2001 CHEVROLET VENTURE Owners Manual

2-16
Multifunction Alarm Locks and Lighting Choices
Your vehicle's locks and lighting systems can be programmed with several different features. The features you can
program depend on the options that came with your vehicle. The following chart shows the features that can be
programmed. To determine which features your vehicle is equipped with, follow the steps listed for entering the
programming mode.

2-17
Entering Programming Mode
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. The optional content theft
-deterrent system must be
disarmed. See ªContent Theft
-Deterrent Systemº in
this section.
2. Remove fuse 47 from the instrument panel fuse
block, located to the right of the glove box.
See ªFuses and Circuit Breakersº in the Index.
3. Close the driver's door.
4. Turn the ignition key towards you to ACCESSORY.
5. Count the number of chimes you hear. You will
hear two to four chimes depending on the features
your vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps
listed under ªExiting Programming Modeº later in
this section.
Delayed Illumination and Exit Lighting
With delayed illumination, the interior lamps will stay
on for about 25 seconds after all the doors and the
liftgate are closed.
With exit lighting, the interior lamps will come on and
stay on for about 25 seconds whenever you remove the
key from the ignition.
Programmable Modes
Mode 1: Both Features Off (The interior lamps will turn on
or off at the same instant that a door is opened or closed.)
Mode 2: Delayed Illumination Only (The interior lamps
will stay on for about 25 seconds after all the doors and
liftgate are closed, or until you lock the doors.)
Mode 3: Exit Lighting Only (The interior lamps will come
on whenever you remove the key from the ignition and stay
on for about 25 seconds, or until you lock the doors.)
Mode 4: Both Features On (This combines Modes 2 and 3.)

2-18
When your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Turn the interior lamps on by turning the instrument
panel brightness control all the way up.
3. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
4. Turn the interior lamps control off to change the
current mode.
5. Turn the interior lamps control from on to off until
you hear the number of chimes corresponding to the
mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Automatic Door Locks
With automatic door locks, all doors will automatically
lock when you shift out of PARK (P) and automatically
unlock when the ignition is turned to OFF.
Programmable Modes
Mode 1: Both Features Off (Automatic door locking and
unlocking is disabled. You will always need to lock your
doors manually before driving to increase occupant safety.)
Mode 2: Automatic Door Locking Only

The automatic door unlock feature is turned off.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
Mode 3: Automatic Unlocking with the Ignition Off

Turn off the ignition with the transaxle in PARK (P);
all doors will unlock automatically.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.

2-19
Mode 4: Automatic Unlocking with Transaxle in PARK (P)

Shift into PARK (P) with the ignition on; all doors
will unlock automatically.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
When your vehicle was shipped from the factory, it was
programmed in Mode 3. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press LOCK on the power door lock switch.
3. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)4. Press LOCK to change the current mode.
5. Press LOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Last Door Closed Locking and
Lockout Prevention
With the last door closed locking and lockout prevention
features, your vehicle will do the following:

If you leave your key in the ignition and leave the
driver's door open, you won't be able to lock the
doors using the power door lock switch.

When you press LOCK on the power door lock
switch or the optional remote keyless entry
transmitter while any door or the liftgate is open, the
doors will not lock. Instead you will hear three
chimes, that will let you know that the last door
closed locking feature is in operation. Five seconds
after all the doors and the liftgate are closed, all the
doors and the liftgate will automatically lock.

2-20
Programmable Modes
Mode 1: Both Features Off (Doors will always lock
immediately when you press LOCK on the power door lock
switch or the optional remote keyless entry transmitter.)
Mode 2: Lockout Deterrent Only (If you leave your key
in the ignition with the driver's door open, you won't be
able to lock the doors with the power door locks.)
Mode 3: Last Door Closed Locking Only (If the power
door lock switch or the optional remote keyless entry
transmitter is used to lock the vehicle while any door or
the liftgate is open, you will hear three chimes. The
doors will not lock. Five seconds after the last door is
closed, all doors and the liftgate will lock.)
Mode 4: Both Features On (This combines Modes 2 and 3.)
When your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.2. Press UNLOCK on the power door lock switch.
3. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
4. Press UNLOCK to change the current mode.
5. Press UNLOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Remote Driver's Unlock Control
With the remote driver's unlock control feature, you can
program your vehicle to do the following:

When you press UNLOCK on your remote keyless
entry transmitter, the driver's door will unlock and,

when you press UNLOCK on your remote keyless
entry transmitter again within five seconds, all doors
and the liftgate will unlock.

2-21
Programmable Modes
Mode 1: Remote All Doors Unlock (When you press
UNLOCK on your remote keyless entry transmitter, all
doors and the liftgate will unlock.)
Mode 2: Remote Driver's Door Unlock Only
(When you press UNLOCK on your remote keyless
entry transmitter once, the driver's door will unlock.
When you press UNLOCK on your remote keyless entry
transmitter again within five seconds, all doors and the
liftgate will unlock.)
When your vehicle was shipped from the factory, it was
programmed in Mode 2. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press UNLOCK on the remote keyless entry transmitter.
3. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)4. Press UNLOCK to change the current mode.
5. Press UNLOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Remote Lock and Unlock Confirmation
With the remote lock and unlock confirmation feature,
your vehicle can do the following:

When you use the remote keyless entry transmitter to
lock your vehicle, your parking lamps will flash to
let you know the command has been received. If you
press LOCK on the remote keyless entry transmitter
again, the horn will sound and the parking lamps will
flash to let you know your vehicle is locked, and

when you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash.

2-22
Programmable Modes
Mode 1: Both Features Off (Remote lock and unlock
confirmation are disabled.)
Mode 2: Exterior Lamps Flash Only

When you use the remote keyless entry transmitter to
lock your vehicle, your parking lamps will flash to
let you know the command has been received.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.
Mode 3: Exterior Lamps Flash and Horn Sound

When you use the remote keyless entry transmitter to
lock your vehicle, the horn will sound and your
parking lamps will flash to let you know the
command has been received.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.Mode 4: Exterior Lamps Flash and Horn Sound
(on second LOCK Press)

When you use the remote keyless entry transmitter to
lock your vehicle, your parking lamps will flash to let
you know the command has been received. The horn
will sound and your parking lamps will flash if you
press the LOCK button again within five seconds.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.
When your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press LOCK on the remote keyless entry transmitter.

2-23
3. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
4. Press LOCK to change the current mode.
5. Press LOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Content Theft-Deterrent System
With the content theft-deterrent system, if anyone
damages or enters your vehicle while the system is
armed, the horn will sound and your parking lamps will
flash for two minutes. The content theft shock sensor
detects if anyone damages your vehicle. The shock
sensors sensitivity can be adjusted, by your Chevrolet
dealer, if more or less sensitivity is desired.Programmable Modes
Mode 1: Damage Detection with Reduced Sensitivity
(If anyone seriously damages your vehicle or opens a
door or the liftgate while your content theft
-deterrent
system is armed, an alarm will sound and your parking
lamps will flash for up to two minutes.)
Mode 2: Damage Detection Off (If anyone opens a door
or the liftgate while your content theft
-deterrent system
is armed, an alarm will sound and your parking lamps
will flash for up to two minutes.)
Mode 3: Feature Off (Your content theft
-deterrent
system is always disarmed.)
Mode 4: Damage Detection with Normal Sensitivity
(If anyone damages or enters your vehicle while your content
theft
-deterrent system is armed, an alarm will sound and your
parking lamps will flash for up to two minutes.)
When your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
