2001 CHEVROLET CORVETTE Owners Manual

3-7
FAN SPEED: Press the button with the fan symbol
on it to manually lock in the current fan speed and to
stop the automatic fan speed control. Pressing the
arrows will delete AUTO from the digital display. The
fan graphics with the fan speed bars will be shown. To
increase the fan speed so that more air flows into the
vehicle, press the UP arrow on the fan switch. To
decrease the fan speed and airflow, press the DOWN
arrow. The AUTO button must be pressed to return to
the automatic fan control.
MODE: Press the MODE button to manually lock in the
current air delivery setting and to stop the automatic
mode control. Pressing the MODE button will delete
AUTO from the digital display and the mode graphics
will be shown. To change the setting, press the MODE
button again. The AUTO button must be pressed to
return to the automatic mode selection.
UPPER: This setting directs most of the air
through the instrument panel outlets and a very small
amount to the lower outlets.
BI-LEVEL: This setting directs air into the
vehicle in two ways. Cooler air is directed toward your
upper body through the instrument panel outlets, while
warmer air is directed through the lower outlets.
LOWER: This setting directs most of the air to
the floor area and some of it toward the windshield and
side window vents.
DEFOG: This setting divides the air between
the windshield and lower outlets and a small amount
toward the side window vents. This is useful when fog
appears on the windshield or side glass due to rain or
snowy conditions.
Function Buttons
These buttons control climate control ON/OFF, air
intake, front defrost, rear defrost and the air
conditioning operation.
OFF: Press the OFF button to turn off the climate
control system. This is the only setting that fully shuts
off the fan. The digital display will show only the
outside temperature. You can still adjust the driver set
temperature, the passenger temperature offset and the
air intake mode while in OFF.

3-8
A/C: This button turns the air conditioning
compressor off or on under most conditions. The light
on the A/C button will come on when the compressor is
operating in either the automatic or manual mode. The
air conditioning does not operate at temperatures below
approximately 35
F to 40
F (2
C to 4
C). The light
on the A/C button will flash if pressed when air
conditioning is not available. The air conditioning cools
and dehumidifies the air coming into the vehicle. The air
conditioning cannot be turned off in DEFROST and
DEFOG, as it helps to remove moisture from the
vehicle. It also helps to keep the windows clear.
If the system is operating in the AUTO mode, turning
the air conditioning off will delete AUTO from the
digital display and show current mode and fan settings.
The AUTO button must be pressed to return to the
automatic mode operation.
The air conditioning may be forced off at high engine
speeds or high engine oil or coolant temperatures. OUTSIDE AIR: Press this button to provide
outside air. The light on this air intake button will come
on to show when it is operating. When in the AUTO
mode, the system automatically selects OUTSIDE AIR
instead of recirculate, as required, to control the
temperature in the vehicle. By pressing OUTSIDE AIR,
the system will lock into the outside air mode. Any
adjustment to the air intake must then be made
manually. OUTSIDE AIR should be used when trying to
defrost or defog windows to help reduce moisture inside
of the vehicle.
RECIRCULATE: Press this button to limit the
amount of outside air entering the vehicle. The light on
this air intake button will come on to show when it is
operating. Recirculate is helpful when you are trying to
cool the air quickly or trying to limit odors and dust
from entering the vehicle. When in the AUTO mode,
the system automatically selects recirculate to cool the
vehicle's temperature. By pressing this button, the
system will lock into the recirculated air mode.
Any adjustment to the air intake must then be made
manually. Recirculation is not available when using the
defrost or defog mode because outside air is need to
reduce moisture inside of the vehicle.

3-9
Operating the system in the recirculation mode may
cause fogging of the vehicle's windows when the
weather is cold and damp. To clear the fog, switch the
system to either the DEFOG or DEFROST mode and
increase the fan speed. To avoid re
-fogging of the
windows, operate the system in the OUTSIDE
AIR mode.
FRONT: Press the FRONT defrost button to
quickly remove fog or frost from the windshield. This
setting directs most of the airflow to the windshield and
a small amount toward the lower and side window
outlets. The light on the button will come on and the
digital display will show the defrost mode symbol and
fan speed when the front defrost mode is being used.
Pressing FRONT defrost again will return the system to
the last operating mode and the air intake mode will be
in OUTSIDE AIR.
If the system is in FRONT defrost when you shut the
engine off, it will restart in FRONT defrost unless the
engine is off for longer than 40 minutes. If the engine is
off longer than 40 minutes, the system will restart in the
operating mode you had set prior to FRONT defrost and
the air intake mode will be in OUTSIDE AIR.
See ªRear Window Defoggerº later in this section for
more information.
Sensors
The automatic electronic dual climate control system
uses several sensors to control operation and
display information.
Solar Load Sensor
This sensor is located on the top right side of the
defroster grille. The defroster grille is on the top of
the instrument panel.
The sensor monitors the sun's solar radiation and uses
this information as part of the automatic climate control
system when operating in the AUTO mode.
Be careful not to put anything over the sensor. When
covered, the sensor cannot compensate for changes in
the amount of heat the vehicle is absorbing from the sun.

3-10
Outside Air Temperature Sensor
This sensor is located in the air intake under the front
bumper of the vehicle. Information from this sensor
is used for the outside air temperature readings
shown on the digital display for the automatic climate
control system.
If the outside temperature goes up, the displayed
temperature will not change until:

The vehicle's speed is above 16 mph (26 km/h) for
one and a half minutes.

