INTERIOR EQUIPMENT
68
WARNING REFLECTOR HOLDER
Sedan
SS14092

1To loosen 2To tighten
This belt is designed to hold the warning reflector.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Although the warning reflector itself is not included as an
original equipment, this belt can be used to store the warning
reflector.
Make sure the warning reflector is securely held.
SportCross
SV14040
The warning reflector is in the auxiliary box.
Although the warning reflector itself is not included as an
original equipment, this auxiliary box can be used to store the
warning reflector.

INTERIOR EQUIPMENT
69
TIE±DOWN HOOKS
SV14003

Sedan
SV14024

SportCross
To secure your luggage, use the tie±down hooks as
shown above.See ºLuggage stowage precautionsº on page 77 for
precautions to observe for loading luggage.
CAUTION
To avoid personal injury, keep the tie±down hooks
stored under the carpet when not in use.

INTERIOR EQUIPMENT
70
LUGGAGE COVER
SV14033

Front luggage cover
SV14044

Rear luggage cover
To use the luggage cover:
1Pull out the front luggage cover and hook it on the
anchors.
2Hang the rear luggage cover onto the anchors of the
back door, then install the clips on both sides.
CAUTION
Do not place anything on the luggage cover. Such items
may be thrown about and possibly injure people in the
vehicle during sudden braking or an accident.

INTERIOR EQUIPMENT
71
SV16158

1Removal 2InstallationSV14043
To remove the luggage cover:
1While pushing the button, slide the knob and release
the lock on both sides.
2Hold up the luggage cover.

INTERIOR EQUIPMENT
72After
you remove the luggage cover, place it somewhere other
than the passenger compartment. This will prevent
passengers from injury in the event of a sudden stop or
accident.
CAUTION
When installing the luggage cover, while pushing the
button, slide the knob and securely lock the luggage
cover. Otherwise, breaking away and falling of the
cover may cause serious injury at a collision.
IN ORDER TO EXPAND THE LUGGAGE SPACE
If you want to have the wider luggage space, you are able to
widen the space by lowering the deck board.
SV41029
1. Pull up the deck board.

INTERIOR EQUIPMENT
73
SV41030
2. Take off the hook at the rear of the deck board.
3. Lift up the back side of the board and secure the board
by hooking it at the top of the back door opening with the
hook at the edge of the strap.
Make sure the board is secured and does not fall down.
SV14036
4. Fold the legs of the center deck board

INTERIOR EQUIPMENT
74
SV14022
5. Remove the lock pins fixed on both sides of the center
deck board in the order shown above, and lower the center
deck board to the lowest position. Then fix the lock pin.
SV14037
6. Fold up the legs of the deck board on both sides.
7. Lower the center deck board.

INTERIOR EQUIPMENT
75
SV14046
NOTICE
Be sure to use the deck board by making its heighteven. Otherwise, luggage may slip down and hit thedeck board, thus resulting in break and damage.
Be sure to check that there is nothing under the deckboard before lowering it. Any object under the deckboard may cause damage to that thing or the deckboard itself.
FLOOR MAT
SV14038
Use a floor mat of the correct size.
If the floor carpet and floor mat have a hole, then it is designed
for use with a locking clip. Fix the floor mat with locking clip into
the hole in the floor carpet.
