2002 TOYOTA SOLARA Owners Manual (in English)

’02 SOLARA_U (L/O 0108)
2692002 MY SOLARA_U (OM33545U)
SPECIFICATIONS
Dimensions and weight 270
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Engine 270
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 271
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 271
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 275
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’02 SOLARA_U (L/O 0108)
2702002 MY SOLARA_U (OM33545U)
Model:
2AZ− FE and 1MZ −FE
Type: 2AZ− FE engine
4 cylinder in line, 4 cycle, gasoline
1MZ −FE engine
6 cylinder V type 4 cycle, gasoline
Bore and stroke, mm (in.): 2AZ− FE engine
88.5 96.0 (3.48 3.78)
1MZ −FE engine
87.5 83.0 (3.44 3.27)
Displacement, cm
3 (cu. in.):
2AZ− FE engine
2362 (144.1)
1MZ −FE engine
2995 (182.8)
Dimensions and weight
4865 (191.5)
1805 (71.1)
1425 (56.1)
∗
1520 (59.8)
Overall length mm (in.)
Overall width mm (in.)
Overall height mm (in.)
Wheelbase mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Vehicle capacity weight
(occupants + luggage) kg (lb.)2670 (105.1)
1545 (60.8)
340 (750)
∗: Unladen vehicle
4865 (191.5)
1805 (71.1)
1400 (55.1)
∗
1520 (59.8) 2670 (105.1)
1545 (60.8)410 (900)
Coupe Convertible
Engine

’02 SOLARA_U (L/O 0108)
2712002 MY SOLARA_U (OM33545U)
Fuel type:
2AZ− FE engine
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or
higher
1MZ −FE engine
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or
higher. For improved vehicle perfor-
mance, the use of premium unleaded
gasoline with an Octane Rating of 91
(Research Octane Number 96) or
higher is recommended.
Fuel tank capacity, L (gal., Imp. gal.): 70 (18.5, 15.4) ENGINE
Valve clearance (engine cold), mm (in.):
2AZ− FE engine
Intake 0.19—0.29 (0.007—0.011)
Exhaust 0.30—0.40 (0.012—0.016)
1MZ −FE engine
Intake 0.15—0.25 (0.006—0.010)
Exhaust 0.25—0.35 (0.010—0.014)
Spark plug type: 2AZ− FE engine
DENSO SK20R11
NGK IFR6A11
1MZ −FE engine
DENSO PK20TR11
NGK BKR6EKPB11
Spark plug gap, mm (in.): 1.1 (0.043)
Drive belt tension measured with Bor-
roughs drive belt tension gauge No.
BT −33− 73F (used belt), Ibf:
1MZ −FE engine 11520 ENGINE LUBRICATION
Oil capacity (drain and refill),
L (qt., Imp. qt.):
2AZ− FE engine
With filter 3.8 (4.0, 3.3)
Without filter 3.6 (3.8, 3.2)
1MZ −FE engine
With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
Oil grade:
API grade SJ “Energy −Conserving”, SL
“Energy −Conserving” or ILSAC
multigrade engine oil is recommended.
Recommended oil viscosity (SAE):
5W-30 Preferred
Temperature range anticipated before
next oil change
Fuel Service specifications

’02 SOLARA_U (L/O 0108)
2722002 MY SOLARA_U (OM33545U)
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
6.0 (6.3, 5.2)
Coolant type: “TOYOTA Long Life Coolant” or equiva-
lent
With ethylene− glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage
∗ at 20 C (68 F):
12.6—12.8 V Fully charged
12.2—12.4 V Half charged
11.8—12.0 V Discharged
∗: Voltage that is checked 20 minutes af- ter the key is removed with all the
lights turned off
Charging rates: 5 A max.
CLUTCH
Pedal free play, mm (in.): 5—15 (0.2—0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3 MANUAL TRANSAXLE
Oil capacity, L (qt., Imp. qt.):
2AZ− FE engine 2.5 (2.6, 2.2)
1MZ −FE engine 4.2 (4.2, 3.7)
Oil type: Gear oil API GL −4 or GL −5
Recommended oil viscosity: SAE 75W −90
AUTOMATIC TRANSAXLE
Automatic transmission
Fluid capacity (drain and refill),
L (qt., Imp. qt.): 2AZ− FE engine Up to 3.9 (4.1, 3.4)
1MZ −FE engine Up to 4.75 (5.0, 4.2)
Fluid type:
2AZ− FE engine—
Automatic transmission fluid Type T −IV
Change automatic transmission fluid only
as necessary. Generally, it is necessary to change auto-
matic transmission fluid only if your ve-
hicle is driven under one of the Special
Operating Conditions listed in your “Toyota
Service Booklet” or “Toyota Warranty
Booklet”. When changing the automatic
transmission fluid, use only Toyota Genu-
ine ATF Type T
−IV (ATF JWS3309 or
NWS6500) to aid in assuring optimum
transaxle performance.
Notice: Using automatic transmission
fluid other than Toyota Genuine ATF
Type TIV may cause deterioration in
shift quality, locking up of your trans-
mission accompanied by vibration, and
ultimately damage the automatic trans-
mission of your vehicle.
1MZ −FE engine—
Automatic transmission fluid D −ll or
DEXRON III (DEXRON II)

