2001 CHEVROLET CORVETTE Owners Manual

2-99
Remember, you must reset the OIL LIFE yourself after
each oil change. It will not reset itself. Also, be careful
not to reset the OIL LIFE accidentally at any time other
than when the oil has just been changed. It can't be reset
accurately until the next oil change.
To reset the system, see ªHow to Reset the Change Oil
Soon Messageº in the Index.
Also, see ªEngine Oil, When to Changeº and
ªMaintenance Scheduleº in the Index.
4 OPTIONS
This button allows you to choose personal options that
may be available on your vehicle, depending on the
options your vehicle is equipped with. Some of these
functions work along with the remote keyless
entry transmitter.
When returning to the options menu, the first item of the
options list will always be displayed, not the one you
were last in when you changed buttons.
The following are the options listed under the
OPTIONS button:
Twilight (Optional, Standard in Canada)
Press the OPTIONS button until TWILIGHT
- OFF
appears on the display, then use the RESET button to
page through the following selections:

TWILIGHT
- ON

TWILIGHT
- OFF

2-100
If you choose TWILIGHT - ON, press the OPTIONS
button again to display DELAY TIME 1 2 in the DIC.
Use the OPTIONS button to switch between delay time
1 and 2. You can increase the delay time by pressing
button 1 (1 FUEL) or decrease the time by pressing
button 2 (2 GAGES). Each bar is equal to 12 seconds.
Lock and Arm
Press the OPTIONS button until LOCK & ARM
appears on the display, then use the RESET button to
page through the following selections:

LOCK & ARM
- OFF

LOCK & ARM
- HORN ONLY

LOCK & ARM
- LIGHTS ONLY

LOCK & ARM
- HORN & LIGHTS
If you choose LOCK & ARM
- OFF, you will receive no
security feedback when locking or unlocking your vehicle.
If you choose LOCK & ARM
- HORN ONLY, only the
horn will chirp to let you know when your alarm system
has armed when locking your vehicle.If you choose LOCK & ARM
- LIGHTS ONLY, only
your exterior lamps will flash to let you know when your
alarm system has armed when locking your vehicle.
If you choose LOCK & ARM
- HORN & LIGHTS, the
horn will chirp and the exterior lamps will flash briefly
to let you know the system has armed when locking
your vehicle.
Alarm
Press the OPTIONS button until ALARM appears on
the display, then use the RESET button to page through
the following selections:

ALARM
-HORN

ALARM HORN & LIGHTS
If you choose ALARM
-HORN, the horn will sound
during an alarm.
If you choose ALARM HORN & LIGHTS, the horn
will sound and the interior and exterior lamps will flash
during an alarm.

2-101
Approach Lights
Press the OPTIONS button until APPROACH LIGHTS
appears on the display, then use the RESET button to
page through the following choices:

APPROACH LIGHTS ON

APPROACH LIGHTS OFF
If you choose APPROACH LIGHTS ON, the fog lamps,
front turn signal, rear back
-up and courtesy lamps will
come on for 30 seconds when you press UNLOCK on
the remote keyless entry transmitter. This will occur
only when it is dark outside.
APPROACH LIGHTS OFF turns off this option.
See ªRemote Keyless Entry (RKE) Systemº in the Index
for more information.
Auto Lock
Press the OPTIONS button until AUTO LOCK appears
on the display, then use the RESET button to page
through the following choices:

AUTO LOCK ON

AUTO LOCK OFFIf you choose AUTO LOCK ON, both doors will
automatically lock when the vehicle exceeds 10 mph
(16 km/h) in a manual transmission. In a vehicle with an
automatic transmission, both doors will automatically
lock when you move the shift lever out of PARK (P).
Choose AUTO LOCK OFF to turn this option off.
Auto Unlock
The AUTO UNLOCK will be available only if AUTO
LOCK is set to ON as described previously.
Press the OPTIONS button until AUTO UNLOCK
appears on the display, then use the RESET button to
page through the following choices:

AUTO UNLOCK DRIVER

AUTO UNLOCK BOTH

AUTO UNLOCK OFF
If you choose AUTO UNLOCK DRIVER, the driver's
door will automatically unlock when you turn the
vehicle off and pull the key out of the ignition.
Choose AUTO UNLOCK BOTH, and both doors will
automatically unlock when you turn the vehicle off and
pull the key out of the ignition.
AUTO UNLOCK OFF turns off this option.

