2002 BUICK REGAL Owner's Manual

2-49
Interior Lamps
Instrument Panel Brightness Control
This feature control the brightness of the instrument
panel lights.
You can brighten or dim the instrument panel lights by
adjusting the exterior lamps control located to the right
of the exterior lamps control.
If you turn to control clockwise the interior lamps will
come on and become brighter as the control is turned
further to MAX. Turning the control all the way
clockwise turns on the courtesy lamps. If you turn the
control counterclockwise the lamps will begin to dim
and continue to get dimmer as the control is turned
closer toward LIGHTS MIN. If the control is turned
all the way counterclockwise, the lamps and lights will
turn off.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps control
clockwise to MAX.
Illuminated Entry
Your courtesy lamps will come on and stay on for a
set time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to RUN or
START, so the lamps will dim right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless
a door is opened.

2-50 Delayed Entry Lighting
Delayed entry lighting lights your vehicle's interior for a
period of time after all the doors have been closed.
The ignition must be off for delayed entry lighting to
work. Just after all the doors have been closed, the
delayed entry lighting feature will continue to work until
one of the following occurs:

The ignition is in RUN, or

the doors are locked, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Delayed Exit Lighting
This feature illuminates the interior for a period of time
after the ignition key is removed from the ignition.
The ignition must be off for delayed exit lighting to
work. When the ignition key is removed, interior
illumination will activate and remain on until one of the
following occurs:

The ignition is in RUN, or

the power door locks are activated, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Perimeter Lighting
Perimeter lighting provides a period of exterior vehicle
lighting as the driver and passengers approach the
vehicle. Perimeter lighting is only activated when the
function is enabled, the doors are closed, the ignition is
in OFF and the security feedback feature is in Mode 3
or 4. (See ªSecurity Feedbackº in the Index for more
information.) The vehicle headlamps and back
-up lamps
are then activated for a period of 25 seconds or until the
ignition switch is turned to RUN.

2-51
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running and the doors closed:
1. Turn the ignition to RUN.
2. Close all the doors.
3. Apply your brakes.
4. Press and hold the power door lock switch. While
holding the door lock switch press and release the
panic button on the remote keyless entry transmitter.
This will initialize the customization mode. While in the
customization mode, the feature will sound the number
of chimes corresponding to the current mode. In Mode
1, one chime means the feature is disabled. In Mode 2,
two chimes signal that the perimeter lighting feature is
enabled. Each additional press will advance the mode by
one, starting from the current mode. During this
procedure, the feature will sound the number of chimes
corresponding to the mode. When the lock switch is
released, the vehicle will remain in the last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation for this feature.Rearview Mirror Reading Lamps
The reading lamps are located on the underside of the
rearview mirror.
Use the button next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open a door.
Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave
the interior courtesy lamps, reading/map lamps, visor
vanity lamps, trunk lamp, underhood lamp or glove box
lamps on. If you leave any of these lamps on, they will
automatically turn off after 20 minutes, if the ignition is
in OFF. The lamps won't come back on again until you
do one of the following:

Turn the ignition on,

turn the exterior lamps control off, then on, or

open a door.
If your vehicle has less than 15 miles (25 km) on the
odometer, the battery saver will turn off the lamps after
only three minutes.

2-52
Mirrors
Adjust all the mirrors so you can see clearly when you
are sitting in a comfortable driving position.
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, pull the lever
at the bottom of the mirror toward you (to the night
position). To return the mirror to the day position, push
the lever away from you.
Inside Day/Night Rearview Mirror with
OnStar
and Map Lamps (If Equipped)
This mirror has a lever located at the bottom of the
mirror between the two map lamps. This lever is used to
change the mirror from day to night position. To reduce
glare from headlamps behind you while driving at night,
turn the lever 90. To return the mirror to the day
position, return the lever to its original position.
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar Systemº in the Index for more
information about the services OnStar provides.

2-53 Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)
Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments.
The mirror's two outer buttons operate the lights on the
bottom sides of the mirror.One photocell on the front of the mirror senses when
it is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the
center of the mirror again.
To keep the photocells operating well, occasionally
clean them with a cotton swab and glass cleaner.
Electrochromic Day/Night Rearview
Mirror with OnStar
and Map Lamps
(If Equipped)
Your vehicle may have an automatic electrochromic
day/night rearview mirror with the OnStar System.
The automatic dimming feature is turned on or off by
pressing the far left button, located on the lower part
of the mirror face, for up to three seconds. When
turned on, this mirror functions exactly like the
electrochromic mirror described previously. See
ªMirrors, Electrochromic Automatic Dimmingº
listed previously in this section for more information.

2-54
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar

Systemº in the Index for
more information about the services OnStar provides.
Power Outside Foldaway Rearview Mirrors
The power mirror
controls are located
on the driver's
door armrest.
To choose either the left or right outside mirror,
move the selector switch located above the control pad
to the left or the right. Then use the four
-way arrows
located on the control pad to move the mirrors in the
desired direction.
Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
These mirrors can also be folded rearward manually.

2-55 Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
With this feature, the driver's side outside mirror will
adjust for the glare of headlamps behind you. This
feature is controlled by the on and off settings on the
electrochromic automatic dimming rearview mirror.
(See ªElectrochromic Automatic Dimming Rearview
Mirrorº earlier in this section.)
The driver's and the front passenger's outside mirrors
are also heated when you activate the rear window
defogger. (See ªRear Window Defoggerº in the Index.)
Both outside mirrors can be folded forward or rearward.

2-56
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch.
Center Console
The console has cupholders, a cassette tape storage area
and a coinholder.
To open the console's storage area, press the latch
located toward the front of the console lid on the
driver's side of the vehicle and pull up.
To access the cupholders, pull on the top of the
cupholder door, located just behind the console shift
lever. Two cupholders will pop into an upright position.
Rear Storage Armrest
To access the rear storage armrest, pull down on the
cloth strap located toward the top of the center back seat
cushion. To open, pull up on the lever at the end of the
armrest and lift. You will then have access to the storage
compartment and dual oversized cupholders.
To use the cupholders, lift up and place the cupholders
in the front of the storage compartment. Replace when
not in use.
