STARTING AND DRIVING
228
SS31019

1Power position 2Normal position
3Snow position
2. Set the driving pattern selector switch to the ºNormalº
position.
Your transmission has a driving pattern selector switch which
allows you to select ºPowerº, ºNormalº or ºSnowº mode \
to suit
your driving condition. For ordinary driving, Lexus
recommends that you use the ºNormalº position to improve fuel
economy.
3. For more powerful acceleration and sporty driving, use
the ºPowerº position.
In the ºPowerº position, the ºECT PWRº light in the instrument\
cluster is on and the transmission is shifted up at higher vehicle
speeds and shifted down more responsively than in the
ºNormalº position.
For ºSnowº mode, see ºElectronic Throttle Control
Systemº on page 246.
SV31022

1Brake pedal 2ºDº (Drive) position
4. With your foot holding down the brake pedal, shift the
selector lever to ºDº.
Always use the ºDº position to improve fuel economy and quiet
driving. In this position, shifting into the overdrive gear is
possible. However, while the engine coolant temperature is
low, the transmission will not shift into the overdrive gear even
in the ºDº position. (See º(c) Using engine brakingº and\
º(g)
Good driving practiceº for exceptions.)
CAUTION
Never put your foot on the accelerator pedal while
shifting.

STARTING AND DRIVING
229
5. Release the parking brake and brake pedal. Depress
the accelerator pedal slowly for smooth starting.
In normal cruising, the vehicle will start in the first gear and
automatically shift up to the most suitable gear. On inclines,
declines or winding roads, etc., the vehicle shifts up and down
automatically
according to the running conditions to obtain the
suitable driving power and engine braking.
When the lever is in º3º position, the automatic transmission
system will select the most suitable gear for the running
conditions such as hill climbing, hard towing, etc.
If you need to accelerate rapidly while driving, depress the
accelerator pedal to the full throttle position. This provides
more acceleration by automatically downshifting the
transmission to the next lower gear or beyond, depending on
the vehicle speed.
If engine braking is needed, such as in descending a long hill,
see º(b) Using engine brakingº.
(b) Driving in M mode
If the change lever is shifted to M position, the shift range
position can be switched over between 5 and 2 using the
shift switch on the steering wheel instead of operating the
change lever. The first shift range position is on 5 when
the change lever is shifted to M position.
SV31024

1ºMº position
When the selector lever is put in the ºMº position, the M MODE
indicator is shown on the instrument cluster.

STARTING AND DRIVING
230
SV31028

2Downshifting on the front, Upshifting on the rear
5: Fifth rangeThe most suitable gear is selected automatically
between first and fifth gears according to the vehicle
speed or the running condition.
4: Fourth range The most suitable gear is selected automatically
between first and fourth gears according to the vehicle
speed or the running condition. 3: Third range
The most suitable gear is selected automatically
between first and third gears according to the vehicle
speed or the running condition.
Slight engine braking will be obtained on a downhill
road.
Smooth running with less shifting will be obtained on an
uphill.
2: Second range First or second gear will be selected automatically
according to the vehicle speed or the running condition.
This range is used in the case that the engine braking is
necessary.
The gear position being used is shown on the instrument
cluster.
Each time you push the switch located on the front of the
steering wheel, the transmission downshifts (from º5º) to º4º\
,
º3º and then º2º.
When you push the switch located on the back of the steering
wheel, the transmission upshifts to º3º, º4º and then º5º\
.
For the precautions on each position, see the description on
the next page.

STARTING AND DRIVING
231
Warning tone sounds twice in any of the following cases:

You attempt to downshift the transmission when it is not
possible to downshift due to the high vehicle speed.
 You attempt to downshift from º2º position.
 You attempt to upshift from º5º position.
If the ºMº indicator flashes, there is a problem somewhere
in the system. In this case, it should be noted that you
cannot downshift or upshift the transmission using the
switches on the steering wheel. Consult with your Lexus
dealer as soon as possible. The transmission works
exactly in the same way as when you put the selector lever
in the ºDº position.
CAUTION
Be careful when downshifting on a slippery surface.
The abrupt change in engine speed could cause the
vehicle to spin or skid.
(c) Using engine braking
SV31023
To use the braking power of the engine, downshift the
transmission in the way described below:
1Shift into the ºMº position, and you push the transmission
down shift switch. The transmission will downshift to
fourth gear and engine braking will be obtained. This is
effective only when you are driving in the ºDº position or
in fifth gear (ºMº position).
When the cruise control is being used, even if you
downshift from º5º to º4º, engine braking will not be
enabled because the cruise control is not cancelled. If
you need to decrease the vehicle speed, see page 239.
2Shift into the º3º position. The transmission will downshift
to third gear when the vehicle speed is or becomes lower
than the speed listed below and stronger engine braking
will be obtained.