2-102
Easy Entry
The easy entry feature will only be available if the
vehicle is equipped with the memory option.
Press the OPTIONS button until SEAT EASY ENTRY
appears on the display, then use the RESET button to
page through the following choices:

SEAT EASY ENTRY ON

SEAT EASY ENTRY OFF
If you choose SEAT EASY ENTRY ON, when you turn
the ignition off and remove the key, the seat will
automatically move back and the telescopic steering
wheel (if equipped) will return to its full
-forward
position for an easy exit or an easy entrance when
returning to the vehicle.
SEAT EASY ENTRY OFF turns off this option.
Languages
You can select which language the DIC will display its
messages. Press the OPTIONS button until the word
LANGUAGES appears on the display, then use the
RESET button to page through the following choices:

LANGUAGE ENGLISH

LANGUAGE FRENCH
LANGUAGE GERMAN

LANGUAGE SPANISH
Blank Page
There is a blank page at the end of the OPTIONS menu.
When the blank page is displayed, you can access the
following items:
FOB TRAINING: This option allows you to match the
RKE transmitter(s) to your vehicle. You can access this
option by pressing and holding RESET for three
seconds while you are on the blank page at the end of
the OPTIONS menu. The message FOB TRAINING
will be displayed. See ªMatching Transmitter(s) To Your
Vehicleº in the Index for more information.
TIRE TRAINING (Except Z06): The Tire Pressure
Monitor (TPM) operates with battery
-powered sensors that
are located inside the valve stems on each tire. Each sensor
has a unique ID code so the vehicle knows the tire location
of the sensor. When the vehicle reaches a speed of greater
than 15 mph (24 km/h), the sensors begin to send the tire
pressure readings to a receiver inside the vehicle. These
readings are displayed when using the GAGES button on
the DIC. If you are unable to display your tire pressures
while the vehicle speed is greater than 15 mph (24 km/h),
you may need to have your sensor ID codes learned by the
vehicle. See your dealer.

2-103 DIC Warnings and Messages
The following messages and warnings may appear in the
DIC display. The DIC display area is located in the
instrument panel cluster below the speedometer and
tachometer, directly above the steering column. You may
receive more than one message at a time. Messages will
appear one behind the other. To acknowledge a message
and remove it from the display, press RESET. You may
scroll through the messages that may have been sent at the
same time. The message center is continuously updated
with the vehicle performance status.
ABS ACTIVE (Anti
-Lock Brake System Active):
When your anti
-lock system is adjusting brake pressure
to help avoid a braking skid, the ABS ACTIVE message
will be displayed.
Slippery road conditions may exist if this message is
displayed, so adjust your driving accordingly. The
message will stay on for a few seconds after the system
stops adjusting brake pressure.
ACT HNDLG
- WARMING UP: When you first start
your vehicle (especially during cold winter weather),
and begin to drive away (up to 6 mph (10 km/h)), the
message ACT HNDLG
- WARMING UP may be
displayed in the DIC, the instrument panel cluster light
will be on, and a chime will sound. This is normal.
You can acknowledge this message by pressing theRESET button. The Active Handling System
performance is affected until the next message WARM
UP COMPLETE is displayed in the DIC.
During hot or cold temperature conditions, this message
may be displayed in the DIC after exceeding 12 mph
(20 kph) for 30 seconds. The Active Handling System is off
until the WARM UP COMPLETE message is displayed.
WARM UP COMPLETE: If you receive this message
and hear a chime, the system has completed the
functional check of the Active Handling System.
TRAC/ACT HNDLG
- ON: If the Traction Control and
Active Handling Systems are off, depressing the Active
Handling System console button momentarily will turn
both systems on. The message TRAC/ACT HNDLG
- ON
will be displayed temporarily in the DIC, the instrument
panel cluster light will be off and a chime will sound.
TRAC/ACT HNDLG
- OFF: By pressing the Active
Handling System console button briefly, the driver can
turn the Traction Control and Active Handling Systems
off. The message TRAC/ACT HNDLG
- OFF will be
displayed in the DIC, the instrument panel cluster light
will be on and a chime will sound. You can acknowledge
this message by pressing the RESET button. The anti
-lock
brake systems remains on with the Traction Control and
Active Handling Systems off. You should adjust your
driving accordingly.

2-104
COMPETITIVE DRIVING: When the Competitive
Driving mode is selected, this message will be displayed
in the DIC. The instrument panel cluster light will not be
on when the Competitive Driving mode is selected. The
Traction Control System will not be operating while in
the Competitive Driving mode. You should adjust your
driving accordingly.
SERVICE ABS (Anti
-Lock Brake System): If the
SERVICE ABS message is displayed when you are driving,
stop as soon as possible and turn the ignition off. Then start
the engine again to reset the system. If the message stays
on, or comes back on again while you are driving, your
vehicle is in need of service. If the regular brake system
warning light isn't on, you still have brakes, but don't have
anti
-lock brakes. If the regular brake system light is also on,
you don't have anti
-lock brakes and there is a problem with
your brakes. See ªBrake System Warning Lightº earlier in
this section.
If the SERVICE ABS message is being displayed, your
traction control system and the optional active handling
system will also be disabled. The driver information
center will scroll three messages: SERVICE ABS,
SERVICE TRACTION SYS and SERVICE ACTIVE
HNDLG, and the instrument cluster car icon will be
illuminated. The driver can acknowledge these messages
by pressing the reset button three times. When the service message is displayed the computer
controlled systems will not assist the driver and you
should have the system repaired as soon as possible.
Adjust your driving accordingly.
SERVICE COLUMN LOCK
(Manual Transmission Only): If the system that
controls the locking and unlocking of the steering
column does not work properly, have the vehicle towed
to a dealer for service.
PULL KEY
- WAIT 10 SEC: If this message comes on,
the steering column lock system has detected a problem
while engaging the steering column lock. This message may
occur when the ignition key is removed and reinserted
before the steering column lock system fully locks or
unlocks the steering column. To acknowledge that you have
read this message, and to clear it from the display, remove
the ignition key and wait 10 seconds before reinserting the
key into the ignition. If you attempt to operate your vehicle
without removing the key for 10 seconds, the vehicle's fuel
system will shut off when you reach 1.5 mph (2.4 km/h).
If the message stays on after removing the key and waiting
10 seconds, have your vehicle taken to an authorized dealer
as soon as possible for diagnosis and repair.

