2001 CHEVROLET CORVETTE Owners Manual

2-115
The HUD controls are located to the left of the
steering wheel.To adjust the HUD so you can see it properly:
1. Start your engine and slide the HUD dimmer control
all the way up.
The brightness of the HUD image is determined by
the light conditions in the direction your vehicle is
facing and where you have the HUD dimmer control
set. If you are facing a dark object or a heavily
shaded area, your HUD may anticipate that you are
entering a dark area and may begin to dim.
It is possible for sunlight to enter the HUD causing
all of the graphics to light up. The display will return
to normal when the sunlight is no longer entering
the HUD.
2. Adjust the seat to your driving position. If you
change your seat position later, you may have to
re
-adjust your HUD.
3. Press the DISPLAY switch up or down to center the
HUD image in your view.
The HUD image can only be adjusted up and down,
not side
-to-side.
4. Slide the dimmer control downward until the HUD
image is no brighter than necessary. To turn HUD
off, slide the switch to OFF.

2-116
If the sun comes out or it becomes cloudy, you may need
to adjust the HUD brightness again using the dimmer
control. Polarized sunglasses could make the HUD
image harder to see.
To change from English to metric units, push the
E/M button located to the right of the steering wheel.
Clean the inside of the windshield as needed to remove
any dirt or film that reduces the sharpness or clarity of
the HUD image.
To clean the HUD, spray household glass cleaner on a
soft, clean cloth. Wipe the HUD lens gently, then dry it.
Do not spray cleaner directly on the lens because the
cleaner could leak into the unit.If the ignition is on and you can't see the HUD image,
check to see if:

Something is covering the HUD unit.

The HUD dimmer control is adjusted properly.

The HUD image is adjusted to the proper height.

Ambient light (in the direction your vehicle is
facing) is low.

A fuse is blown. See ªFuses and Circuit Breakersº in
the Index.
Keep in mind that your windshield is part of the HUD
system. If you ever have to have your windshield
replaced, be sure to get one that is designed for HUD or
your HUD image may look blurred and out of focus.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Manual Comfort Controls
3
-4 Automatic Electronic Dual Climate
Control System (Option)
3
-9 Sensors
3
-10 Air Conditioning
3
-11 Heating
3
-11 Defogging and Defrosting
3
-11 Rear Window Defogger
3
-12 Audio Systems
3
-12 Setting the Clock
3
-13 AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control3
-18 AM-FM Stereo with Compact Disc Player and
Automatic Tone Control (Option)
3
-22 Trunk-Mounted CD Changer (Option)
3
-27 Theft-Deterrent Feature
3
-29 Understanding Radio Reception
3
-29 Tips About Your Audio System
3
-30 Care of Your Cassette Tape Player
3
-31 Care of Your Compact Discs
3
-31 Care of Your Compact Disc Player
3
-31 Fixed Mast Antenna (Z06)
3
-32 Power Antenna Mast Care (Convertible)
3
-32 Integrated Windshield and Rear Window
Antennas (Coupe)

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
With these systems, you can control the heating, cooling
and ventilation in your vehicle. Your vehicle also has
a flow
-through ventilation system described later in
this section.
Manual Comfort Controls
Fan Knob
The left knob controls the force of air you want.
Turn the knob clockwise to increase fan speed or
counterclockwise to decrease fan speed. The fan must be
turned on for the air conditioning compressor to operate.Temperature Knob
The center knob controls the temperature of the air
coming through the system. Turn it counterclockwise
(toward the blue area) for cooler air. Turn it clockwise
(toward the red area) for warmer air.
Mode Knob
The right knob selects the location of where the air will
enter the vehicle.
UPPER: This setting directs most of the air
through the instrument panel outlets with a very small
amount of air directed to the lower outlets.
BI-LEVEL: This setting directs air into the
vehicle in two ways. Cooler air is directed toward your
upper body through the instrument panel outlets, while
warmer air is directed through the lower outlets.
LOWER: This setting directs most of the air
through the lower ducts to the floor area of the vehicle
with some of the air also directed toward the windshield
and side window vents.

3-3
DEFOG: This setting divides the air between the
windshield and lower outlets with a small amount of air
directed toward the side window vents. This is useful
when fog appears on the windshield or side glass due to
rain or snowy conditions.
DEFROST: Use this setting to quickly remove fog
or frost from the windshield. This setting directs most of
the airflow to the windshield with a small amount of air
directed toward the lower and side window outlets.
Mode Buttons
These buttons control the air intake, the air conditioning
and the rear window defogger operation.
OUTSIDE AIR: Press this button and it
will bring outside air into the vehicle. The light on the
button will come on when operating. Use this setting
while trying to defrost or defog windows to help
clear moisture.
RECIRCULATE: Press this button to limit the
amount of outside air entering the vehicle by
recirculating most of the air inside the vehicle. The light
on the button will come on when operating. This setting
is helpful when you are trying to cool the air quickly or
to limit odors entering the vehicle. Recirculate cannot be
used while in the DEFROST or DEFOG modes.Operating the system in the recirculation mode may
cause fogging of the vehicle's windows when the
weather is cold and damp. To clear the fog, switch the
system to either the DEFOG or DEFROST mode and
increase the fan speed. To avoid re
-fogging of the
windows, operate the system in the OUTSIDE
AIR mode.
A/C: This button turns the air conditioning
compressor off or on under most conditions. The light
on the A/C button comes on when the compressor is
operating. The air conditioning does not operate at
temperatures below approximately 35
F to 40
F
(2
C to 4
C). The air conditioning cools and
dehumidifies the air coming into the vehicle. The air
conditioning cannot be turned off in DEFROST, as it
helps to remove moisture from the vehicle. It also helps
to keep the windows clear.
The air conditioning may be forced off at high engine
speeds or high engine oil or coolant temperatures.
See ªRear Window Defoggerº later in this section for
more information.

