2002 CHEVROLET MALIBU Owners Manual

3-6 Rear Window Defogger
The rear window defogger
button is located on the
lower right corner of the
control panel.
The rear window defogger uses a warming grid to
remove fog from the rear window.
Press the defogger button to turn the system on. The
indicator light will glow. The rear window defogger will
turn itself off after about 10 minutes the first time the
button is pressed, and five minutes each additional time
the button is pressed. You can turn the defogger off by
pressing the button again or turning off the ignition.
The rear window defogger is designed to clear the center
of the window first.
Do not attach a temporary vehicle license across the
defogger grid on the rear window.NOTICE:
Don't use a razor blade or anything else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use vent mode to direct outside air
through your vehicle. Your vehicle also has the
flow
-through ventilation system.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the air conditioning
fan is running.

3-7
Ventilation Tips

Keep the hood and the area around the windshield
wipers free of ice, snow or any other obstruction,
such as leaves. The heater and defroster will work
far better, reducing the chance of fogging the inside
of your windows.

Keep the air path under the front seats clear of
objects, to help air circulate throughout your vehicle.

When an objectionable odor outside the vehicle is
encountered, the recirculation setting can prevent the
odor from being drawn into the vehicle through the
ventilation system. For example, this usage of
recirculation can be helpful when driving through a
long tunnel with poor ventilation. However,
extended usage of recirculation in cold or cool
weather can cause window fogging.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.

3-8 Setting the Clock
Press and hold the HR or MN buttons, located below the
tune knob, for two seconds. Then press and hold HR
until the correct hour appears. AM or PM will appear on
the display. Press and hold MN until the correct minute
appears. The clock may be set with the ignition on or
off. The clock symbol will appear on the display in
time
-set mode.
To set the clock to the time of an FM station
broadcasting Radio Data System (RDS) information,
press and hold HR and MN at the same time for two
seconds until UPDATED and the clock symbol appear
on the display. If the time is not available from the
station, NO UPDAT will appear on the display instead.
RDS clock time is broadcast once a minute. Once you
have tuned to an RDS broadcast station, it may take a
few minutes before pressing and holding the HR and
MN buttons to result in an update to the clock time.
AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and
Automatic Tone Control
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
 VOL
(Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-9
AUTO VOL (Automatic Volume): With automatic
volume, your audio system adjusts automatically to
make up for road and wind noise as you drive.
Set the volume at the desired level. Press this button to
select LOW, MEDIUM or HIGH. AVOL will appear on
the display. The volume level should always sound the
same to you as you drive. Each higher volume setting
allows for more volume compensation at faster vehicle
speeds. Then as you drive, automatic volume increases
the volume as necessary to overcome noise at any speed.
NONE will appear on the display if the radio cannot
determine the vehicle speed. If you don't want to use
automatic volume, select OFF.
DISP (Display): Press this knob when the ignition is off
to display the clock.Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
 TUNE
: Turn this knob to choose radio stations.
 SEEK
: Press the right or left arrow to seek to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
 PSCAN
(Preset Scan): Press and hold one of
the arrows for more than two seconds and the radio will
produce one beep. The radio will scan to the first preset
station stored on your pushbuttons, play for a few
seconds and flash the station frequency, then go on to
the next preset station. Press one of the arrows or one
of the pushbuttons again to stop scanning. SCAN will be
displayed whenever the tuner is in the preset scan mode.
The channel number (P1 through P6) will appear with
the frequency. In FM mode, this function will scan
through the current band such as FM1 or FM2. The
radio will scan preset stations with a strong signal only.
The sound will mute while scanning.

3-10
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO TONE to choose the bass and treble
equalization that best suits the type of station you are
listening to.
5. Press and hold one of the six numbered pushbuttons.
The radio will produce one beep. Whenever you
press that numbered pushbutton, the station you set
will return and the bass and treble equalization that
you selected will also be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
AUDIO: Push and release the AUDIO knob until
BASS or TREB appears on the display. Turn the
knob clockwise or counterclockwise to increase or
decrease. The display will show the bass or treble level.
If a station is weak or noisy, you may want to decrease
the treble.
To adjust bass and treble to the middle position, push
and hold the AUDIO knob. The radio will produce one
beep and adjust the display level to the middle position.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. You will hear one beep
and the radio will display ALL. The bass and treble will
be adjusted to the middle position.
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for country/western, jazz, talk, pop, rock and
classical stations.
Each time you press the AUTO TONE button, this
feature will switch to one of these program types.
To return the bass and treble to the manual mode,
push and release the AUDIO knob until the display
goes blank.

