AUDIO
204If no messages have been stored, or if there are no more
messages to be recalled, ºNO MSG STOREDº will appear on
the display, and the message display will be canceled. The
display then returns to show the program service name. The
message display will be canceled if you activate any function
that affects the display.
Message display can be canceled by pressing any of the
following buttons:
ºAMº, ºFMº, ºCDº, ºTAPEº, ºLOADº, ºSEEKº, ºTUNEº, any
preset, º
SCANº, any audio control, ºRDSº, or ºº. If the
current station is not a traffic program and traffic
announcements is off, pushing ºTRAFº will cancel the display.
The message will be canceled after the entire message has
been displayed.
(g) ºALERTº display
The alert program type sends emergency alert messages. The
radio will receive alert messages if it is on and tuned to an RDS
station, or if the previous station was an RDS station. If the
radio receives an alert announcement, it will interrupt the
previous mode, display ºALERTº .
Cassette tape player operation
(a) Playing a cassette tape
SV22058
When you insert a cassette tape, the exposed tape should
face to the right.
The player will automatically start when you insert a cassette
tape. At this time, ºPLAYº appears on the display.
If a metal or chrome equivalent cassette tape is put in the
cassette player, the player will automatically adapt to it and
ºMTLº appears on the display.
To stop or eject the cassette tape, push the ºEJECTº button.
Auto±reverse feature: After the cassette player reaches the
end of a tape, it automatically reverses and begins to play the
other side, regardless of whether the cassette was playing or
fast forwarding.

AUDIO
205
SV22059
If a cassette is already in the slot, push the ºTAPEº button.
DolbyB Noise Reduction* feature: If you are listening
to a tape that was recorded with Dolby  B Noise Reduction,push the button marked with the double±D symbol. The
double±D symbol will appear on the display. Push the button
again to turn off Dolby  B NR.
The Dolby NR mode reduces tape noise by about 10 dB. For
best sound reproduction, play your tapes with this button on or
off according to the mode used for recording the tape.
To play a tape recorded without Dolby NR, push the button until
the symbol disappears from the display.
*: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. ºDOLBYº and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation. (b) Manual program selection
SV22060
ºProgramº button:
Push the º
º button to select the
other side of a cassette tape. The display indicates which side
is currently selected (  indicates top side,  indicates bottom
side).
ºRewindº button: Push the º º button to rewind a tape.
ºREWº appears on the display.
To stop rewinding, push the same button or ºTAPEº button.
ºFast forwardº button: Push the º

º button to fast forward
a cassette tape. ºFFº appears on the display.
To stop fast forwarding, push the same button or ºTAPEº
button.

AUDIO
206(c) Automatic program selection
SV22061
ºRPTº button: The repeat feature automatically replays the
current program.
Push the º
RPTº button while the program is playing. When the
program ends, it will automatically be rewound and replayed.
Push the button again to turn off the repeat feature.
There must be at least 5 seconds of blank space between
programs for the repeat feature to work correctly.
ºSKIPº button: The skip feature allows you to fast forward
past long stretches of blank tape. This is especially useful at
the end of cassettes.
Push the ºSKIPº button. The player will automatically skip any
blank portions of 15 seconds or more and play the next
program. To cancel it, push the button once again.
SV22018
ºAutomatic program selectionº button: The automatic
program selection feature allows you to program your cassette
player to skip forward or backward to locate the song you want
to hear. You can skip up to nine programs at a time.
Push this button on the upper side to skip forward. ºFFº and
the number will appear on the display. Push the button until the
number you want to skip appears on the display. After that, the
player will automatically skip forward.
When the end of the tape is reached, the player automatically
reverses sides and resumes normal play.

