2002 PONTIAC GRAND PRIX Owners Manual

2-69
Auxiliary Power Connection
(Power Drop)
The vehicle is equipped with an auxiliary power
connection. This feature provides power ground and
accessing wires which can be used to add aftermarket
electrical equipment to the vehicle. The connection is
located on the passenger's side of the vehicle, below the
glove box on the right side of the console.
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a one touch
hands
-free communication link between you and the
OnStar Center. To receive OnStar services, a service
subscription agreement is required and an additional
fee may be required. Services are available 24 hours
a day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
(OnStar Services Button): Press this button once
to contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Communication button to cancel the
automatic redial.
(Emergency Button): In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.

2-70
(Communication Button): Press this button
at the end of a call. Also press this button to answer a
call from the center, or cancel a call if one of the other
buttons is accidentally pressed. This button is also
used to access OnStar Personal Calling and Virtual
Advisor services. See the OnStar owner package for
more information.
Volume Control:You can control the volume of the
OnStar system using either the volume knob on the
radio or if equipped, the steering wheel volume controls.
(Telltale Light): This light will indicate the status of
the system. A solid green light will come on when you
start the vehicle to let you know that the system is on
and is ready to make or receive calls.
If the light blinks green it means that an incoming or
outgoing call is in progress. Press the Communications
button if you notice the light blinking and you are not
on a call.
The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar Services
button to attempt to contact an advisor. If the connection
is made, the advisor will assist you with steps to take to
make sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
OnStar Services
The following services are available within OnStar
service plans. Your vehicle comes with a specific
one
-year service plan that allows use of some or all
of the following services.

Automatic Notification of Air Bag
Deployment: If an air bag deploys, a priority
emergency signal is automatically sent to the center.
An advisor will locate your vehicle's position, try to
contact you and assist you in the situation. If the
center is unable to contact you, an emergency service
provider will be contacted.

Stolen Vehicle Tracking: Call the center at
1
-888-4-ONSTAR (1-888-466-7827) to report your
vehicle stolen. The system can then attempt to locate
and track your vehicle and the advisor will assist the
proper authorities.

Roadside Assistance with Location: For vehicle
breakdowns, press the OnStar Services button. An
advisor will contact the appropriate help.

2-71

Remote Diagnostics: If an instrument panel
light comes on, press the OnStar Services button.
An advisor can perform a check of the engine
on
-board computer and recommend what action
needs to be taken.

OnStar MED
-NET: Med-Net can store your
personal medical history and provide it to emergency
personnel if necessary. (Requires activation and
additional fee).

Accident Assist: An advisor can provide
step
-by-step guidance following an accident.

Remote Door Unlock:To contact the center, call
1
-888-4-ONSTAR. You will be required to provide
your security information. An advisor will send a
command to your vehicle to unlock itself. The
advisor can delay unlocking your vehicle. Remote
Door Unlock is disabled 48 hours after the vehicle is
parked to maintain the battery charge.
Vehicle Locator Service: To contact the center, call
1
-888-4-ONSTAR. You will be required to provide
your security information. An advisor will send a
command to your vehicle to sound the horn and/or
flash the lamps.

Route Support: An advisor can provide directions
or guidance to most places you want to go. In
addition, they can help you locate gas stations,
rest areas, ATMs, hospitals, hotels, stores, eateries
and more.

Ride Assist: An advisor can locate transportation in
the event that you are unable to drive.

Concierge Services: The concierge advisor can
obtain tickets, reservations, or help with vacation/trip
planning and other unique items and services.

2-72
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement.
In order to provide you with excellent service, calls with
the OnStar Center may be monitored or recorded.
OnStar Service is:

available in the 48 contiguous United States, Alaska,
Hawaii and Canada;

available when the vehicle is within the operating
range of a cellular provider;

subject to limitations caused by atmospheric
conditions, such as severe weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.Global positioning locating capabilities will not be
available if satellite signals are obstructed.
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative if
the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
OnStar is the communications link between you and
existing governmental emergency and roadside service
providers. OnStar will receive your call and use
reasonable effort to contact an appropriate provider.
OnStar cannot promise that the providers will respond in
a timely manner or at all.
Purse or Litter Bag Holder
On the front of the center console, to the right of the
accessory power outlet, there is a hook that can be used
to hold a purse or litter bag.

2-73
Power Sunroof (Option)
Base Version ShownThe sunroof includes a sliding glass panel and a
one
-piece sunshade. The switch to control the sunroof is
located in the headliner on the roof panel. The switch
works only when the ignition is on or RAP is active.
See ªRetained Accessory Power (RAP)º in the Index.
Push the rear of the switch once and the sunroof will
open to the vent position only. You will need to open the
sunshade by hand.
Push the rear of the switch a second time and the
sunroof will open the remainder of the way by itself.
This is the express
-open feature.
To close the sunroof, push and hold the front of the
switch until the sunroof motor stops. The sunshade must
be closed by hand.

2-74
The Instrument Panel -- Your Information System

2-75
The main components of the instrument panel are the following:
A. Side Window Defogger Vents
B. Fog Lamp Switch
C. Multifunction Lever
D. Instrument Panel Cluster
E. Hazard Warning Button
F. Horn
G. Trip Computer (If Equipped) and/or Driver
Information Center (DIC)
H. Instrument Panel Vents
I. Interior Lamps ControlJ. Exterior Lamps Control
K. Tilt Steering Wheel Control
L. Audio Steering Controls (If Equipped)
M. Head Up Display (HUD) Controls (Option)
N. Comfort Controls
O. Ashtray and Cigarette Lighter
P. Audio System
Q. Glove Box
R. Instrument Panel Fuse Block

2-76
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know
how fast you're going, about how much fuel is in your tank and many other things you need to drive safely
and economically.
United States Version Shown, Canada Similar
