2002 PONTIAC GRAND PRIX Owners Manual

2-61
Automatic Dimming Feature
The automatic dimming feature is turned on or off by
briefly pressing the COMP button located on the bottom
of the mirror face. A light on the mirror will be lit when
the feature is turned on. It will go out when the feature is
turned off.
Temperature Display
The TEMP button located on the bottom of the mirror
face changes the temperature display. You can select
F,

C, or turn the display off.
Compass Operation
Press the COMP button once briefly to turn the compass
on or off. When on, the display will show the compass
direction, with a maximum of two characters. For
example, NE is displayed for north
-east.Compass Calibration
Press and hold the COMP button down for six seconds
to activate the compass calibration mode. If your vehicle
has the optional mirror with the compass, temperature
display and OnStar system, press the on/off button
for nine seconds.
CAL will be displayed in the compass/temperature
window on the mirror.
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or
less until CAL is no longer displayed in the
compass window.

Drive the vehicle on your everyday routine.
(This method may take longer to calibrate).
Compass Variance
Compass variance is the difference between earth's
magnetic north and true geographic north. If not
adjusted to account for compass variance, your compass
could give false readings. The mirror is set to zone eight
upon leaving the factory. It will be necessary to adjust
the compass to compensate for compass variance if you
live outside zone eight. Under certain circumstances,
such as during a long distance cross-country trip, it will
be necessary to adjust for compass variance.

2-62
To adjust for compass variance, do the following:
1. Find your current location and variance zone number
on the map.
2. Press and hold the COMP button for three seconds.
If your vehicle has the optional mirror with the
compass, temperature display and OnStar system,
press the on/off button for six seconds. Release the
button when ªZONEº is displayed. The number
shown is the current zone number.3. Scroll through the zone numbers that appear in the
compass/temperature window on the mirror by
pressing the COMP button or the on/off button. Once
you find your zone number, release the button. After
about four seconds, the mirror will return to the
compass and temperature display, and the new zone
number will be set.
Electrochromic Day/Night Rearview Mirror
with Compass, Temperature Display, and
OnStar

(Option)
Your vehicle may have an automatic-dimming rearview
mirror with a compass and temperature display and the
OnStar system.
When turned on, this mirror functions exactly like the
electrochromic mirror described previously. See
ªMirrors, Electrochromic Rearviewº in the Index for
more information.
The mirror also has an eight
-point compass and
temperature display in the upper right corner on the
mirror face and a three
-button OnStar system.
: The button with this symbol is the on/off button for
the mirror functions such as automatic dimming and
temperature display. It is the far left button located on
the lower part of the mirror face.

2-63
Automatic Dimming Feature
The automatic dimming feature is turned on and off by
pressing the far left button, located on the lower part of
the mirror face, for up to three seconds. A light on the
mirror will be lit when the feature is turned on. It will go
out when the feature is turned off.
Temperature Display
The ON/OFF button located on far left on the bottom of
the mirror face changes the temperature display. You can
select
F,
C, or turn the display off.
Compass Operation
There is a compass display in the window in the upper
right corner of the mirror face. The compass displays a
maximum of two characters. For example, NE is
displayed for north
-east.
The compass may need to be calibrated. See ªCompass
Calibrationº in the Index for more information.
The other three buttons are for the OnStar system.
See your dealer for more information on the system and
how to subscribe to OnStar. See ªOnStar

Systemº in
the Index for more information about the services
OnStar provides.
Power Outside Rearview Mirrors
The power mirror control is
located near the driver's
window, on the armrest.
Turn the control counterclockwise to adjust the left
mirror or clockwise to adjust the right mirror. Then
move the control in the direction you want the
mirror to go.

2-64
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Glove Box
Use your key to lock and unlock the glove box. To open,
lift the right side of the latch.
Overhead Console (If Equipped)
The optional overhead console has reading lamps and
storage compartments (including one for your garage
door opener and one for sunglasses). These features are
explained on the following pages.

2-65
Reading Lamps
To turn either reading lamp on or off, press the switch
next to it.
Garage Door Opener
You can store your garage door opener in the rear
compartment of the overhead console, and operate it
from this position. To install your garage door opener,
follow these instructions:
1. Open the compartment by pressing the latch forward.
Remove the hook and loop patch.
2. Peel the protective backing from the hook and loop
patch and press it firmly to the back of your garage
door opener.
3. Be sure that the button on your garage door opener is
centered above the area with raised lines on the
compartment door. Make sure the button is facing
down and press the opener firmly into place.
4. Add one peg at a time until your garage door opener
operates with the compartment door closed while
pressing the button.Sunglasses Storage Compartment
The sunglasses storage compartment is the second
compartment from the rear on the overhead console.
To open the sunglasses storage compartment, press the
release latch forward and pull the compartment down to
the full open position.
Center Console Storage
To open the armrest storage area, pull up on the front
edge of the latch. The console has cassette and CD
storage and a coinholder.
The center console also contains two cupholders. To
access the cupholders, pull the cupholder door, located
behind the console shift lever. The two cupholders will
pop up into an upright position.
Below the center ashtray is an open storage
compartment. In front of this, you may have a
smaller compartment for storing smaller items.
Rear Armrest Storage (If Equipped)
If you have a trunk access panel, you will also have a
pull down armrest that contains an open storage bin and
two cupholders.

2-66
Trunk Access Panel (If Equipped)
If the vehicle has rear seat armrests, you will also have a
trunk access panel.
This feature allows items in the trunk to pass through
the rear seat. To use the trunk access panel, pull the rear
armrest down, unlock the access panel with the ignition
key and pull it down.
Convenience Net (If Equipped)
The vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, in the net. It can help
keep them from falling over during sharp turns or quick
starts and stops.
The net isn't for larger, heavier loads. Store them in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.

2-67
Ashtray and Cigarette Lighter
The center front ashtray is on the instrument panel. To
open it, pull at the bottom of the ashtray until it is fully
open. To remove the ashtray cup, lift the tabs on the
sides and pull out. On four
-door models an ashtray is
located on each of the rear doors.
NOTICE:
Don't put papers and other things that burn
into the ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.
To use the lighter, located inside the center front ashtray,
push it in all the way and let go. When it's ready, it will
pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
To block out glare, you can swing down the visors.
You can also swing them from front to side.
Visor Vanity Mirrors
Open the cover to expose the vanity mirror. If the
vehicle has the optional lighted vanity mirrors, the
lamps come on when you open the cover.

2-68
Accessory Power Outlet
Your vehicle has a 12-volt outlet which can be used to
plug in electrical equipment such as a cellular telephone,
a compact disc player, etc. It is located on the
passenger's side, near the floor.
Remove the tethered cap to use the outlet. When
not using the outlet, be sure to cover it with the
protective cap.
The accessory power outlet will only operate while the
ignition is on and for a few minutes after turning the
ignition off. If you would like to operate an accessory
for an extended period of time, see your dealer for
more information.
NOTICE:
When using accessory power outlets:

Maximum load of any outlet should not
exceed the fuse rating.

Be sure to turn off electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain the battery.
Certain electrical accessories may not be compatible with the
accessory power outlet and could result in blown vehicle or
adapter fuses. If you experience a problem, see your dealer
for additional information on the accessory power plugs.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
When adding electrical equipment, be sure to follow the
proper installation instructions included with the equipment.
NOTICE:
Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or
accessory bracket from the plug. Improper use of
the power outlet can cause damage not covered
by your warranty.
