3-38
Playing a Specific Loaded Compact Disc
For every CD loaded, a number will appear on the radio
display. To play a specific CD, first press the CD AUX
button to start playing a CD. Then press the numbered
pushbutton that corresponds to the CD you want to play.
A small bar will appear under the CD number that is
playing, and the track number will appear.
If an error appears on the radio display, see ªCompact
Disc Messagesº later in this section.
LOAD CD
(Eject): The CD eject side of this button
will eject a disc or discs, if you have multiple discs
loaded. To eject a disc or discs from the disc player,
perform one of the following steps:

Press and release the CD eject side of the LOAD CD
button to eject the disc that is currently playing, or

to eject all of the discs, press the CD eject side of the
LOAD CD button for two seconds, you will hear a
beep, and the light will flash to let you know when a
disc is being ejected.
When the CD eject side of the LOAD CD button is
pressed, the receiver will eject the disc and REMOVE
CD will be displayed. You can now remove the disc. If
the disc is not removed, after 25 seconds, the disc will
be automatically pulled back into the receiver.If you try to push the disc back into the receiver, before
the 25 second time period is complete, the receiver will
sense an error and will try to eject the disc several times
before stopping.
Do not repeatedly press the CD eject side of the LOAD
CD eject button to eject a disc after you have tried to
push it in manually. The receivers 25
-second eject timer
will reset at each press of eject, which will cause the
receiver to not eject the disc until the 25
-second time
period has elapsed.
Once the player stops and the disc is ejected, remove
the disc. After removing the disc, press the PWR
knob off and then on again. This will clear the
disc
-sensing feature and enable discs to be loaded
into the player again.

REV (Reverse): Press and hold this button to reverse
quickly within a track. You will hear sound at a reduced
volume. Release it to play the passage. The display will
show elapsed time.
FWD  (Forward): Press and hold this button to
advance quickly within a track. You will hear sound at a
reduced volume. Release it to play the passage. The
display will show elapsed time.

3-39
RPT (Repeat): With repeat, you can repeat one track or
an entire disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and hold
the RPT button for two seconds. RPT will appear on
the display. Press RPT again to turn if off.
RDM (Random): With random, you can listen to the
tracks in random, rather than sequential order, on one
disc or on all of the discs. To use random, do one of the
following:

To play the tracks on the disc you are listening to in
random order, press and hold RDM for more than
two seconds. You will hear a beep and RANDOM
ONE will appear on the display. Press RDM again to
turn if off.

Press and release the RDM button to play the tracks
on all of the discs that are loaded, in random order.
RANDOM ALL will appear on the display. Press
RDM to turn it off.AUTO EQ (Automatic Equalization): Press AUTO
EQ to select the desired preset equalization setting while
playing a compact disc. The equalization will be
automatically set whenever you play a compact disc.
See ªAUTO EQº listed previously for more information.


SEEK : To seek, press the left arrow while
playing a CD to go to the start of the current track, if
more than ten seconds have passed. Press the right arrow
to go to the next track. If you press the button more than
once, the player will continue moving backward or
forward through the disc.


SCAN : To scan one disc, press and hold
either SCAN arrow for more than two seconds until
SCAN appears on the display and you hear a beep.
Use this feature to listen to each track of the currently
selected disc for ten seconds. The sound will mute while
scanning. SCAN will appear on the display. Press
either SCAN arrow again, to stop scanning.
To scan all loaded discs, press and hold either SCAN
arrow for more than four seconds until DISC SCAN
appears on the display and you hear a beep. Use this
feature to listen to the first track, for ten seconds for
each disc loaded. The sound will mute while scanning to
the next track. DISC SCAN will appear on the display.
Press either SCAN arrow again, to stop scanning.

3-40
P-TYPE (Program Type): Press this knob to see how
long the current track has been playing. To change what
is normally shown on the display (track or elapsed
time), press the knob until you see the display you
want, then hold the knob until the display flashes.
AM FM: Press this button to play the radio when a
disc(s) is in the player.
Using Song List Mode
The integrated six
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into the song list feature, perform the
following steps:
1. Turn the disc player on and load it with at least one
disc. See ªLOAD CDº listed previously in this
section for more information.
2. Check to see that the disc changer is not in song list
mode. S
-LIST should not appear in the display. If
S
-LIST is present, press the SONG LIST button
to turn it off.3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK SCAN right
arrow button to locate the track that you want to
save. The track will begin to play.
4. Press and hold the SONG LIST button for two or
more seconds to save the track into memory. When
SONG LIST is pressed a beep will be heard
immediately. After two seconds of pressing SONG
LIST continuously, two beeps will sound to confirm
that the track has been saved.
5. Repeat Steps 3 and 4 for saving other selections.
If you attempt to save more than 20 selections, S
-LIST
FULL will appear on the display.
To play the song list, press the SONG LIST button.
One beep will be heard and S
-LIST will appear on the
display. The recorded tracks will begin to play in the
order that they were saved.
You may seek through the song list by using the SEEK
SCAN arrows. Seeking past the last saved track will
return you to the first saved track.