3-11
Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
left speakers, push and release the AUDIO knob until
BAL appears on the display. Turn the knob clockwise to
move the sound to the right speakers and
counterclockwise to move the sound to the left speakers.
To adjust the fade, push and release the AUDIO
knob until FADE appears on the display. Turn the
knob clockwise to move the sound to the front
speakers and counterclockwise to move the sound to
the rear speakers.
To adjust the balance and fade to the middle position,
push the AUDIO knob, then push it again and hold it
until you hear one beep. The balance and fade will be
adjusted to the middle position and the display will
show the speaker balance.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. The radio will produce
one beep and display ALL with the level display in the
middle position.Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that receives data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS your radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS features are only available on FM stations which
broadcast RDS information. The RDS features of your
radio rely on receiving specific RDS information from
these stations. These features will only work when the
RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, contact the radio station.

3-12
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.
Finding RDS Stations
To find RDS stations, perform the following steps:
1. Press the SEEK TYPE button or turn the P
-TYPE
LIST knob to display the program type list.
2. Turn the knob either clockwise or counterclockwise
to select a program type. The list is alphabetical. If
you select ANY TYPE your radio will seek to the
first PTY available.
3. Press the SEEK TYPE button to activate search.
DISP (Display): Press this knob to change what appears
on the display while using RDS. Pressing this knob will
also display an RDS station frequency or program type
when the radio is on. The display options are station
name, station frequency, PTY and the name of the
program (if available). Pressing and holding this knob
will activate the RDS default display.Finding a PTY Preset Station
P
-TYPE LIST (Program Type): Turn this knob
clockwise or counterclockwise to select the Program
Type (PTY) you want to listen to. TYPE and a PTY will
appear on the display. Press the SEEK TYPE button and
the radio will seek to the first RDS broadcaster of the
selected program type. If the radio cannot find the
desired program type, NONE will appear on the display
and the radio will return to the last station you were
listening to.
BAND (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same program type. Press and hold BAND for two
seconds to turn alternate frequency on. AF ON will appear
on the display. The radio may switch to stronger stations.
Press and hold BAND again for two seconds to turn
alternate frequency off. AF OFF will appear on the
display. The radio will not switch to other stations. When
you turn the ignition off and then on again, the alternate
frequency feature will automatically be turned on.
SEEK TYPE: Press this button to go to a station with
the last selected PTY; TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press TYPE a second time to seek. If a station with the
selected PTY is not found, the radio will return to the
original station and display NONE.

3-13
RDS Messages
ALERT!: Alert warns of national or local emergencies.
You will not be able to turn off alert announcements.
ALERT! appears on the display when an alert
announcement plays. When an alert announcement
comes on the current radio station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player is playing, play will
stop for the announcement and resume when the
announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
INFO (Information): If the current station has a
message, the information symbol will appear on the
display. These text messages are from the RDS
broadcaster to the listening public and may be general
information such as artist and song title, call in phone
numbers, etc. Press this button to see the message. If the
whole message does not appear on the display, parts of
the message will appear every three seconds until the
message is completed. To scroll through the message at
your own speed, press the INFO button again for less
than one second.A new group of words will appear on the display.
Once the complete message has been displayed, the
information symbol will disappear from the display until
another new message is received. The old message can be
displayed by pressing the INFO button until a new
message is received or a different station is tuned to.
When a message is not available from an FM station,
NO INFO will be displayed.
TRAF (Traffic): Press this button to receive traffic
announcements. If the current station does not broadcast
traffic announcements, the radio will seek to a station
that does. The traffic symbol will flash on the display.
When the radio finds a station that broadcasts traffic
announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
Your radio can be programmed to interrupt the playback
of a CD or FM station by enabling the traffic interrupt
feature. Press the TRAF button once to seek to an RDS
station that supports the traffic interrupt feature if the
current station does not. The traffic symbol will flash on
the display when seeking for a station that supports
traffic interrupt. When the traffic interrupt feature is on,
TRAF will appear on the display.