The vehicle's speed is above 45 mph (72 km/h) for
one minute.
These delays help prevent false readings. If the
temperature goes down, the outside temperature display
is updated immediately.
If the vehicle has been turned off for more than three
hours, the current outside temperature will be shown
when you start the vehicle. If it has been turned off for
less than three hours, the temperature will be recalled
from the previous vehicle operation.Inside Temperature Sensor
This sensor is located to the left of the ignition switch.
The automatic climate control system uses this sensor to
receive information, so if you block or cover it, the
system will not function properly.
Air Conditioning
On very hot days, the vehicle will cool down more
quickly and economically if you open the windows long
enough to let hot inside air escape. Then keep the
windows closed in order to allow the air conditioning to
work best. Maximum cooling will occur when the
recirculate setting is operating, airflow direction is in the
upper mode, and the temperature knob (on a manual
climate control system) is turned all the way to the blue
area. These settings will be selected by the automatic
electronic dual climate control system if operating in
AUTO when maximum cooling is required.
When the air conditioning is on, you may
sometimes notice slight changes in the vehicle's engine
performance and power. This is normal. The system is
designed to help fuel economy while maintaining the
desired cooling level.
The air conditioning removes moisture from the air,
so you may notice water dripping from under the
vehicle when it is idling or after it has been turned off.
This is normal.

3-11 Heating
The heater works best if you keep the windows closed.
Maximum heating will occur when airflow direction is
in the lower mode and the temperature knob (on a
manual climate control system) is all the way in the red
area. These settings will be selected by the automatic
electronic dual climate control system if operating in
AUTO when maximum heating is required.
The BI
-LEVEL setting is designed for use on sunny
days when the air is only moderately warm or cool.
On days like these, the sun may adequately warm
your upper body, but your lower body may not be
warm enough. The BI
-LEVEL setting will direct
cooler airflow to your upper body and warmer air to the
floor area.
If you have the optional engine coolant heater and use
it during cold weather 0
F (
-18
C) or lower, the
heating system will provide heat more quickly because
the coolant is already warmed. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting
To rapidly defrost the windshield, the FRONT defrost
mode (automatic electronic dual climate control system)
or defrost mode (manual control system) should be used
and the fan speed should be adjusted to the highest
speed. With the manual control system, turn the
temperature knob all the way to the red area.
To keep the windshield clear and provide heated air to
the floor area of the vehicle, use the DEFOG setting.
Your vehicle is equipped with side window defogger
vents located near the side rearview mirrors.
Rear Window Defogger
REAR: This button turns the rear defogger and the
heated outside mirrors on. The light on the button will
come on when operating. The system automatically
shuts off after approximately 15 minutes. If further
defogging is desired, press the button again and it will
operate for about seven and a half more minutes.
The rear window defogger operates only when the
engine is running.

3-12
The rear window defogger uses a warming grid to
remove fog from the rear window. Do not attach
anything like a temporary vehicle license or a decal
across the defogger grid on the rear window.
NOTICE:
Don't use a razor blade or something sharp on
the inside of the rear window. If you do, you
could cut or damage the warming grid, and
repairs wouldn't be covered by your warranty.
Ventilation System
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the fan is running.
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of the windows.
When you enter a vehicle in cold weather, turn the
fan to the highest speed for a few moments before
driving off. This helps clear the intake outlets of
snow and moisture, and reduces the chance of
fogging the inside of the windows.

Keep the area around the base of the center instrument
panel console and air path under the seats clear of
objects. This helps air circulate throughout the vehicle.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is off. See ªRetained
Accessory Powerº in the Index.
Setting the Clock
Press and hold HR until the correct hour appears.
Press and hold MN until the correct minute appears.

3-13 AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control
Your vehicle is equipped with six Bose
amplified
speakers. See your dealer for details.
Playing the Radio
PWR VOL: Press this knob to turn the system on and
off. To increase volume, turn the knob clockwise. Turn
it counterclockwise to decrease volume. The knob is
capable of turning continuously.
RECALL: Press this button to recall the station being
played. If you press the button when the ignition is off,
the clock will show for a few seconds.SCV: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Then, as you drive,
SCV automatically increases the volume, as necessary,
to overcome noise at any particular speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, turn the control all the
way down. Each notch on the control ring allows for
more volume compensation at faster vehicle speeds.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it.
SEEK: Press the right or left arrow to go to the
next higher or lower station. The sound will mute
while seeking.

3-14
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear in the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press SEEK again to stop scanning. The sound
will mute while scanning.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the equalization that
best suits the type of station selected.
5. Press and hold one of the six numbered buttons. The
sound will mute. When it returns, release the button.
Whenever you press that numbered button, the
station you set will return and the AUTO TONE
equalization that you selected will also be
automatically selected for that button.
6. Repeat the steps for each pushbutton.P.SCAN: Press this button to listen to each of your
favorite stations stored on your pushbuttons for a few
seconds. The radio will scan through each of the stations
stored on your pushbuttons, except those stations with
weak reception. The AUTO TONE setting stored for that
pushbutton will be automatically chosen. Press P.SCAN
or one of the pushbuttons again to stop scanning. P.SCAN
will be displayed whenever the tuner is in the P.SCAN
mode. The channel number (P1 through P6) will appear
momentarily just before the frequency is displayed. In
FM mode, this function will scan through both FM1 and
FM2 preset stations and FM1 or FM2 will appear on
the display.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank.
