
Integrated Power Module C1.......... 8W-80-70
Integrated Power Module C2.......... 8W-80-70
Integrated Power Module C3.......... 8W-80-71
Integrated Power Module C4.......... 8W-80-71
Integrated Power Module C5.......... 8W-80-72
Integrated Power Module C6.......... 8W-80-72
Integrated Power Module C7.......... 8W-80-73
Knock Sensor (3.7L)................. 8W-80-73
Knock Sensor-Left (5.7L)............. 8W-80-74
Knock Sensor-Right (5.7L)............ 8W-80-74
Leak Detection Pump (NGC).......... 8W-80-74
Leak Detection Pump................ 8W-80-74
License Lamp-Left.................. 8W-80-74
License Lamp-Right................. 8W-80-75
Lift Pump Motor (Diesel)............. 8W-80-75
Line Pressure Sensor (3.7L/5.7L)....... 8W-80-75
Line Pressure Sensor (4.7L)........... 8W-80-75
Lumbar Motor-Driver................ 8W-80-76
Lumbar Motor-Passenger............. 8W-80-76
Manifold Absolute Pressure Sensor
(3.7L/4.7L/5.7L).................. 8W-80-76
Manifold Absolute Pressure Sensor
(5.9L/8.0L)...................... 8W-80-76
Mode Door Actuator 1 (Panel To Floor) . . . 8W-80-77
Mode Door Actuator 2 (Defrost To Floor) . 8W-80-77
Multi-Function Switch............... 8W-80-77
Output Speed Sensor (3.7L/4.7L/5.7L) . . . 8W-80-77
Output Speed Sensor (5.9L)........... 8W-80-77
Output Speed Sensor (Diesel).......... 8W-80-78Component Page
Overdrive Switch................... 8W-80-78
Overhead Map/Reading Lamp (Except
Base).......................... 8W-80-78
Oxygen Sensor 1/1 Upstream.......... 8W-80-78
Oxygen Sensor 1/2 Downstream........ 8W-80-79
Oxygen Sensor 2/1 Upstream (California 4.7L/
California 5.9L).................. 8W-80-79
Oxygen Sensor 2/2 Downstream (California
4.7L/California 5.9L)............... 8W-80-79
Park/Turn Signal Lamp-Left Front...... 8W-80-80
Park/Turn Signal Lamp-Right Front.... 8W-80-80
Passenger Blend Door Actuator (Dual-
Zone).......................... 8W-80-80
Passenger Lumbar Switch............ 8W-80-80
Power Mirror-Left................... 8W-80-80
Power Mirror-Right................. 8W-80-81
Power Outlet...................... 8W-80-81
Power Outlet-Console (Except Base)..... 8W-80-81
Power Seat Motor-Driver Front Vertical . . 8W-80-81
Power Seat Motor-Driver Horizontal.... 8W-80-82
Power Seat Motor-Driver Rear Vertical . . 8W-80-82
Power Seat Switch-Driver............ 8W-80-82
Power Seat Switch-Passenger.......... 8W-80-82
Power Steering Pressure Switch
(3.7L/4.7L/5.7L).................. 8W-80-83
Power Window Motor-Driver.......... 8W-80-83
Power Window Motor-Left Rear........ 8W-80-83
Power Window Motor-Passenger........ 8W-80-83
Power Window Motor-Right Rear....... 8W-80-83
Power Window Switch-Left Rear....... 8W-80-84
Power Window Switch-Right Rear...... 8W-80-84
Power Window-Circuit Breaker........ 8W-80-84
Powertrain Control Module........... 8W-80-84
Powertrain Control Module........... 8W-80-85
Powertrain Control Module........... 8W-80-86
Powertrain Control Module C1 (JTEC) . . . 8W-80-87
Powertrain Control Module C1 (NGC) . . . 8W-80-88
Powertrain Control Module C2 (JTEC) . . . 8W-80-89
Powertrain Control Module C2 (NGC) . . . 8W-80-90