’02 SOLARA_U (L/O 0108)
2732002 MY SOLARA_U (OM33545U)
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.):
60 (2.4)
Pedal free play, mm (in.): 1—6 (0.04—0.23)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf): 5—8 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III

’02 SOLARA_U (L/O 0108)
2742002 MY SOLARA_U (OM33545U)
Tire size and pressure:
kPa (kgf/cm
2 or bar, psi)
Tire sizeFrontRearWheel size
CoupeP205/65R15 92H200 (2.0, 29)200 (2.0, 29)156JJ
P205/60R16 91H220 (2.2, 32)220 (2.2, 32)16 6JJ
ConvertibleP205/65R15 92H220 (2.2, 32)220 (2.2, 32)15 6JJ
P205/60R16 91H230 (2.3, 33)230 (2.3, 33)16 6JJ
When driving under the above vehicle load conditions at sustained high speeds above 160 km/h (100 mph), in countries where such
speeds are permitted by −law, inflate the front and rear tires to 240 kPa (2.4 kgf/cm2
or bar, 35 psi) provided that it does not exceed the
maximum cold tire pressure molded on the tire sidewall.
Wheel nut torque, N·m (kgf·m, ft·lbf): 103 (10.5, 76)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire pressure” through “Alum inum
wheel precautions” in Section 7 −2.
Tires

’02 SOLARA_U (L/O 0108)
2752002 MY SOLARA_U (OM33545U)
Engine compartment
Engine compartment (vehicles with
daytime running light system and 1MZFE
engine with automatic transmission)
Fuses (type A)
1. A/F HTR 25 A: A/F sensor
2. A/C 10 A: Air conditioning system
3. SPARE 10 A: Spare fuse
4. SPARE 15 A: Spare fuse
5. SPARE 30 A: Spare fuse
6. ALTS 5 A: Charging system
7. HEAD RH(UPR) 20 A: Right−hand
headlight (high beam)
Engine compartment (type A)
8. EFI 15 A (1MZFE engine) or EFI 20 A (2AZFE engine): Multiport fuel in-
jection system/sequential multiport fuel
injection system
9. HORN 10 A: Horn, theft deterrent sys-
tem
10. HAZARD 15 A: Emergency flasher
11. AM2 30 A: Gauge and meter, SRS
airbag system, seat belt pretensioners,
Multiport fuel injection system/sequen-
tial multiport fuel injection system,
“IGN” and “ST” fuses
12. TEL 5 A: No circuit
Fuses

’02 SOLARA_U (L/O 0108)
2762002 MY SOLARA_U (OM33545U)
Engine compartment (type B)
13. HEAD LH(UPR): Left−hand headlight
(high beam)
14. RADIO NO.1 20 A: Audio system
15. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, pers onal
light, trunk light, electric moon roof,
interior light, vanity mirror light, door
courtesy light, power door lock system,
quarter trim courtesy light
16. ECUB 10 A: Cruise control system,
anti −lock brake system, SRS airbag
system, seat belt pretensi oners
Instrument panel
17. DRL NO.2 5 A: Daytime running light
system
18. HLP LH(LWR) 10 A: Left−hand head-
light (low beam)
19. HLP RH(LWR) 10 A: Right−hand
headlight (low beam)
20. SEATHEATER 20 A: Seat heaters
21. HEATER 10 A: Air conditioning system,
rear window defogger, starting system 22. GAUGE 10 A:
Gauges and meters,
back −up lights, cruise control system,
charging system, traction control sys-
tem, daytime running light system,
power windows, service reminder indi-
cators and warning buzzers
23. WIPER 25 A: Windshield wipers and
washer
24. MIRRORHEATER 10 A: Outside rear
view mirror defogger
25. ECUIG 15 A: Cruise control system,
anti −lock brake system, SRS airbag
system, seat belt pretensi oners, theft
deterrent system, shift lock control sys-
tem, traction control system, daytime
running light system, locking with wire-
less remote control system, multiport
fuel injection system/sequential multi-
port fuel injection system
26. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/s equential multiport fuel injec-
tion system
27. STOP 15 A: Stop lights, cruise control
system, high −mounted stoplight, anti −
lock brake system, shift lock control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
