2000 YAMAHA TDM 850 Owners Manual

1
1-1
1-GIVE SAFETY THE RIGHT OF WAY
EAU00021
Motorcycles are fascinating vehicles, which can give you an unsurpassed feeling of power and
freedom. However, they also impose certain limits, which you must accept; even the best motorcycle
does not ignore the laws of physics.
Regular care and maintenance are essential for preserving your motorcycle’s value and operating
condition. Moreover, what is true for the motorcycle is also true for the rider: good performance
depends on being in good shape. Riding under the influence of medication, drugs and alcohol is, of
course, out of the question. Motorcycle riders - more than car drivers - must always be at their mental
and physical best. Under the influence of even small amounts of alcohol, there is a tendency to take
dangerous risks.
Protective clothing is as essential for the motorcycle rider as seat belts are for car drivers and
passengers. Always wear a complete motorcycle suit (whether made of leather or tear-resistant
synthetic materials with protectors), sturdy boots, motorcycle gloves and a properly fitting helmet.
Optimum protective wear, however, should not encourage carelessness. Though full-coverage
helmets and suits, in particular, create an illusion of total safety and protection, motorcyclists will
always be vulnerable. Riders who lack critical self-control run the risk of going too fast and are apt to
take chances. This is even more dangerous in wet weather. The good motorcyclist rides safely,
predictably and defensively - avoiding all dangers, including those caused by others.
Enjoy your ride!
Give safety the right of way
E_4tx_Label.fm Page 1 Saturday, October 16, 1999 9:35 AM

DESCRIPTION
2
Left view ............................................................................................. 2-1
Right view ........................................................................................... 2-2
Controls/Instruments .......................................................................... 2-3
E_4tx_DescriptionTOC.fm Page 1 Saturday, October 16, 1999 9:35 AM

2-1
2
EAU00026
2-DESCRIPTIONLeft view1. Coolant reservoir tank (page 6-10)
2. Helmet holder (page 3-13)
3. Seat lock (page 3-12)
4. Rear shock absorber spring preload
adjusting nut (for fine adjustment) (page 3-15)
5. Rear shock absorber damping force
adjusting knob (page 3-16)
E_4tx_Description.fm Page 1 Saturday, October 16, 1999 9:36 AM

DESCRIPTION
2-2
2
Right view6. Luggage strap holders (page 3-17)
7. Rear shock absorber spring preload adjusting lever
(for coarse adjustment) (page 3-15)
8. Fuses (page 6-29)
9. Engine oil level check window (page 6-8)
10. Front fork spring preload adjusting bolt (page 3-14)
11. Front fork damping force adjusting screw (page 3-14)
E_4tx_Description.fm Page 2 Saturday, October 16, 1999 9:36 AM

DESCRIPTION
2-3
2
Controls/Instruments12. Clutch lever (page 3-8)
13. Handlebar switches (page 3-6)
14. Starter (choke) “ ” (page 3-7)
15. Speedometer (page 3-3)
16. Main switch/steering lock (page 3-1)17. Tachometer (page 3-4)
18. Fuel gauge (page 3-5)
19. Throttle grip (page 6-16)
20. Front brake lever (page 3-9)E_4tx_Description.fm Page 3 Saturday, October 16, 1999 9:36 AM

3
INSTRUMENT AND CONTROL FUNCTIONS
Main switch/steering lock ...................................... 3-1
Indicator lights ...................................................... 3-2
Speedometer ........................................................ 3-3
Tachometer ........................................................... 3-4
Diagnosis device................................................... 3-5
Antitheft alarm (optional) ...................................... 3-5
Fuel gauge ............................................................ 3-5
Handlebar switches .............................................. 3-6
Starter (choke) “ ” .............................................. 3-7
Clutch lever ........................................................... 3-8
Shift pedal ............................................................. 3-8
Front brake lever ................................................... 3-9Rear brake pedal.................................................. 3-9
Fuel tank cap ..................................................... 3-10
Fuel .................................................................... 3-11
Fuel tank breather hose (for Germany only) ...... 3-12
Seat.................................................................... 3-12
Helmet holder..................................................... 3-13
Storage compartment ........................................ 3-13
Front fork adjustment ......................................... 3-14
Rear shock absorber adjustment ....................... 3-15
Luggage strap holders ....................................... 3-17
Sidestand ........................................................... 3-17
Sidestand/clutch switch operation check............ 3-17
E_4tx_FunctionsTOC.fm Page 1 Saturday, October 16, 1999 9:36 AM

3-1
3
EAU00027
3-INSTRUMENT AND CONTROL FUNCTIONS
EAU00029*
Main switch/steering lockThe main switch controls the ignition
and lighting systems. Its operation is
described below.
EAU00036
ON
Electrical circuits are switched on. The
engine can be started. The key cannot
be removed in this position.
EAU00038
OFF
All electrical circuits are switched off.
The key can be removed in this posi-
tion.
EAU00040
LOCK
The steering is locked in this position
and all electrical circuits are switched
off. The key can be removed in this po-
sition.
To lock the steering, turn the handle-
bars all the way to the left. While push-
ing the key into the main switch, turn it
from “OFF” to “LOCK” and remove it.
To release the lock, turn the key to
“OFF” while pushing.
EW000016
WARNING
@ Never turn the key to “OFF” or
“LOCK” when the motorcycle is
moving. The electrical circuits will
be switched off which may result in
loss of control or an accident. Be
sure the motorcycle is stopped be-
fore turning the key to “OFF” or
“LOCK”. @1. Push
2. Turn
E_4tx_Functions.fm Page 1 Saturday, October 16, 1999 9:36 AM

INSTRUMENT AND CONTROL FUNCTIONS
3-2
3
EAU00048
(Parking)
The steering is locked in this position,
and the taillight and auxiliary light come
on but all other circuits are off. The key
can be removed in this position.
To use the parking position, first lock
the steering, then turn the key to “ ”.
Do not use this position for an extend-
ed length of time as the battery may
discharge.
EAU00056
Indicator lights
EAU00058
Turn indicator lights “ ” / “ ”
The corresponding indicator flashes
when the turn switch is moved to the
left or right.
EAU00061
Neutral indicator light “ ”
This indicator comes on when the
transmission is in neutral.
EAU00063
High beam indicator light “ ”
This indicator comes on when the
headlight high beam is used.
EAU01707
Coolant temperature indicator light
“”
This indicator light comes on when the
engine overheats. If the light comes on,
stop the engine immediately and allow
the engine to cool. To check that the in-
dicator light is working properly:l
Turn the engine stop switch to
“ ” and the main switch to “ON”.
l
Put the transmission in neutral or
apply the clutch lever.
l
Push the start switch.
If the indicator light does not come on
while pushing the start switch, have a
Yamaha dealer inspect the electrical
circuit.
EC000002
CAUTION:@ When the engine is overheated, do
not continue riding. @
1. Left turn indicator light “ ”
2. Neutral indicator light “ ”
3. High beam indicator light “ ”
4. Coolant temperature indicator light “ ”
5. Right turn indicator light “ ”
6. Fuel indicator light “ ”
E_4tx_Functions.fm Page 2 Saturday, October 16, 1999 9:36 AM
