INSTRUMENT AND CONTROL FUNCTIONS
3-9
3
EAU00160
Front brake leverThe front brake lever is located on the
right handlebar and is equipped with a
position adjuster.
To activate the front brake, pull the le-
ver toward the handlebar.To adjust the front brake lever position,
turn the adjusting nut while pulling the
lever forward. Make sure the mark “ ”
on the adjusting nut is aligned with the
mark “ ” on the lever.
EAU00162
Rear brake pedalThe rear brake pedal is on the right
side of the motorcycle. Press down on
the brake pedal to apply the rear brake.
1. Brake lever position adjuster
a. Lever distance
1. Adjusting nut
2. Proper position
1. Rear brake pedal