AUDIO
207
Push
this button on the lower side to skip backward. Push the
button until ºREWº and the number you want to skip appear on
the display.
 If you set ºREW 1º, the player will rewind to the beginning
of the current program.
 When counting the number of programs you want to rewind,
remember to count the current program as well. For
example, if you want to rewind to a song that is two before
the song you are listening to, push this button until ºREW
3º appears on the display.
When the beginning of the tape is reached, the player
automatically resumes normal play.
There must be at least 5 seconds of blank space between
programs for this feature to work correctly.
ºRPTº, ºSKIPº or ºAutomatic program selectionº
features: These features may not work well with some spoken
word, live or classical recordings.
Compact disc player operation
(a) Inserting or ejecting compact discs
The ignition switch must be in the ºACCº or ºONº position.
Your automatic changer can store up to 6 discs.
Ty p e A
SV22062
 Setting a single compact disc:
1. Push the ºLOADº button briefly.
You can set a disc at the lowest empty disc number.
2. When the amber indicators of the slot start blinking, the
ºWAIT DISCº appears on the display. After the indicators
blinking amber change to the green and stay on, the
ºWAIT DISCº changes to the ºLOAD DISCº on the display.
While the green indicators stay on, insert only one disc.
If you need to insert the next disc, repeat the same
procedure to insert another disc.
After insertion, the set disc is automatically loaded.

AUDIO
208If the label faces down, the disc cannot be played. In this case,
ºERROR1º and disc number appear on the display.

Setting all the discs:
1. Push the ºLOADº button until you hear a beep.
2. When the amber indicators of the slot start blinking, the
ºWAIT DISCº appears on the display. After the indicators
blinking amber change to the green and stay on, the
ºWAIT DISCº changes to the ºLOAD DISCº on the display.
While the green indicators stay on, insert only one disc.
After inserting the disc, the amber indicators of the slot
start blinking and the ºWAIT DISCº appears on the display
again. After the ºWAIT DISCº changes to the ºLOAD
DISCº, you can insert the next disc. Repeat this procedure
until you insert all the discs.
To cancel the operation, push the ºLOADº or ºDISCº button.
If you do not insert the discs within 15 seconds after pushing
the ºLOADº button and ºLOADº is displayed, the operation will
be canceled automatically.
NOTICE
Do not insert one disc stacked on top of another one or feed them in continuously, to prevent discs from getting
stuck in the player.
SV22063
 Ejecting a single disc:
1. Push the button under the ºDISC º or ºDISC
º
signal on the display to display the disc number you want
to eject.
2. Push the ºEJECTº button briefly.
At this time, the display shows ºEJECTº, and the indicators at
both ends of the slot as well as the disc number light up.
 Ejecting all the discs:
Push the ºEJECTº button until you hear a beep.
However, if you accidentally pushed the ºEJECTº button, push
the ºDISCº or ºLOADº button to insert the disc again.
Do not push in the disc which is being ejected forcibly.

AUDIO
209
Ty p e B
SV22046
When
you insert a compact disc, lightly push it in with the
label side up.
The disc player will grab the disc and slide it into place to play
it from the track 1 program.
As this is done, ºCDº appears on the display. Also, the track
number and elapsed playback time will appear on the display.
SV22047
To eject the compact disc, push the ºEJECTº button.

AUDIO
210(b) Playing a compact disc
SV22064
Push the ºDISCº button if the discs are already loaded in
the player.
The discs set in the player are played continuously, starting
with disc number 1. The disc number of the disc currently
being played, the track number and the time from the
beginning of the program appear on the display.
When
play of one disc ends, the first track of the following disc
starts. When play of the final disc ends, play of the first disc
starts again.
The player will skip any empty disc trays. (c) Selecting a desired disc (type A only)
SV22034
Push the ºDISC º or ºDISC º button to select the disc
number.
Push the button several times until the desired disc number
appears on the display. When you release the button, the
player will start playing the selected disc from the first track.

AUDIO
211
(d) Searching for a desired track
SV22023
Push the ºSCANº button briefly.
ºSCANº will appear on the display. The compact disc player
will play the next track for 10 seconds, then scan again. To
select a track, push the ºSCANº button a second time. If the
player reaches the end of the disc, it will continue scanning at
track 1.
After all the tracks are scanned in one pass, normal play
resumes.
(e) Searching for a desired disc (type A only)
SV22024
Push the ºSCANº button until you hear a beep.
With ºD
SCANº on the display, the program at the beginning
of each disc will be played for 10 seconds. To continue
listening to the program of your choice, push the ºSCANº
button a second time.
After all the discs in the player are scanned in one pass, the
scan function is cancelled.