Powertrain Control Module C3 (JTEC) . . . 8W-80-91
Powertrain Control Module C3 (NGC) . . . 8W-80-92
Powertrain Control Module C4 (NGC) . . . 8W-80-93
Radio (Base)....................... 8W-80-94
Radio (Premium)................... 8W-80-94
Recirculation Door Actuator........... 8W-80-95
Remote Radio Switch-Left............ 8W-80-95
Remote Radio Switch-Right........... 8W-80-95
Seat Heater Interface Module.......... 8W-80-95
Sentry Key Immobilizer Module........ 8W-80-96
Speaker-Center Instrument Panel...... 8W-80-96
Speaker-Left Front Door.............. 8W-80-96
Speaker-Left Instrument Panel........ 8W-80-96
Speaker-Left Rear.................. 8W-80-96
Speaker-Right Front Door............ 8W-80-97
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

Component Page
Speaker-Right Instrument Panel....... 8W-80-97
Speaker-Right Rear................. 8W-80-97
Speed Control Servo................. 8W-80-97
Speed Control Switch-Left (ETC)....... 8W-80-98
Speed Control Switch-Left (Except ETC) . 8W-80-98
Speed Control Switch-Right (ETC)...... 8W-80-98
Speed Control Switch-Right (Except
ETC)........................... 8W-80-98
Switch-Driver Seat Belt.............. 8W-80-98
Switch-Passenger Airbag On-Off....... 8W-80-99
Tail/Stop/Turn Signal Lamp-Left....... 8W-80-99
Tail/Stop/Turn Signal Lamp-Right...... 8W-80-99
Tension Reducer-Seat Belt (Standard
Cab)........................... 8W-80-99
Tensioner-Left Seat Belt............. 8W-80-100
Tensioner-Right Seat Belt............ 8W-80-100
Throttle Position Sensor............. 8W-80-100
Throttle Position Sensor (Diesel)...... 8W-80-100
Trailer Tow Connector.............. 8W-80-101
Trailer Tow Connector-Add On........ 8W-80-101
Transfer Case Control Module C1...... 8W-80-101
Transfer Case Control Module C2...... 8W-80-102
Transfer Case Control Module C3...... 8W-80-102
Transfer Case Mode Sensor.......... 8W-80-102
Transfer Case Position Sensor (4.7L/
5.9L).......................... 8W-80-103
Transfer Case Selector Switch........ 8W-80-103
Transfer Case Shift Motor........... 8W-80-103
Transmission Control Module......... 8W-80-104Component Page
Transmission Range Sensor (5.9L/
Diesel)........................ 8W-80-105
Transmission Solenoid Assembly (5.9L/
8.0L).......................... 8W-80-105
Transmission Solenoid/Trs Assembly
(3.7L/4.7L/5.7L)................. 8W-80-106
Underhood Lamp.................. 8W-80-106
Vacuum Pump (Diesel).............. 8W-80-106
Vehicle Speed Sensor (Diesel)......... 8W-80-107
Vistronic Fan Drive (Diesel).......... 8W-80-107
Washer Fluid Level Switch........... 8W-80-107
Washer Pump Motor-Front........... 8W-80-107
Water In Fuel Sensor (Diesel)......... 8W-80-107
Wheel Speed Sensor-Left Front
(ABS)......................... 8W-80-108
Wheel Speed Sensor-Rear (ABS)....... 8W-80-108
Wheel Speed Sensor-Right Front
(ABS)......................... 8W-80-108
Wiper Motor-Front................. 8W-80-108
Washer Fluid Level Switch........... 8W-80-109
Washer Pump Motor-Front........... 8W-80-109
Water In Fuel Sensor (Diesel)......... 8W-80-109