3-4 Automatic Electronic Dual Climate
Control System (Option)
Your vehicle may be equipped with an Automatic
Electronic Dual Climate Control System. This system
can automatically adjust and control temperature output,
fan speed, air delivery mode, air conditioning operation
and air intake. You can use the AUTO (automatic)
setting or override the automatic operation with manual
control settings. The set temperature will be
remembered each time you turn the ignition off and
restart in the same settings. You can use the memory
option to recall your settings. See ªMemoryº in
the Index.Digital Display
The digital display shows readings in Fahrenheit or
Celsius by pressing the E/M button (English/Metric) on
the Driver Information Center (DIC). When you start
the vehicle, the display will show the current fan speed,
air delivery mode and the driver
-set temperature
for approximately five seconds and then show the
outside temperature.
When the system is fully in the automatic mode, the
word AUTO will also appear on the display unless you
are in full cold 60
F (16
C) or full hot 90
F (32
C),
then the word AUTO will not display. If you have
selected a manual fan speed, then the fan symbol will
appear on the display. If a manual air delivery mode has
been selected, the delivery mode symbol will appear on
the display.
Driver Set Temperature Knob
The DRIVER knob changes the temperature on the
driver's and passenger's side of the vehicle. Turn the
knob clockwise to increase the temperature and
counterclockwise to decrease the temperature.
Whenever you turn this knob, the temperature will be
displayed for approximately five seconds along with the
current fan speed and air delivery mode.

3-5
When adjusting the temperature, start with a driver-set
temperature of 73
F (23
C) until you determine
your comfort zone. If you choose 60
F (16
C), the
system will remain at maximum cooling and will not
automatically adjust fan speed or air delivery. If you
choose 90
F (32
C), the system will remain at
maximum heating and will not automatically adjust fan
speed or air delivery. Choosing either maximum setting
will not cause the system to heat or cool any faster.
Turning the knob past either maximum setting has no
effect on the operation of the system.
Passenger Temperature Offset
The PASSENGER knob changes the temperature on the
passenger's side of the vehicle. When the knob is in the
12 o'clock position, the passenger's temperature is the
same as the driver's. Turn the knob clockwise for warmer
air on the passenger's side, counterclockwise for cooler air.
If the driver
-set temperature is set at 60
F (16
C) or
90
F (32
C), turning the passenger knob has no effect
because the system is locked at a maximum setting.Automatic Operation
Press the AUTO button to place the entire system in the
automatic mode. After a five
-second display of the
current settings, only the word AUTO and the outside
temperature will be shown on the digital display unless
you are in full cold 60
F (16
C) or full hot 90
F
(32
C), then the word AUTO will not display. The
system will operate to achieve your comfort set
temperature as quickly as possible. The AUTO control
system works best with the windows up and the
removable roof installed or the convertible top up.
A Typical Cold Weather Example:
Your vehicle has been parked outside overnight in cold
weather below 32
F (0
C) and you have set the
driver temperature at 73
F (23
C) and have selected
the AUTO mode. The system will automatically adjust
the temperature output to maximum heating. The fan
will start at a low speed. This is to avoid blowing cold
air into the vehicle. The length of the delay depends on
the amount of time since the engine was last started, the
outside temperature and the engine coolant temperature.
As the coolant warms up, the fan speed will gradually
increase. Air will flow to the floor with some air to
the windshield to prevent fogging under most
normal conditions.

3-6
As the interior of the vehicle warms up to your comfort
set temperature, the fan speed will decrease and the
temperature output may become cooler. If the interior
temperature continues to warm up due to heating from
the sun or outside temperature increases, the system
may switch to other air delivery modes (typically
DEFOG or BI
-LEVEL).
A Typical Hot Weather Example:
The vehicle has been parked outside all day in hot
weather above 80
F (27
C) and you have set the driver
temperature at 73
F (23
C) and have selected the
AUTO mode. The system will automatically adjust the
temperature output to maximum cooling. The fan will
start at a low speed momentarily to push the hot air to
the floor of the vehicle and then go to a higher fan speed
with cold airflow out of the instrument panel outlets. A
small amount of airflow will continue through the lower
ducts to cool the floor area.The air intake may start in the recirculated mode for
maximum cooling performance. As the interior of the
vehicle cools down to your comfort set temperature,
the fan speed will decrease and the temperature output
may become warmer. The air intake may shift from
recirculation to outside air mode. If the interior
continues to cool due to a decrease in the amount of heat
the vehicle is absorbing from the sun or a decrease in the
outside temperature, the system could switch to other air
delivery modes (typically BI
-LEVEL or DEFOG).
Manual Settings
With the automatic electronic dual climate control
system, there are several manual settings you can use to
control the system and override the AUTO operation.
You can program the fan speed, air delivery mode, air
intake mode and control the air conditioning operation
using these settings. The system will still determine the
temperature output level based on the driver
-set
temperature and the passenger temperature offset.
