2001 CHEVROLET CORVETTE Owners Manual

2-107
SERVICE RIDE CONTROL: This message is
used to indicate to the driver that the Selective Real Time
Damping (SRTD) system has detected a malfunction and
that the system must be serviced. The SERVICE RIDE
CONTROL message will always come on when a failure
is detected by the Selective Real Time Damping (SRTD)
system. If a fault is present in the SRTD which causes the
shocks to be in their full soft condition, the SERVICE
RIDE CONTROL, SHOCKS INOPERATIVE and
MAXIMUM 80 MPH (129 km/h) will display together.
You will never get a SHOCKS INOPERATIVE and
MAXIMUM SPEED 80 MPH (129 km/h) message
without a SERVICE RIDE CONTROL message.
SHOCKS INOPERATIVE: You will hear four chimes
when this message is displayed. To acknowledge that
you have read the message and to remove it from the
display, press RESET. The message will reappear every
10 minutes until this condition changes.
This message indicates that a malfunction is present in the
Selective Real Time Damping (SRTD) system which is
causing the shocks to be in their full soft mode. This is a
warning to the driver that the vehicle handling may be
affected. Have your vehicle serviced as soon as possible.MAXIMUM SPEED 80 MPH (129 km/h): You will
hear four chimes when this message is displayed. To
acknowledge the warning, press RESET. After you press
RESET, a message will reappear every 10 minutes until
this condition changes.
This message indicates that the vehicle speed will be
limited to 80 mph (129 km/h) when the shock absorber
system has failed and the shocks are in their full soft
mode. Have your vehicle serviced as soon as possible.
COOLANT OVER TEMP: You will hear four chimes
and the CHECK GAGES telltale will come on when this
message is displayed. To acknowledge the warning,
press the RESET button. After you press the RESET
button, a message will be displayed and you will hear a
chime every minute until this condition changes. If you
do not press RESET, the message will remain on the
digital display until the condition changes.
If the engine coolant exceeds 255
F (124
C), this
message is displayed. If you have been operating your
vehicle under normal driving conditions, you should
pull off from the road, stop your vehicle and turn off the
engine as soon as possible. You can monitor the coolant
temperature with the GAGES button on the DIC or the
engine coolant gage on the instrument panel cluster. See
ªEngine Overheatingº in the Index.

2-108
REDUCE ENGINE RPM: You will hear four chimes
when this message is displayed. To acknowledge the
warning, press the RESET button. After you press the
RESET button, a message will be displayed and you
will hear a chime every minute until this condition
changes. If you do not press RESET, the message will
remain on the digital display until the condition changes.
If the engine oil temperature exceeds 320
F (160
C),
this message is displayed. You should check the engine
coolant temperature and engine oil level. If your engine
is too hot, see ªEngine Overheatingº in the Index. Your
vehicle may need service, so see your dealer. You can
monitor the oil temperature with the GAGES button on
the DIC.
HIGH TRANS TEMP (Automatic Transmission
Only): You will hear four chimes when this message is
displayed. To acknowledge this warning, press the RESET
button. After you press the RESET button, the message
will be displayed every 10 minutes until the condition
changes. If you do not press RESET, the message remains
on the display until the condition changes.
If the transmission fluid temperature rises above
270
F (132
C) or rises rapidly, this message is
displayed. The transmission may shift gears or apply the
torque converter clutch to reduce the fluid temperature.
Driving aggressively or driving on long hills can causethe transmission fluid temperature to be higher than
normal. If this message appears, you may continue to
drive at a slower speed. You should also monitor the
transmission fluid temperature and allow it to cool to at
least 230
F (110
C). The transmission fluid temperature
can be monitored with the GAGES button on the DIC.
See ªAutomatic Transmission Fluidº in the Index. You
should also check the engine coolant temperature. If it is
also hot, see ªEngine Overheatingº in the Index.
If the HIGH TRANS TEMP message is displayed during
normal vehicle operation on flat roads, your vehicle may
need service. See your dealer for an inspection.
SERVICE ACTIVE HANDLING: If the SERVICE
ACTIVE HNDLG message is displayed, there is a
problem with your Active Handling System and your
vehicle needs service. The instrument cluster light will
also be on and a chime will sound. When this message is
displayed, the system is not working. Adjust your
driving accordingly.
ACTIVE HANDLING: Your vehicle is equipped with
a computer controlled system to assist the driver in
controlling the vehicle in difficult driving conditions.
You may feel or hear the system working and see the
ACTIVE HANDLING message displayed in the DIC.
This is normal when the system is operating. Also see
ªAnti
-Lock Brakesº in the Index.

