2002 BUICK REGAL Owner's Manual

2-57 Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net isn't for larger, heavier loads. Store those in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
The center front ashtray is located just below the
instrument panel's comfort controls at the front of the
console, behind the front compartment storage door.
To remove the ashtray, open the storage door. Then open
the small black door, lift up on the ashtray and pull it out.
The rear ashtray is located within a small door at the
rear of the console. Push on the right side of the door.
The ashtray will then pivot to the right for usage. You
can only access the ashtray by pushing on the door's
right side.To remove the ashtray, push down on the snuffer located
in the middle of the ashtray and lift it out.
NOTICE:
Don't put papers and other things that burn
into your ashtrays. If you do, cigarettes or
other smoking materials could set them on fire,
causing damage.
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.

2-58
Sun Visors
To block out glare, you can swing down the visors. You
can also move them from side to side. The visors also
have extenders that you can pull out for added coverage.
Visor Vanity Mirrors
Open the cover on the visor to expose the vanity mirror.
Lighted Vanity Mirrors
If your vehicle has the optional lighted vanity mirrors,
the lamps come on when you open the cover.
Auxiliary Power Outlet
With accessory power outlets you can power auxiliary
electrical equipment such as a cellular telephone or
CB radio.
Your vehicle is equipped with a 12
-volt outlet.
It is located on the console, near the floor on the
passenger's side.
Open the cover to use the outlet. Be sure to close the
cover when the outlet is not in use.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
Certain power auxiliary plugs may not be compatible
to the power auxiliary outlet and could result in blown
vehicle or adapter fuses. If you experience a problem,
see your dealer for additional information on the power
accessory plugs.
NOTICE:
Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or
accessory bracket from the plug. Improper
use of the power outlet can cause damage not
covered by your warranty.

2-59
NOTICE:
When using accessory power outlets:

Loading of any electrical equipment should
not exceed the maximum fuse rating.

Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain the battery.
When adding electrical equipment, be sure to follow
the proper installation instructions included with
the equipment.
Auxiliary Power Connection
(Power Drop)
Your vehicle is equipped with an auxiliary power
connection. This feature provides power, ground and
accessory wires which can be accessed to add
aftermarket electrical equipment to your vehicle.
It is located on the
passenger's side of
the vehicle, under the
glove box, and is labeled
with a wire function and
fuse rating.

2-60
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
When adding electrical equipment, be sure to follow
the proper installation instructions included with
the equipment.
For information on accessing the connection and
electrical hookup, please refer to your service manual.
To order a service manual, see ªService Publications,
Orderingº in the Index.
OnStar
System (If Equipped)
OnStar is a vehicle communications system that offers a
variety of services and provides a one
-touch hands-free
communication link between you and the OnStar Center.
To receive OnStar services, a service subscription
agreement is required and an additional fee may
be required. Services are available 24 hours a day,
7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
(OnStar Services Button): Press this button once to
contact an advisor who will be able to assist you with these
services. If you are not quickly connected, the system will
automatically reset and redial. This ensures connection to the
center; there is no additional action required. Press the
Communication button to cancel the automatic redial.

2-61
(Emergency Button): In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
(Communication Button): Press this button at
the end of a call. Also press this button to answer a
call from the center, or cancel a call if one of the other
buttons is accidentally pressed. This button is also
used to access OnStar Personal Calling and Virtual
Advisor services. See the OnStar owner package for
more information.
(Volume Control): You can control the volume
of the OnStar System using either the volume knob
on the radio or using the steering wheel volume control
(If equipped).
(Telltale Light): This light will indicate the status
of the system. A solid green light will come on when
you start the vehicle to let you know that the system is
on and is ready to make or receive calls.If the light blinks green it means that an incoming or
outgoing call is in progress. Press the Communication
button if you notice the light blinking and you are not
on a call.
The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar button to
attempt to contact an advisor. If the connection is made,
the advisor will assist you with steps to take to make
sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
Cellular Antenna
The cellular antenna on the outside of your vehicle is
critical to effective communications using the OnStar
system. Optimum cellular reception can be obtained
when the mast is straight up and down.

2-62 OnStar Services
The following services are available within OnStar
service plans. Your vehicle comes with a specific
one
-year service plan that allows use of some or
all for the following services.

Automatic Notification of Air Bag Deployment: If
an air bag deploys, a priority emergency signal is
automatically sent to the center. An advisor will
locate your vehicle's position, try to contact you
and assist you in the situation. If the center is unable
to contact you, an emergency service provider will
be contacted.

Stolen Vehicle Tracking: Call the center at
1
-888-4-ONSTAR (1-888-466-7827) to report
your vehicle stolen. The system can then attempt to
locate and track your vehicle and the advisor will
assist the proper authorities.
Roadside Assistance with Location: For vehicle
breakdowns, press the OnStar button. An advisor
will contact the appropriate help.

Remote Diagnostics: If an instrument panel light
comes on, the center can perform a check of the
engine on
-board computer. An advisor can then
recommend what action needs to be taken.

OnStar MED
-NET: Med-Net can store your
personal medical history and provide it to emergency
personnel if necessary. (Requires activation and
additional fee.)

Accident Assist: An advisor can provide
step
-by-step guidance following an accident.

Remote Door Unlock: To contact the center,
call 1
-888-4-ONSTAR. You will be required to
provide your security information. An advisor will
send a command to your vehicle to unlock itself.
The advisor can delay unlocking your vehicle.
Remote Door Unlock is disabled 48 hours after the
vehicle is parked to maintain the battery charge.

2-63

Vehicle Locator Service: To contact the center, call
1
-888-4-ONSTAR. You will be required to provide
your security information. An advisor will send a
command to your vehicle to sound the horn and/or
flash the lamps.

Route Support: An advisor can provide directions
or guidance to anywhere you want to go. In addition,
they can help you locate gas stations, rest areas,
ATMs, hospitals, hotels, stores, eateries and more.

Ride Assist: An advisor can locate transportation in
the event that you are unable to drive.

Concierge Services: The concierge advisor can
obtain tickets, reservations, or help with vacation/trip
planning and other unique items and services.
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement. In order to provide you with
excellent service, calls with the OnStar Center may
be monitored or recorded.OnStar Service is:

available in the 48 contiguous United States, Alaska,
Hawaii and Canada;

available when the vehicle is within the operating
range of a cellular provider;

subject to limitations caused by atmospheric
conditions, such as severe weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.
Global positioning locating capabilities will not be
available if satellite signals are obstructed.
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative
if the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
OnStar is the communication link between you and
existing governmental emergency and roadside service
providers. OnStar will receive your call and use
reasonable effort to contact an appropriate provider.
OnStar cannot promise that the providers will respond
in a timely manner or at all.

2-64
Sunroof (Option)
Your vehicle may be equipped with an express-open
sunroof. It includes a sliding glass panel and a
one
-piece sunshade.
The switch is located overhead on the headliner.
The switch works only when the ignition is on or when
retained accessory power is active. See ªRetained
Accessory Powerº in the Index.VENT: To open the sunroof to the vent position only,
push and hold the front of the switch. You will need to
open the sunshade by hand. To close the sunroof from
the vent position, push and hold the rear (indented part)
of the switch.
Open/Express Open: To open the sunroof, push the
rear (indented part) of the switch once. The sunroof
and sunshade will open by themselves. This is the
express
-open feature.
Close: To close the sunroof, push and hold the front of
the switch until the sunroof motor stops. The sunshade
can only be closed by hand.
