2001 TOYOTA AVALON engine coolant

PP0RT-02
- PREPARATIONCOOLING
PP-15
65 Author
: Date
:
2001 AVALON (RM808U)
COOLANT
ItemCapacityClassification
Engine coolant9.0 liters (9.5 US qts, 7.9 lmp. qts)Toyota Long Life Coolantº or equivalent

PP0RP-02
- PREPARATIONSFI
PP-1 1
61 Author
: Date
:
2001 AVALON (RM808U)
COOLANT
ItemCapacityClassification
Engine coolant9.0 liters (9.5 US qts, 7.9 lmp. qts)ºTOYOTA Long Life Coolantº or equivalent

SS-36
- SERVICE SPECIFICATIONSBODY ELECTRICAL
152 Author
: Date
:
2001 AVALON (RM808U) ENGINE COOLANT TEMPERATURE SENDER GAUGE (Resistance)
Temperature °C (°F)Resistance (W)
A - BApprox. 250 W
C - DApprox. 250 W
LIGHT FAILURE RELAY (Wire Harness Side)
3 - Ground (Light control switch OFF)No voltage
3 - Ground (Light control switch TAIL or HEAD)Battery positive voltage
4 - Ground (Ignition switch LOCK or ACC)No voltage
4 - Ground (Ignition switch ON)Battery positive voltage
7 - Ground (Stop light switch OFF)No voltage
7 - Ground (Stop light switch ON)Battery positive voltage
8 - Ground (Ignition switch LOCK or ACC)No voltage
8 - Ground (Ignition switch ON)Battery positive voltage
SLIDING ROOF CONTROL RELAY AND SWITCH (Wire Harness Side)
8 - Ground (Ignition switch LOCK or ACC)* No voltage
8 - Ground (Ignition switch ON)Battery positive voltage
5 - Ground (Constant)Battery positive voltage
*: Exceptions: For 60 seconds after the ignition switch ON"OFF (ACC) or until driver or passenger door is
opened after the ignition switch ON"OFF (ACC).

SS-10
- SERVICE SPECIFICATIONSENGINE MECHANICAL
126 Author
: Date
:
2001 AVALON (RM808U) Engine coolant drain union x Cylinder block
3940029
Water seal plate x Cylinder block1818013
Oil filter union x Cylinder block3031022
Water inlet housing x Cylinder block88069 in.´lbf
Knock sensor x Cylinder block3940029
No.2 idler pulley bracket x Cylinder block2829021
A/C compressor housing bracket x Cylinder block2525018
Generator bracket x Cylinder block4344032
Drive plate x Crankshaft8385061
Transaxle x Engine6465047
No.1 oil pan x Transaxle37.238027
Drive plate x Torque convertor clutch4142030
Flywheel housing under cover x Transaxle7.88069 in.´lbf
Rear engine mounting insulator x Cylinder block6465047
Front engine mounting insulator x Cylinder block6465047
Engine moving control rod x RH engine mounting bracket6465047
Engine moving control rod x RH fender apron6465047
RH engine mounting stay x Water outlet3232023
RH engine mounting stay x Engine moving control rod3232023
RH engine mounting stay x No.2 RH engine mounting bracket3232023
Front engine mounting insulator x Front frame Silver color bolt
Green color bolt44
66450
67032
49
Engine mounting absorber x Front frame4849035
Engine mounting absorber x Transaxle4849035
Rear engine mounting insulator x Front frame6667048
LH engine mounting insulator x Transaxle6465047
PS pump x PS pump bracket4344031
A/C compressor x Housing bracket25.526019
A/C compressor x No.1 oil pan25.526019
Generator adjusting bar x Drive belt adjusting bar bracket1818513
Fuel inlet hose x Fuel filter2930021
Front exhaust pipe support bracket x No.1 oil pan20.621015
Front exhaust pipe x Exhaust manifold6263046
Front exhaust pipe x Center exhaust pipe5657041
Center exhaust pipe x Tailpipe5657041
Front exhaust pipe bracket x Sub frame3333024
Front exhaust pipe support bracket x Front exhaust pipe stay3333024

