2002 PONTIAC GRAND PRIX Owners Manual

2-21
Before your vehicle was shipped from the factory, it was
programmed to Mode 4. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press the LOCK button on the remote keyless
entry transmitter.
3. Count the number of chimes you hear. The number
of chimes tells you which mode the vehicle is set for.
If you do not wish to change the current mode, you
can either exit the programming mode by following
the instructions earlier in this section or program the
next feature available on your vehicle.
4. Press LOCK on the remote keyless entry transmitter
again to change the current mode.
5. Repeat Step 4 until you hear the number of chimes
that matches the number of the mode you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
earlier in this section or program the next feature
available on your vehicle.Content Theft-Deterrent System
(If Equipped)
Your vehicle may be equipped with a content
theft
-deterrent alarm system. Once armed, the system
will go off if someone tries to enter the vehicle without
using the remote keyless entry transmitter or the correct
key, or when someone turns the ignition on with an
incorrect key. The horn will sound, and your vehicle's
headlamps will flash for about two minutes.
Programmable Modes
Mode 1: Not Used
Mode 2: Content Theft On ± If anyone tampers with the
trunk lock or opens a door while the content
theft
-deterrent system is armed, an alarm will sound and
the headlamps will flash for up to two minutes.
Mode 3: Content Theft Off ± The content
theft
-deterrent system is always disarmed.
Mode 4: Not Used

2-22
Before your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Turn the parking lamps on, then off.
3. Count the number of chimes you hear. The number
of chimes tells you which mode the vehicle is set for.
If you do not wish to change the current mode, you
can either exit the programming mode by following
the instructions earlier in this section or program the
next feature available on your vehicle.
4. Turn the parking lamps on, then off again to change
the current mode.
5. Repeat Step 4 until you hear the number of chimes
that matches the number of the mode you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
earlier in this section or program the next feature
available on your vehicle.Arming and Disarming the Content
Theft-Deterrent System (If Equipped)
To arm and disarm the content theft-deterrent system,
the system must be turned on by using Mode 2 listed
previously in this section under ªContent
Theft
-Deterrent System.º
With the arming and disarming feature, you can do
the following:

Arm the system when you lock the doors using either
power door lock switch while any door is open and
the key is removed from the ignition.

Arm the system when you lock the doors with your
remote keyless entry transmitter and the key is
removed form the ignition.

Disarm the system when you unlock the doors with
your key or remote keyless entry transmitter.

2-23
Programmable Modes
Mode 1: Power Door Lock Switch Arming Off

The content theft
-deterrent system will arm when
you lock the doors with the remote keyless entry
transmitter. The key must be removed from the
ignition when you lock the doors or the content
theft
-deterrent system will not arm.

The content theft
-deterrent system will disarm when
you unlock the doors with the keys or the remote
keyless entry transmitter.
Mode 2: Remote Keyless Entry Transmitter
Arm/Disarm Only

The content theft
-deterrent system will arm when
you lock the doors with the remote keyless entry
transmitter. The key must be removed from the
ignition when you lock the doors or the content
theft
-deterrent system will not arm.

The content theft
-deterrent system will disarm
when you unlock the doors with the remote keyless
entry transmitter.While this mode provides increased security, it can be a
problem if the remote keyless entry transmitter is
damaged, lost or if it fails to operate for any reason
while the content theft
-deterrent system is armed. The
content theft
-deterrent system must be disarmed for the
engine to run and while in Mode 2, the key can no
longer disarm the system.
If your vehicle is equipped with the OnStar
 system,
OnStar will not be able to remotely unlock your vehicle
if it has been programmed to Mode 2.
Mode 3: Standard Arming and Disarming

The content theft
-deterrent system will arm when
you lock the doors using either power door lock
switch while any door is open and the key is
removed from the ignition.

The content theft
-deterrent system will arm when
you lock the doors with your remote keyless entry
transmitter. The key must be removed from the
ignition when you lock the doors or the content
theft
-deterrent system will not arm.

The content theft
-deterrent system will disarm when
you unlock the doors with the key or the remote
keyless entry transmitter.

2-24
Before your vehicle was shipped from the factory, it was
programmed to Mode 1. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Insert a second ignition key fully into any door key
cylinder and turn it to the unlock position.
This step is necessary to prevent accidental
programming of this feature to Mode 2. Do not
program this feature to Mode 2 without first reading
the note contained in the description for that mode.
The door key lock cylinder must remain in the
unlock position during Steps 2 through 4.
3. Press the horn symbol on the remote keyless
entry transmitter.4. Count the number of chimes you hear. The number
of chimes tells you which mode the vehicle is set for.
If you do not wish to change the current mode, you
can either exit the programming mode by following
the instructions earlier in this section or program the
next feature available on your vehicle.
5. Press the horn symbol on the remote keyless entry
transmitter again to change the current mode.
6. Repeat Step 5 until you hear the number of chimes
that matches the mode you want.
7. Remove the key from the door key cylinder.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
earlier in this section or program the next feature
available on your vehicle.

2-25
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk open or if
electrical wiring or other cable connections must
pass through the seal between the body and
the trunk:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on VENT. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock
To unlock the trunk from the outside, insert the key and
turn it clockwise. You can also press the trunk symbol
on the remote keyless entry transmitter (if equipped).
Remote Trunk Release
This feature is used to unlock the trunk from inside
the vehicle.
Press the TRUNK button
located behind the glove
box door.
The shift lever must be in PARK (P) for the remote
trunk release button to work.

2-26
Trunk Release Handle
NOTICE:
The trunk release handle was not designed to be
used to tie down the trunk lid or as an anchor
point when securing items in the trunk. Improper
use of the trunk release handle could damage it.
There is a glow-in-the-dark trunk release handle located
inside the trunk on the latch. This handle will glow
following exposure to light. Pull the release handle to
open the trunk from the inside.
Trap-Resistant Trunk Kit
To help prevent a child from becoming trapped in your
trunk, you can order a trap
-resistant trunk kit from your
dealer. This kit includes:

a modified trunk latch,

a lighted release handle, and

seatback tethers (for vehicles with folding
rear seatbacks).
See your dealer for additional information.

2-27
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your trunk
or glove box.

Be sure to close and lock the storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

If your vehicle has a remote keyless entry system,
take the transmitter with you.

2-28
Content Theft-Deterrent
(If Equipped)
The vehicle may have a theft-deterrent alarm system.
A red light located on top of the instrument panel
(toward the center of the vehicle, near the windshield)
will flash slowly when the system is armed.While armed, the doors will not unlock with the power
door lock switch. The alarm will sound if someone
tampers with the trunk lock, enters the vehicle (without
using the remote keyless entry transmitter or key to
unlock the doors), or turns the ignition on. The horn will
sound and the headlamps will flash for up to two
minutes. The system will also cut off the fuel supply,
preventing the vehicle from being driven.
Arming with the Power Lock Switch
Your alarm system can be programmed to arm when you
use either power lock switch to lock the doors while any
door is open and the key is removed from the ignition.
If you would like to arm the system with the power lock
switch see ªMultifunction Alarm Locks and Lighting
Choicesº in the Index. When programmed, the red light
will flash quickly to let you know that the system is
ready to arm with the power lock switches. When you
press the rear of a power door lock switch, the red light
will stop flashing and stay on to let you know that the
system is arming. After all the doors are closed and
locked, the red light will begin flashing at a very slow
rate to let you know the system is armed.