3-41
To delete tracks from the song list, perform the
following steps:
1. Turn the disc player on.
2. Press the SONG LIST button to turn song list on.
S
-LIST will appear on the display.
3. Press the SEEK SCAN arrows to select the desired
track to be deleted.
4. Press and hold the SONG LIST button for two
seconds. When pressing SONG LIST, one beep will
be heard immediately. After two seconds of pressing
the SONG LIST button continuously, two beeps will
be heard to confirm that the track has been deleted.
After a track has been deleted, the remaining tracks are
moved up the list. When another track is added to the
song list, the tracks will be added to the end of the list.
To delete the entire song list, perform the following steps:
1. Turn the disc player on.
2. Press the SONG LIST button to turn song list on.
S
-LIST will appear on the display.
3. Press and hold the SONG LIST button for more than
four seconds. A beep will be heard, followed by two
beeps after two seconds and a final beep will be
heard after four seconds. S
-LIST EMPTY will
appear on the display indicating that the song list has
been deleted.If a disc is ejected, and the song list contains saved
tracks from that disc, those tracks are automatically
deleted from the song list. Any tracks saved to the
song list again are added to the bottom of the list.
To end song list mode, press the SONG LIST button.
One beep will be heard and S
-LIST will be removed
from the display.
Compact Disc Messages
CHECK CD: If this message appears on the radio
display, it could be due to of the following reasons:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If the CD is not playing correctly, for any other reason,
try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error message, write it down and provide it to your
dealer when reporting the problem.

3-42
Entertainment System (Option)
Your vehicle may have an optional Digital Video Disc
(DVD) entertainment system. The entertainment system
works with the vehicle's audio system and includes a
DVD player, a video display screen, headphones and a
remote control. The entertainment system also integrates
the rear climate control and rear seat audio functions.
Before You Drive
The video entertainment system is for passengers in the
second and third row seats only. The driver cannot
safely view the video screen while driving and should
not try to do so.
In severe or extreme weather conditions your
entertainment system will shut down until the
temperature is within the operating range. This
protection feature will keep your video components
from being damaged while the temperature is below
-4
F (-20
C) or above 140
F (60
C). To resume
operation, shut off the entertainment system, pull down
the video screen and then heat or cool the vehicle until
the temperature is within the operating range.
Headphones
The entertainment
system includes four
dual channel, wireless
headphones. The
headphones have an
ON/OFF switch, a
channel A/B switch
and a volume control.
To use the headphones turn the switch located on the left
side to ON. An indicator light located on the right side
will illuminate. If the light does not illuminate, the
batteries may need to be replaced. See ªBattery
Replacementº later in this section for more information.
Switch the headphones to OFF when not in use.
If you move too far forward, step out of the vehicle or
break the ªline of sightº between the headphones and
the display above the video screen, the sound in the
headphones will be degraded or will cut out entirely. If the
system is shut off, or the headphones are out of the ªline
of sightº for more than three minutes, the headphones will
shut off automatically to preserve battery life.

3-43
If the channel switch located on the right side is on A,
the headphones will play the DVD or auxiliary device.
See ªStereo RCA Jacksº later in this section for
more information. If the channel switch is on B, the
headphones will play the rear seat audio system. See
ªRear Seat Audio (Vehicles with the Entertainment
System)º in the Index for more information.
To adjust the volume on the headphones, use the volume
control located on the right side.
NOTICE:
Do not store the headphones in heat or direct
sunlight. This could damage the headphones and
would not be covered by your warranty. Keep the
headphones stored in a cool place.
Battery Replacement
To change the batteries, do the following:
1. Slide open the battery door located on the left side of
the headphones.2. Remove the batteries from the compartment.
3. Replace the two AAA batteries. Make sure that they
are installed correctly.
If the headphones are to be stored for a long period
of time, remove the batteries and keep them in a cool,
dry place.
Stereo RCA Jacks
The RCA jacks are located on the faceplate of the DVD
player. They allow you to hook up an auxiliary device
such as a camcorder or a video game unit. You may
require adapter connectors or cables to connect your
auxiliary device to the RCA jacks. Refer to the
manufacturer's instructions for proper usage.
The entertainment system will always start in the
auxiliary mode. To use the auxiliary function, connect a
camcorder or a video game unit to the RCA jacks and
turn on the auxiliary device. If you want to view a DVD,
insert the DVD into the DVD player. The system will
automatically switch to DVD and start to play. To return
to the auxiliary device, press the stop button to stop the
DVD or use the remote control. See ªRemote Controlº
later in this section for more information.

3-44 Audio Speakers
Only one audio source can be heard through the
speakers at one time.
Audio from the radio, cassette or CD player will be
heard through all speakers when the front audio system
is being used and the rear seat audio system is off.
Sound from the DVD player or an auxiliary device can
be heard through all speakers when the front audio
system and rear seat audio are off and a DVD or
auxiliary device is playing.
When the front audio system is on, to hear the DVD,
auxiliary device or the rear seat audio system you must
use the headphones. With the rear seat audio system on,
the speaker in the overhead console and the rear
speakers are muted.
The speaker in the overhead console is set at a low level
and is not intended to be heard at a high volume.
Video Screen
The video screen is located in the overhead console.
To use the video screen, do the following:
1. Push forward on the release button and the screen
will fold down.
2. Pull the screen toward you and adjust its position
as desired.

3-45
When the video screen is not in use, push it up into its
locked position.
If a DVD is playing and the screen is raised to its
locked position, the screen will shut off, but the DVD
will continue to play through the previously selected
audio source.
NOTICE:
Avoid directly touching the video screen, as
damage may occur. Do not touch the video
screen. See ªCleaning the Video Screenº in
the Index for more information.
DVD Player
The DVD player is located in the front floor console.
The DVD player can be controlled by the buttons on the
DVD player and by the buttons on the remote control.
See ªRemote Controlº later in this section for more
information.
The DVD player works while the ignition is in RUN
or ACCESSORY and while RAP is active. See
ªRetained Accessory Power (RAP)º in the Index
for more information.