2-109
LOW TIRE PRESSURE: (Except Z06)
You will hear two chimes when this message is
displayed. To acknowledge the warning, press RESET.
After you press RESET, a message will appear every
10 minutes until this condition changes. This message
indicates that the pressure in one of your tires is less
than 25 psi (172 kPa). Next to the LOW TIRE
PRESSURE message, you can see either LF (left front),
LR (left rear), RF (right front) or RR (right rear) to
indicate to you which tire is low on pressure. You can
receive more than one tire pressure message at a time.
To read other messages that may have been sent at the
same time, press RESET. If a tire pressure message
appears on the DIC, stop as soon as you can. Have the
tire pressures checked and set to those shown on your
Tire Loading Information Label. See ªExtended
Mobility Tiresº and ªTire Pressure Monitorº in
the Index.
CAUTION:
When the LOW TIRE PRESSURE or FLAT
TIRE message is displayed on the Driver
Information Center, your vehicle's handling
capabilities will be reduced during severe
maneuvers. If you drive too fast, you could lose
control of your vehicle. You or others could be
injured. Don't drive over 55 mph (90 km/h) when
the LOW TIRE PRESSURE or FLAT TIRE
message is displayed. Drive cautiously, and check
your tire pressures as soon as you can.

2-110
FLAT TIRE: (Except Z06) You will hear two chimes
when this message is displayed followed by the message
MAX SPEED 55 MPH (90 km/h). If this message
appears, do not drive your vehicle above these limits.
The next message to appear is REDUCED HANDLING.
Adjust your driving accordingly. To acknowledge these
warnings, press RESET. After you press RESET, a
message will reappear every 10 minutes until this
condition changes. This message indicates that the
pressure in one of your tires is lower than 5 psi (34 kPa).
Next to the FLAT TIRE message, you can see either
LF (left front), LR (left rear), RF (right front) or
RR (right rear) to indicate to you which tire is flat.
You can receive more than one tire pressure message at
a time. To read other messages that may have been sent
at the same time, press RESET. If a tire pressure
message appears on the DIC, stop as soon as you can.
Have the tire pressures checked and set to those shown
on your Tire Loading Information Label. See ªExtended
Mobility Tiresº and ªTire Inflationº in the Index.
CAUTION:
When the LOW TIRE PRESSURE or FLAT
TIRE message is displayed on the Driver
Information Center, your vehicle's handling
capabilities will be reduced during severe
maneuvers. If you drive too fast, you could lose
control of your vehicle. You or others could be
injured. Don't drive over 55 mph (90 km/h) when
the LOW TIRE PRESSURE or FLAT TIRE
message is displayed. Drive cautiously, and check
your tire pressures as soon as you can.