STARTING AND DRIVING
232
3Shift into the º2º position. The transmission will downshift
to second gear when the vehicle speed is or becomes
lower than the speed listed below and stronger engine
braking than that of º3º position will be obtained.
4Shift into the ºLº position. The transmission will downshift
to first gear when the vehicle speed is or becomes lower
than the speed listed below and maximum engine braking
will be enabled.
º4º 177 km/h (110 mph)
º3º 123 km/h ( 76 mph)
º2º 81 km/h ( 51 mph)
ºLº 17 km/h ( 11 mph)
CAUTION
Be careful when downshifting on a slippery surface.
The abrupt change in engine speed could cause the
vehicle to spin or skid.
(d) Using the º3º, º2º and ºLº positions
The º3º, º2º and ºLº positions are used for strong eng\
ine
braking as described previously.
With the selector lever in º3º, º2º or ºLº, you can start t\
he vehicle
in motion as with the lever in ºDº.
With the selector lever in º3º or º2º, the vehicle will star\
t in the
first gear and automatically shift to third or second gear.
With the selector lever in ºLº, the transmission is engaged in
the first gear.
NOTICE
Be careful not to over±rev the engine. Watch the tachometer to keep engine rpm from going into thered zone. The approximate maximum allowablespeed for each position is given below for yourreference:
º3º 124 km/h (78 mph)
. . . . . . . . . . . . . . . . . . .
º2º 81 km/h (51 mph)
. . . . . . . . . . . . . . . . . . .
ºLº 52 km/h (33 mph)
. . . . . . . . . . . . . . . . . . .
Do not continue hill climbing or hard towing for a long
time in the º3º, º2º or ºLº position. This may causesevere automatic transmission damage from
overheating. To prevent such damage, º4º positionshould be used in hill climbing or hard towing.

STARTING AND DRIVING
233
(e) Backing up
SV31025

1Brake pedal 2ºRº (Reverse) position
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the
selector lever to the ºRº position.
NOTICE
Never shift into reverse while the vehicle is moving.
(f) Parking
SV31026

1Brake pedal 2Parking brake lever
3ºPº (Park) position
1. Bring the vehicle to a complete stop.
2. Pull the parking brake lever up fully to securely apply the
parking brake.
3. With the brake pedal held down with your foot, shift the
selector lever to the ºPº position.
CAUTION
Never attempt to move the selector lever into ºPº under
any circumstances while the vehicle is moving. Serious
mechanical damage and loss of vehicle control may
result.

STARTING AND DRIVING
234
(g) Good driving practice
If the transmission repeatedly shifts up and down between the
fourth and overdrive gears when climbing a gentle slope, shift
the selector lever to the ºMº position and select the fourth gear
by pushing the transmission switch. Be sure to shift the
selector lever to the ºDº position after climbing the slope.
CAUTION
Always keep your foot on the brake pedal while stopped
with the engine running. This prevents the vehicle from
creeping.
NOTICE
Do not hold the vehicle on an upgrade with the accelerator pedal. This can cause the transmission tooverheat. Alw ays use the brake pedal or parking brake.
(h) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in snow, mud, sand, etc.,
then you may attempt to rock the vehicle free by moving
it forward and backward. Do not attempt this procedure
if people or objects are anywhere near the vehicle.
During the rocking operation the vehicle may suddenly
move forward or backward as it becomes un±stuck,
causing injury or damage to nearby people or objects.
NOTICE
If you rock your vehicle, observe the following precautions to prevent damage to the transmission and
other parts.
Do not depress the accelerator pedal while shifting the selector lever or before the transmission iscompletely shifted to forward or reverse gear.
Do not race the engine and avoid spinning thewheels.
If your vehicle remains stuck after rocking the vehicleseveral times, consider other ways such as towing.

STARTING AND DRIVING
235
(i) If you cannot shift the selector
If you cannot shift the selector lever even though the brake
pedal is depressed, use the shift lock override button. For
instructions, see ºIf you cannot shift automatic transmission
selector leverº on page 284.
(j) If the ºECT PWRº indicator light flashes
If the ºECT PWRº indicator light flashes, contact your Lexus
dealer as soon as possible. There may be trouble in the
transmission system.
MANUAL TRANSMISSION
SV31034
The shift pattern is the conventional pattern shown above.
Press the clutch pedal down fully while shifting, and then
release it slowly. Do not rest your foot on the pedal while
driving, because it will cause clutch trouble. And do not use the
clutch to hold the vehicle when stopped on an uphill grade ±
use the parking brake.
Upshifting too soon or downshifting too late will cause lugging,
and possibly pinging. Regularly revving the engine to
maximum speed in each gear will cause excessive engine
wear and high fuel consumption.
Recommended shifting speeds
The transmission is fully synchronized and upshifting or
downshifting is easy.
For the best compromise between fuel economy and vehicle
performance, you should upshift or downshift at the following
speeds:
