Page 1746 of 1897
R04211
Inner Diam.
Tires
(3 or More)Width
R13763
10 m (33 ft) or more
AB0166
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-23
1543 Author: Date:
2001 AVALON (RM808U)
Covering method using tires:
Place at least 3 tires without disc wheel on top of the
disc wheel with tire to which the steering wheel pad
is tied.
Tire size: Must exceed the following dimensions-
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(g) Deploy the airbag.
(1) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(-) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
(h) Dispose of the steering wheel pad (with airbag).
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
Use gloves and safety glasses when handling a steer-
ing wheel pad with the deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a steering wheel pad with
the deployed airbag.
(1) Remove the steering wheel pad from the disc
wheel.
(2) Place the steering wheel pad in a vinyl bag, tie the
end tightly and dispose of it in the same way as oth-
er general parts disposal.
Page 1815 of 1897
F08857
SR0EG-05
F08858
SR-8
- STEERINGSTEERING WHEEL
1471 Author: Date:
2001 AVALON (RM808U)
STEERING WHEEL
INSPECTION
1. CHECK STEERING WHEEL FREEPLAY
(a) Stop the vehicle and face the tires straight ahead.
(b) Rock the steering wheel gently up and down with a finger
lightly, check the steering wheel freeplay.
Maximum freeplay: 30 mm (1.18 in.)
2. CHECK STEERING EFFORT
(a) Center the steering wheel.
(b) Remove the steering wheel pad (See page SR-12).
(c) Start the engine and run it at idle.
(d) Measure the steering effort in both directions.
Steering effort (Reference)
5.9 N´m (60 kgf´cm, 52 in.´lbf)
HINT:
Take the tire type, pressure and contact surface into consider-
ation before making your diagnosis.
(e) Torque the steering wheel set nut.
Torque: 50 N´m (510 kgf´cm, 37 ft´lbf)
(f) Install the steering wheel pad (See page SR-22).
Page 1816 of 1897
SR0EC-02
SR-2
- STEERINGTROUBLESHOOTING
1465 Author: Date:
2001 AVALON (RM808U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, repair or replace these parts.
SymptomSuspect AreaSee page
Hard steering
1. Tires (Improperly inflated)
2. Power steering fluid level (Low)
3. Drive belt (Loose)
4. Front wheel alignment (Incorrect)
5. Steering system joints (Worn)
6. Suspension arm ball joints (Worn)
7. Steering column (Binding)
8. Power steering vane pump
9. Power steering gearSA-2
SR-5
SR-3
SA-4
-
SA-38
-
SR-25
SR-37
Poor return
1. Tires (Improperly inflated)
2. Front wheel alignment (Incorrect)
3. Steering column (Binding)
4. Power steering gearSA-2
SA-4
-
SR-37
Excessive play
1. Steering system joints (Worn)
2. Suspension arm ball joints (Worn)
3. Universal joint, Intermediate shaft, Sliding yoke (Worn)
4. Front wheel bearing (Worn)
5. Power steering gear-
SA-38
-
SA-9
SR-37
Abnormal noise
1. Power steering fluid level (Low)
2. Steering system joints (Worn)
3. Power steering vane pump
4. Power steering gearSR-5
-
SR-25
SR-37
Page 1895 of 1897
SA1DO-03
R03031
W02620
Front
R07928
SA-2
- SUSPENSION AND AXLETIRE AND WHEEL
1336 Author: Date:
2001 AVALON (RM808U)
TIRE AND WHEEL
INSPECTION
1. INSPECT TIRE
(a) Check the tires for wear and proper inflation pressure.
Cold tire inflation pressure:
Tire sizeFront, rear
kPa (kgf/cm2, psi)
P205/65R15 92H210 (2.1, 31)
P205/60R16 91H220 (2.2, 32)
(b) Check the tire runout.
Tire runout: 1.0 mm (0.039 in.) or less
2. ROTATING TIRES
HINT:
See the illustration for where to rotate each tire when you in-
clude the spare tire in the rotation and when you do not.
3. INSPECT WHEEL BALANCE
(a) Check and adjust the Off-the-car balance.
(b) If necessary, check and adjust the On-the-car balance.
Imbalance after adjustment: 8.0 g (0.018 lb) or less
Page 1896 of 1897
W03084
- SUSPENSION AND AXLETIRE AND WHEEL
SA-3
1337 Author: Date:
2001 AVALON (RM808U)
4. CHECK WHEEL BEARING LOOSENESS
(a) Check the backlash in the bearing shaft direction.
Maximum: 0.05 mm (0.0020 in.)
(b) Check the axle hub deviation.
Maximum: 0.05 mm (0.0020 in.)
5. CHECK FRONT SUSPENSION FOR LOOSENESS
6. CHECK STEERING LINKAGE FOR LOOSENESS
7. CHECK BALL JOINT FOR LOOSENESS
8. CHECK SHOCK ABSORBER WORKS PROPERLY
Check that oil leaks
Check mounting bushings for wear
Bounce front and rear of the vehicle
Page 1897 of 1897
SA0CB-02
- SUSPENSION AND AXLETROUBLESHOOTING
SA-1
1335 Author: Date:
2001 AVALON (RM808U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspect AreaSee page
Wander/pulls
3. Tire (Worn or improperly inflated)
4. Wheel alignment (Incorrect)
5. Steering linkage (Loosen or worn)
6. Hub bearing (Worn)
7. Steering gear (Out of adjustment or broken)
8. Suspension parts (Worn)SA-2
SA-4
SA-7
-
SA-9
SA-45
SR-37
-
Bottoming
1. Vehicle (Overloaded)
2. Spring (Weak)
3. Shock absorber (Worn)-
SA-25
SA-49
SA-28
SA-52
Sways/pitches
1. Tire (Worn or improperly inflated)
2. Stabilizer bar (Bent or broken)
3. Shock absorber (Worn)SA-2
SA-40
SA-62
SA-28
SA-52
Front wheel shimmy
1. Tire (Worn or improperly inflated)
2. Wheel (Out of balance)
3. Shock absorber (Worn)
4. Wheel alignment (Incorrect)
5. Ball joint (Worn)
6. Hub bearing (Worn)
7. Steering linkage (Loosen or worn)
8. Steering gear (Out of adjustment or broken)SA-2
SA-2
SA-28
SA-4
SA-38
SA-9
-
SR-37
Abnormal tire wear
1. Tire (Worn or improperly inflated)
2. Wheel alignment (Incorrect)
3. Shock absorber (Worn)
4. Suspension parts (Worn)SA-2
SA-4
SA-28
SA-52
-