2-111
HIGH TIRE PRESSURE - (LF, LR, RF, RR)
(Except Z06): You will hear two chimes when this
message is displayed. To acknowledge the warning,
press RESET. After you press RESET, a message will
reappear every 10 minutes until this condition changes.
This message indicates that the pressure in one of your
tires is higher than 42 psi (290 kPa). Next to the
HIGH TIRE PRESSURE message, you can see either
LF (left front), LR (left rear), RF (right front) or
RR (right rear) to indicate to you which tire is higher
than 42 psi (290 kPa). You can receive more than one
tire pressure message at a time. To read other messages
that may have been sent at the same time, press RESET.
If a tire pressure message appears on the DIC, stop as
soon as you can. Have the tire pressures checked and set
to those shown on your Tire Loading Information Label.
See ªExtended Mobility Tiresº and ªTire Inflationº in
the Index.SERVICE TIRE MON SYS (Except Z06): If this
message comes on, a part on the Tire Pressure Monitor
(TPM) is not working properly. If you drive your
vehicle while any of the four sensors are missing or
inoperable, the warning will come on in approximately
10 minutes. If all four sensors are missing, the warning
will come on in approximately 15 to 20 minutes. (All
the sensors would be missing, for example, if you put
different wheels on your vehicle without transferring the
sensors.) If the warning comes on and stays on, there
may be a problem with the TPM. See your dealer.

2-112
Other Messages
Here are more messages that you can receive on your
Driver Information Center (DIC). To acknowledge a
message and read another message that may have come
on at the same time, press the RESET button.

BRAKE BEFORE SHIFT
(Automatic Transmissions Only)

CHANGE OIL NOW (See ªGM Oil Life Systemº
in the Index.)

CHANGE OIL SOON (See ªGM Oil Life Systemº
in the Index.)

CRUISE DISENGAGED (See ªCruise Controlº in
the Index.)

CRUISE SET __ MPH (__ km/h)
(See ªCruise Controlº in the Index.)

DOOR AJAR
ENGINE PROTECTION REDUCE ENGINE RPM

HATCH AJAR (Coupe)

HIGH VOLTAGE (See ªVoltmeterº in the Index.)

LOW BRAKE FLUID
(See ªBrake Fluidº in the Index.)

LOW FUEL (See ªFuel Gageº in the Index.)

LOW VOLTAGE (See ªVoltmeterº in the Index.)

LOW WASHER FLUID (See ªWindshield Washer
Fluidº in the Index.)

RESERVE FUEL (See ªFuel Gageº in the Index.)

TONNEAU AJAR (Convertible)

TRUNK AJAR (Convertible/Z06)

UPSHIFT NOW
(See ªManual Transmissionº in the Index.)

2-113
Head-Up Display (Option)
CAUTION:
If the HUD image is too bright, or too high in
your field of view, it may take you more time to
see things you need to see when it's dark outside.
Be sure to keep the HUD image dim and placed
low in your field of view.
If your vehicle is equipped with the Head-Up Display
(HUD), you can see some of the driver information that
appears on your instrument panel cluster.The information may be displayed in English or metric
units and appears as an image focused out toward the
front of your vehicle. The HUD consists of the
following information:

Speedometer

Turn Signal Indicators

High
-Beam Indicator Symbol

Tachometer

Oil, Temperature and Fuel Gages

Shift Light (Performance SHIFT Light)
This light is used for performance driving to indicate
that the vehicle's best performance level has been
reached to shift the transmission into the next higher
gear. The SHIFT light will display at an engine
speed of about 5,750 rpm, just prior to reaching the
engine fuel cut
-off mode. To better understand the
vehicle's power curves, see ªCapacities and
Specificationsº in the Index.

Check Gages Icon

2-114
There are five HUD selections that you can choose to
view in the HUD display. By pressing and holding the
PAGE button, you can scroll through these pages in the
following order:

Speed Only

Speed and Gage

Speed, Tachometer and Gage

Speed and Tachometer

Tachometer Only
When you have chosen the desired HUD display, release
the PAGE button.
Gages can be scrolled through by tapping the PAGE
button (only when a gage is displayed). The gages
shown are the following:

Oil Pressure

Coolant Temperature

Fuel Level
The selections that you choose will remain in the
HUD display until they are changed.
Be sure to continue scanning your displays, controls and
driving environment just as you would in a vehicle
without HUD. If you never look at your instrument
panel cluster, you may not see something important,
such as a warning light. Under important warning
conditions, the CHECK GAGES icon will illuminate in
the HUD. View your Driver Information Center (DIC)
for more information.