2-105
LOW OIL PRESSURE: You will hear four chimes and
the CHECK GAGES telltale will come on when this
message is displayed. To acknowledge the warning,
press the RESET button. After you press the RESET
button, a message will be displayed and you will hear a
chime every minute until the vehicle is serviced. If you
do not press RESET, the message will remain on the
digital display until the vehicle is serviced.
Low oil pressure may be the result of a combination of
low oil level and abrupt changes in the vehicle's
direction. When this warning is displayed, you should
not operate the engine at high rpm or make fast abrupt
moves. As soon as possible, you should check the oil
level. See ªEngine Oilº in the Index.
LOW OIL LEVEL: Press RESET to acknowledge that
you have read the message and to remove it from the
display. The message will reappear every 10 minutes
until this condition changes.
You will hear two chimes when this message is
displayed. If this message appears after starting your
engine, your engine oil level may be too low. You may
need to add oil. See ªEngine Overheatingº in the Index.REDUCED ENGINE POWER: You will hear chimes
continuously when this message is displayed. To
acknowledge that you have read the message and to
remove it from the display, press RESET.
The message will reappear every 15 seconds until this
condition changes.
If the Driver Information Center (DIC) displays the
REDUCED ENGINE POWER message and the
CHECK ENGINE light comes on, a noticeable
reduction in the vehicle's performance may occur. If the
REDUCED ENGINE POWER message is displayed but
there is no reduction in performance, proceed to your
destination. The performance may be reduced the next
time the vehicle is driven.
The vehicle may be driven at a reduced speed while the
REDUCED ENGINE POWER message is displayed,
but acceleration and speed may be reduced. Anytime the
CHECK ENGINE light stays on, the vehicle should be
taken to an authorized Chevrolet dealer as soon as
possible for diagnosis and repair.
Also, refer to ªMalfunction Indicator Lampº
(Check Engine Light) in the Index. If the REDUCED
ENGINE POWER message is displayed in combination
with the COOLANT OVER TEMP message, see
ªEngine Overheatingº in the Index.

2-106
SERVICE VEHICLE SOON: If this message appears
on the DIC, there may be an electrical or another system
problem with your vehicle. Have your vehicle checked
by your dealer if this message keeps appearing.
CHARGE SYSTEM FAULT: Press RESET to
acknowledge that you have read the message and to
remove it from the display. The message will reappear
every 10 minutes until this condition changes. You will
hear two chimes when this message is displayed.
If this message comes on while you are driving, you may
have a problem with the electrical charging system. It
could indicate that you have a loose or broken drive belt or
another electrical problem. Have it checked right away.
Driving while this light is on could drain your battery.
If you must drive a short distance with the message on,
be certain to turn off your accessories, such as the radio
and air conditioner.
TRACTION SYS ACTIVE: When your Traction
Control System is limiting wheel spin, the TRACTION
SYS ACTIVE message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. The message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.TRACTION SYSTEM - ON: This message is
displayed when you decide to turn on the Traction
Control System by pressing the switch on the console.
This message will shut off automatically on its own.
TRACTION SYSTEM
- OFF: You will hear a single
quick tone when this message is displayed. This message
comes on and stays on when the Traction Control System
button on the console is pressed to turn the system off.
To acknowledge this message, press RESET.
SERVICE TRACTION SYSTEM: If the SERVICE
TRACTION SYS message is displayed when you are
driving, there is a problem with your Traction Control
System and your vehicle is in need of service. When this
message is displayed, the system will not limit wheel
spin. Adjust your driving accordingly.
If you have the optional Active Handling System, the
SERVICE ACTIVE HNDLG message will also be
displayed and the instrument cluster car icon will also be
illuminated. The driver can acknowledge both messages
by pressing the reset button two times which will also
turn off the instrument cluster icon. When the service
messages are displayed, the computer controlled
systems will not assist the driver in controlling the
vehicle. Have the system repaired as soon as possible.
Adjust your driving accordingly.
