2002 Lexus IS300 Gauges, Meters And Service Reminder Indicators / LEXUS 2002 IS300 WAGON OWNER'S MANUAL (OM53423U)

COMFORT ADJUSTMENT
164
SV16154

1Lock
10. Replace the luggage cover and slide the knob while
pushing the button, then securely lock the luggage cover.
SV16121

Side seat position
6. Remove the head restraint.

COMFORT ADJUSTMENT
165
SV16161

1Unlock
7. While pushing the button, slide the knob, then release
the lock on both sides and remove the luggage cover.
SV16120
8. Fix the child restraint system with the seat belt.
9. Latch the hook onto the anchor bracket and tighten the
top strap.
For instructions to install the child restraint system, see ºT ypes
of child restraint systemº on page 137.
CAUTION
 Make sure the top strap is securely latched, and
check that the child restraint system is secure by
pushing and pulling it in different directions.
 Follow all the installation instructions provided by its
manufacturer.

COMFORT ADJUSTMENT
166
SV16155

1Lock
10. Replace the luggage cover and slide the knob while
pushing the button, then securely lock the luggage cover.
SV16145
11. Replace the head restraint.

COMFORT ADJUSTMENT
167
Installation with child restraint lower
anchorages
SV16117
The lower anchorages for the child restraint system
interfaced with the FMVSS225 specification are installed
in the rear seat.
The anchorages are installed in the clearance between the
seat cushion and seatback of both outside rear seats.
Child restraint system interfaced with the FMVSS225
specification can be fixed with these anchorages. In this case,
it is not necessary to fix the child restraint system with a seat
belt on the vehicle.
SV16134

Type A

COMFORT ADJUSTMENT
168
SV16135

Type B
CHILD RESTRAINT SYSTEM INSTALLATION
Type A:
1. Widen the clearance at the lower seatback and confirm
the position of the lower anchorages below the tag in the
seatback.
2. Latch the hooks of lower straps onto the anchorages
and tighten the lower straps.
Type B:
1. Widen the clearance at the lower seatback and confirm
the position of the lower anchorages below the tag in the
seatback.
2. Latch the buckles onto the anchorages.
If your child restraint system has a top strap, it should be
anchored. (For the installation of the top strap, see ºUsing a top
strapº on page 154.)
For the installation details, refer to the instruction manual
equipped with each product.

COMFORT ADJUSTMENT
169
CAUTION
When using the lower anchorages for the child
restraint system, be sure that there are no irregular
objects around the anchorages or that the seat belt is
not caught.
 Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its
manufacturer.
 Do not put a child restraint system on the rear seat if
it interferes with the lock mechanism of the front
seats. This can cause severe injury to the child and
front passenger in case of sudden braking or a
collision.

COMFORT ADJUSTMENT
170

SECTION 1 ± 7
171
INSTRUMENTS AND CONTROLS
Theft deterrent
Theft deterrent system172
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
