2001.5 Peugeot 106 Dag Owner's Manual

Battery
To charge the battery with a battery
charger:
Ð Disconnect the battery starting with the negative ( Ð) terminal.
Ð
Follow the instructions for use given
by the charger manufacturer.
Ð Re-connect starting with the positive (+) terminal.
Ð Check that the terminals and posts are clean. If they arecovered with sulphation (a whiteor green deposit), undo them andclean them. To start and charge the batteryfrom another battery: Make sure that the connections are correct:
- Connect the red cable to the
positive (+) terminals of both bat- teries.
- Connect one end of the green or black cable to the negative ( Ð
)
terminal of the auxiliary battery.
- Connect the other end of the green or black cable to an earthpoint on the broken down vehicleas far as possible from the
battery.
Operate the starter and allow theengine to run.
Wait for the engine to return to idle, then disconnect the cables. It is advisable to disconnect the battery if the vehicle is to be outof use for more than one month.
P R A C T I C A L I N F O R M AT I O N91
Ð Do not disconnect the terminals while the engine is running.
Ð Do not recharge batteries without Þrst disconnecting theterminals.
Ð
A permanent electrical supplyis necessary for operation ofthe electronic systems. If thebattery is disconnected, switchon the ignition and wait
10 seconds before starting.
However, if minor disturbancesoccur following disconnection
contact a PEUGEOT dealer.
06-05-2002

Fitting a radio
Your 106 has the following factory- Þtted equipment:
Ð Roof aerial.
Ð Coaxial aerial lead.
Ð Basic suppression.
Ð Supply to front speakers (accor-ding to speciÞcation, the wires are located in the pillars in front ofthe doors).
Ð Supply to rear speakers*.
Ð 2 x 8-way connectors. It only remains for you to connect your radio and Þt the speakers.
The connectors
A1 : Ñ
A2 : Ñ
A3 : Ñ
A4 : (+) Accessories
A5 : Ñ
A6 : (+) Parking lights
A7 : (+) Permanent
A8 : Earth
B1 : (+) Right-hand rear speakers*
B2 : (Ð) Right-hand rear speakers*
B3 : (+) Right-hand front speakers
B4 : (Ð) Right-hand front speakers
B5 : (+) Left-hand front speakers
B6 : (Ð) Left-hand front speakers
B7 : (+) Left-hand rear speakers*
B8 : (Ð) Left-hand rear speakers* Fitting speakers Provision is made for Þtting 130 mm diameter speakers in the frontdoors. (It is possible to Þt 100 mmdiameter speakers at the rear*).
Consult a PEUGEOT dealer. * According to speciÞcation
P R A C T I C A L I N F O R M AT I O N92
A
B
06-05-2002

P R A C T I C A L I N F O R M AT I O N93
To tow your 106 without lifting... A towing bar should always be used. From the front and rear:
Ð Attach the towing bar to thetowing eye.
Tow-bar This device must be Þtted by a
PEUGEOT dealer. Towing (boat, caravan, etc.)
¥ before setting out:
- check the pressure of thetyres, both on the vehicle and
on the trailer.
- check the electrical signals on the trailer.
- practice manoeuvring, in parti- cular reversing.
- grease the tow ball regularly, remove it when you have Þni-shed towing.
¥ In a caravan, distribute the load inside evenly and do not exceedthe maximum load.
¥ Always drive at a moderate speed, change gear early, bothgoing uphill and downhill. Payattention to side winds.
¥ When towing, fuel consumption increases. Do not forget to use a
roof deßector if necessary.
¥ Braking distance increases. Brake gradually and gently. Avoidjerky braking. Do not exceed your vehicleÕs
towing capacity.
Towing weight: see ÔTechnical dataÕ section. Recommended nose weight: 50 kg.
06-05-2002