Wheel Speed Sensor-Left Front
(ABS)......................... 8W-80-109
Wheel Speed Sensor-Rear (ABS)....... 8W-80-110
Wheel Speed Sensor-Right Front
(ABS)......................... 8W-80-110
Wiper Motor-Front................. 8W-80-110
8W - 80 - 4 8W-80 CONNECTOR PIN-OUTSDR

4WD SWITCH (MANUAL TRANSFER CASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K77 18BR/WT 4WD SWITCH SENSE
2 K4 18BK/LB SENSOR GROUND
A/C COMPRESSOR CLUTCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 20DB/BK A/C CLUTCH RELAY OUTPUT
2 Z359 18BK/BR GROUND
A/C PRESSURE TRANSDUCER - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K6 18VT/WT (EXCEPT NGC) 5 VOLT SUPPLY
2 K7 18OR (NGC) 5-VOLT SUPPLY
3 C18 18DB A/C PRESSURE SIGNAL
4- -
A/C PRESSURE TRANSDUCER (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K55 18LB/WT MASS AIR FLOW SENSOR SIGNAL
2 K72 18DG/OR 5 VOLTS SUPPLY
3 C18 18DB A/C PRESSURE SIGNAL
4- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 5

A/C-HEATER CONTROL C1 - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1 F15 20DB FUSED IGNITION SWITCH OUTPUT (RUN)
2 Z120 20WT/BK GROUND
3 C57 20DB/GY SENSOR GROUND
4 C33 20DB/RD MODE DOOR 2 DRIVER
5- -
6 C12 20LG/BK EVAPORATOR TEMPERATURE SENSOR SIGNAL
7- -
8 Y165 20OR/YL PANEL LAMPS DRIVER
9 C62 20DB/PK BLEND DOOR DRIVER
10 C35 20DG/YL MODE DOOR 1 DRIVER
11 C34 20DB/WT COMMON DOOR DRIVER
12 C32 20GY/DB RECIRCULATION DOOR DRIVER
13 C46 20YL/LG PASSENGER BLEND DOOR DRIVER
14 - -
15 C16 20LB/YL HEATED MIRROR RELAY CONTROL
16 D25 20VT/LG PCI BUS
A/C-HEATER CONTROL C2 - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 C4 16TN BLOWER MOTOR LOW DRIVER
3 C6 14LB BLOWER MOTOR M2 DRIVER
4- -
5 Z37 10BK/DB GROUND
6- -
7 C5 16LG BLOWER MOTOR M1 DRIVER
8- -
9- -
10 C7 10BK/TN BLOWER MOTOR HIGH DRIVER
ACCELERATOR PEDAL POSITION SENSOR (5.7L/DIESEL M/T NORMAL BUILD)-6WAY
CAV CIRCUIT FUNCTION
1 K81 20DB/DG APPS NO. 2 SIGNAL
2 K6 20VT/WT 5-VOLT SUPPLY
3 K7 20OR 5-VOLT SUPPLY
4 K981 20BR/DG APPS NO. 2 RETURN
5 K255 20WT/DG APPS NO. 1 SIGNAL
6 K223 20PK/DB APPS NO. 1 RETURN
8W - 80 - 6 8W-80 CONNECTOR PIN-OUTSDR

AIRBAG-PASSENGER SQUIB 1 - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
2 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
AIRBAG-RIGHT CURTAIN SQUIB - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R74 18LB/YL RIGHT CURTAIN SQUIB 1LINE 1
2 R76 18LB/WT RIGHT CURTAIN SQUIB 1 LINE 2
AMBIENT TEMPERATURE SENSOR-2WAY
CAV CIRCUIT FUNCTION
1 G31 20VT/LG (NGC) AAT SIGNAL
1 G31 20VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2 Y137 20VT/LB SENSOR GROUND
2 K4 20VT/LB (NGC) SENSOR GROUND
AMPLIFIER AUDIO C1 - GRAY 12 WAY
CAV CIRCUIT FUNCTION
1 X53 20DG LEFT FRONT SPEAKER (+)
2 X55 20BR/RD LEFT FRONT SPEAKER (-)
3 X57 20BR/LB LEFT REAR SPEAKER (-)
4 Z115 18DB/BK GROUND
5 X60 20DG/RD RADIO 12 VOLT OUTPUT
6 X56 20DB/RD RIGHT FRONT SPEAKER (-)
7 X54 20VT RIGHT FRONT SPEAKER (+)
8 X51 20BR/YL LEFT REAR SPEAKER (+)
9 X58 20DB/OR RIGHT REAR SPEAKER (-)
10 X52 20DB/WT RIGHT REAR SPEAKER (+)
11 Z126 18BK/DB GROUND
12 D25 20VT/GY PCI BUS
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 9
