2002 BUICK REGAL Owner's Manual

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry
2
-17 Trunk
2
-22 Theft
2
-23 PASS-Key
II
2
-24 New Vehicle ªBreak-Inº
2
-25 Ignition Positions
2
-26 Starting Your Engine
2
-27 Engine Coolant Heater (If Equipped)
2
-28 Automatic Transaxle Operation
2
-33 Parking Brake
2
-34 Shifting Into PARK (P)
2
-36 Shifting Out of PARK (P)
2
-37 Parking Over Things That Burn
2
-38 Engine Exhaust
2
-38 Running Your Engine While You're Parked2
-39 Horn
2
-39 Tilt Wheel
2
-40 Turn Signal/Multifunction Lever
2
-46 Exterior Lamps
2
-49 Interior Lamps
2
-52 Mirrors
2
-56 Storage Compartments
2
-58 Sun Visors
2
-58 Auxiliary Power Outlet
2
-59 Auxiliary Power Connection (Power Drop)
2
-60 OnStar
System (If Equipped)
2
-64 Sunroof (Option)
2
-65 The Instrument Panel -- Your
Information System
2
-66 Instrument Panel Cluster
2
-68 Warning Lights, Gages and Indicators
2
-82 Driver Information Center (Option)

2-2
Windows
CAUTION:
Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome by
the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with the
windows closed in warm or hot weather.

2-3 Power Windows
The switches on the driver's door armrest can be used
to control each of the windows when the ignition is on.
In addition, each passenger's door has a window.Express
-Down Window
The driver's window switch has an express
-down
feature. This switch is labeled AUTO. Tap the rear of
the switch and the driver's window will open a small
amount. If the rear of the switch is pressed all the
way down, the window will go all the way down.
To stop the window while it is lowering, press the front
of the switch. To raise the window, press and hold the
front of the switch.
The driver's window controls also include a lock
-out
switch. Press LOCK to stop front and rear passengers
from using their window switches. The driver can still
control all the windows with the lock on. Press the other
side of the LOCK switch for normal window operation.

2-4
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
Don't leave the keys in a vehicle with children.

2-5
The ignition key is for the
ignition only.
The door key is for the
doors and all other locks.The ignition and door keys don't have plugs. Your
dealer or Buick Roadside Assistance has the code for
your keys.
If you need a new ignition or door key, contact
your dealer who can obtain the correct key code.
Also, see ªRoadside Assistanceº in the Index for
more information.
NOTICE:
Your vehicle has a number of features that can
help prevent theft. But you can have a lot of
trouble getting into your vehicle if you ever
lock your keys inside. You may even have to
damage your vehicle to get in. So be sure you
have extra keys.
If your vehicle is equipped with the OnStar
system
with an active subscription and you lock your keys
inside the vehicle, OnStar may be able to send a
command to unlock your vehicle. See ªOnStarº in
the Index for more information.

2-6
Door Locks
CAUTION:
Unlocked doors can be dangerous.

Passengers -- especially children -- can
easily open the doors and fall out of a
moving vehicle. When a door is locked,
the handle won't open it. You increase the
chance of being thrown out of the vehicle
in a crash if the doors aren't locked.
So, wear safety belts properly and lock
the doors whenever you drive.

Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.

Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.
From the outside, use your door key or remote keyless
entry transmitter.
From the inside, to manually lock the door, push the
lever forward. To unlock, push the lever rearward.

2-7 Power Door Locks
Your vehicle is equipped
with front power door lock
switches. Press a power
door lock switch to lock
or unlock all doors.
The rear doors do not have power door lock switches.
Use the manual lock levers to lock or unlock each
rear door.
Programmable Automatic Power
Door Locks
Programmable automatic power door locks are intended
to provide enhanced security and convenience by
automatically locking and unlocking doors. This
feature provides four operating modes.Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: No automatic door lock or unlock.
Mode 2:

Automatic all
-door lock when the transaxle is shifted
out of PARK (P); no automatic door unlock.

Automatic door relock when any door is unlocked,
opened and then all doors are again closed while the
vehicle is not in PARK (P) or NEUTRAL (N) and
the driver's foot is on the brake pedal.
Mode 3:

Automatic all
-door lock when the transaxle is shifted
out of PARK (P).

Automatic all
-door unlock when the transaxle is
shifted into PARK (P).

Automatic door relock when any door is unlocked,
opened and then all doors are closed again while the
vehicle is not in PARK (P) or NEUTRAL (N) and
the driver's foot is on the brake pedal.

2-8
Mode 4:

Automatic all
-door lock when the transaxle is shifted
out of PARK (P).

Automatic driver's door only unlock when the
transaxle is shifted into PARK (P).

Automatic door relock when any door is unlocked,
opened and then all doors are closed again while the
vehicle is not in PARK (P) or NEUTRAL (N) and
the driver's foot is on the brake pedal.
Before your vehicle was shipped from the factory, it
was programmed to Mode 3. The mode in which your
vehicle was programmed may have been changed since
it left the factory. To determine which programmable
mode your vehicle is programmed to or to program
your vehicle to a different mode, do the following:
1. Turn the ignition key to RUN.
2. Close all of the doors.
3. Apply your brakes.
4. Press and hold the power door lock switch in the
lock position. While holding the door lock switch in
the lock position, move the shift lever out of and
back into PARK (P).After an initial transaxle cycle, each additional cycle
will advance the operating mode by one, starting from
the current operating mode. During this procedure, the
automatic door lock and unlock functions will operate as
defined by each mode listed previously, providing the
driver with feedback of the current operating mode.
If cycled beyond Mode 4, the vehicle will enter
operating Mode 1. When the door lock switch is
released, the vehicle will remain in the most recent
operating mode.
Disconnecting the vehicle's battery for up to a year
will not change the last programmed mode of the
programmable automatic power door locks.