T E C H N I C A L D ATA102
For your PEUGEOT, only use accessories and original parts approved by the manufacturer.
These accessories and parts are all suitable for your PEUGEOT, after being tested and approved for reliability and
safety.
A wide choice of original accessories, approved by PEUGEOT, is available through the network.They all carry the PEUGEOT guarantee. Security:Anti-theft alarms, engraving of windows, wheel anti-theft devices, fog lamps...
Comfort: Air conditioning, telephone console, seat covers, carpets, luggage compartment tray, mud ßaps, sun roof*, luggage net, armrest, door deßectors, storage under the rear parcel shelf...
Communication: Audio equipment, telephone, CB, loud speakers, CD changer, navigation...
Personalisation: Tailgate spoiler, alloy wheels, Þnishers, steering wheels, sport exhaust...
Leisure: Towbar, roof bars, roof box, carriers (for bicycles, skis...)
Children: Booster seats and child seats, side blinds and rear blind...
Maintenance products: Windscreen wiper ßuid, internal and external cleaning and maintenance products...
* As the Þtting of a sun roof may involve cutting the roof strengthener, it is imperative that only original PEUGEOTproducts are used.
06-05-2002

T E C H N I C A L D ATA94
PETROL
Models model codes 1CHFF
1AHFF 1CKFW 1CNFXF
1SHFF 1AKFW
Engines HFX KFW NFX
Capacity (cm 3
) 1124 1360 1587
Bore x stroke (mm) 72 x 69 75 x 77 78,5 x 82
Maximum power EU standard (Kw) 44,1 55 87
Maximum power at (rpm) 5500 5500 6600
Maximum power EU standard (Nm) 94 120 145
Maximum torque at (rpm) 3500 3400 5200
Fuel Unleaded Unleaded UnleadedCatalytic converter YES YES YES
GearboxManual (5 gears) Manual (5 gears)
Unit capacities (in litres)
Engine (with/without Þlter change) 2,9 / 3,0 2,9 / 3,0 2,9 / 3,2Gearbox - Þnal drive 2 2 2
Fuel tank 45 45 45
Data
06-05-2002

T E C H N I C A L D ATA95
DIESEL
Models 1CVJXF
model codes 1AVJXF
1SVJXF
Engines VJX
Capacity (cm 3
) 1527
Bore x stroke (mm) 77 x 82
Maximum power EU standard (Kw) 42
Maximum power at (rpm) 5000
Maximum power EU standard (Nm) 95
Maximum torque at (rpm) 2250
Fuel Diesel
Catalytic converter (1)
GearboxManual(5 gears)
Unit capacities (in litres) Engine (with/without Þlter change) 4,25 / 4,50
Gearbox - Þnal drive 2,4
Fuel tank 45
Data (1) According to country
06-05-2002

T E C H N I C A L D ATA96
According to current directive. MPG (litres/100km)
Engine Gearbox Model code Urban Out-of-town Mixed CO21C..., 1A..., 1S...driving driving drivingemission weight
1124 cm3
MA/5 HFX 35.3 (8.0) 56.6 (5.0) 46.3 (6.1) 145
1360 cm3
MA/5 KFWF 34.4 (8.2) 56.5 (5.0) 45.6 (6.2) 148
1360 cm3
(sport) MA/5 KFWU 33.6 (8.4) 54.3 (5.2) 44.1 (6.4) 152
MA/5 NFXF 22.4 (12.6) 45.6 (6.2) 33.2 (8.5) 201
1527 cm3
Diesel MA/5 VJX 41.5 (6.8) 65.7 (4.3) 54.3 (5.2) 138
Fuel consumption
1587 cm 3
16 valves
Fuel consumption Þgures correct at the time of printing.
06-05-2002

T E C H N I C A L D ATA97
3 DOOR HATCHBACK
Model codes: 1 C... HFF KFW NFXF VJXF
¥ Kerb weight 815 815 950 875
¥ Maximum vehicle weight 1295 1315 1386 1375
¥ Gross train weight (GTW) 1945 2015 1886 2075
¥ Unbraked trailer 400 400 400 400
¥ Braked trailer (within the GTW limit) 650 700 700 700
Loads and towing weights (in kg)
5 DOOR HATCHBACK
Model codes: 1 A... HFF KFW VJXF
¥ Kerb weight 835 835 895
¥ Maximum vehicle weight 1315 1335 1395
¥ Gross train weight (GTW) 1965 2035 2095
¥ Unbraked trailer 400 400 400
¥ Braked trailer (within the GTW limit) 650 700 700
VA N
Model codes: 1 S... HFF VJXF
¥ Kerb weight 800 860 ¥ Maximum vehicle weight 1295 1375
¥ Gross train weight (GTW) 1945 2075
¥ Unbraked trailer 400 400
¥ Braked trailer (within the GTW limit) 650 700
06-05-2002