SF06Q-05
B06679
ECT Switch
19 mm
Deep Socket
Wrench
Gasket
S01196S01699Z17274
Ohmmeter
Resistance kW
Temperature °C (°F) Acceptable 30
20
10
5
3
2
1
0.5
0.3
0.2
0.1
40 -20 0 20 60 80 100
(212) (176) (140) (104) (68) (32) (-4)
- SFIENGINE COOLANT TEMPERATURE (ECT) SENSOR
SF-73
1182 Author
: Date
:
2001 AVALON (RM808U)
ENGINE COOLANT
TEMPERATURE (ECT) SENSOR
INSPECTION
1. DRAIN ENGINE COOLANT
2. REMOVE ECT SENSOR
(a) Disconnect the ECT sensor connector.
(b) Using a 19 mm deep socket wrench, remove the ECT
sensor and gasket.
3. INSPECT ECT SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance: Refer to the graph
If the resistance is not as specified, replace the ECT sensor.
4. REINSTALL ECT SENSOR
(a) Install a new gasket to the ECT sensor.
(b) Using a 19 mm deep socket, install the ECT sensor.
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
(c) Connect the ECT sensor connector.
5. REFILL WITH ENGINE COOLANT

SF06S-03
B09135
Ground Cable
PCV Hose
Air Intake Chamber
Assembly
ECT Sensor
Connector ECT Sender
Gauge Connector
IAC Valve
Connector
VSV Connector for No.2 ACIS
Engine Coolant
Reservoir HoseThrottle Position
Sensor Connector Brake Booster
Vacuum Hose Throttle Body Bracket
Water Outlet PS Pressure Tube
19.5 (200, 14)
39 (400, 19)
15 (150, 11)
43 (440, 32)
Ground Strap
DLC1
Gasket
15 (150, 11)
Grand Strap
Connector

Gasket
39 (400, 29)
V-Bank Cover
Accelerator CableAir Cleaner Hose
w/ Resonator
Purge Hose
Vacuum Hose
Fuel Hose
Clamp
Heater Hose
Intake Manifold Assembly
Injector Connector x 9
Knock Sensor
Connector
Upper Radiator
Hose

Gasket
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)

Retainer
Knock Sensor
Water Bypass
Hose
VSV Connector for
EVAP
No.1 Engine
Hanger
VSV Connector
for No.1 ACIS
Throttle Cable
Ground Cable
SF-76
- SFIKNOCK SENSOR
1185 Author
: Date
:
2001 AVALON (RM808U)
KNOCK SENSOR
COMPONENTS

SF0ZT-02
A10518
5 mm
Hexagon
Wrench
B09090
B09091(d)
(b)
(c)
(e)
B09092
(j)(g)
(h) (f)
(k) (i)
SF-36
- SFITHROTTLE BODY
1145 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE V-BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 3 cap nuts.
(b) Loosen the V-bank cover fastener counterclockwise.
HINT:
At the time of installation, please refer to the following items.
Press down the V-bank cover fastener.
(c) Remove the V-bank cover.
3. REMOVE AIR CLEANER HOSE WITH RESONATOR
(a) Disconnect the PCV hose.
(b) Disconnect the vacuum hose (from the VSV for the active
engine control mount).
(c) Loosen the 3 hose clamps, and remove the air cleaner
hose with the resonator.
4. DISCONNECT ACCELERATOR CABLE AND
THROTTLE CABLE
5. REMOVE THROTTLE BODY
(a) Remove the bolt holding the throttle body to the throttle
body bracket.
Torque: 19.5 N´m (200 kgf´cm, 14 ft´lbf)
(b) Disconnect the throttle position sensor connector.
(c) Disconnect the IAC valve connector.
(d) Disconnect the wire clamp.
(e) Disconnect the brake booster vacuum hose.
(f) Disconnect the water bypass hose (from the intake man-
ifold).
(g) Disconnect the water bypass hose (from the water inlet
housing).
(h) Disconnect the air assist hose.
(i) Disconnect the fuel vapor feed hose (from the emission
control valve set).
(j) Disconnect the vacuum hose (from the No.1 ACIS VSV).
(k) Disconnect the vacuum hose (from the vacuum tank for
the ACIS).
