Even if the anti±lock brake system should
fail, the brake system will still operate
conventionally. However, when the ºABSº
warning light is on (and the brake system
warning light is off), the anti±lock brake
system is not assisting brake performance
so that the wheels can lock±up during
sudden braking or braking on slippery
road surfaces. Have your vehicle checked
by your Toyota dealer as soon as pos-
sible.
DRUM±IN±DISC TYPE PARKING BRAKE
SYSTEM (1MZ±FE engine)
Your vehicle has a drum±in±disc type
parking brake system. This type of brake
system needs bedding±down of the brake
shoes periodically or whenever the parking
brake shoes and/or drums are replaced.
Have your Toyota dealer perform the bed-
ding±down.
Brake pad wear limit indicators
The brake pad wear limit indicators on
your disc brakes give a warning noise
when the brake pads are worn to where
replacement is required.
If you hear a squealing or scraping noise
while driving, have the brake pads
checked and replaced by your Toyota
dealer as soon as possible. Expensive ro-
tor damage can result if the pads are not
replaced when necessary.
Luggage stowage precautions
When stowing luggage or cargo in the
vehicle, observe the following:

Put luggage or cargo in the trunk when
at all possible. Be sure all items are
secured in place.

Be careful to keep the vehicle bal-
anced. Locating the weight as far for-
ward as possible helps maintain bal-
ance.

For better fuel economy, do not carry
unneeded weight.
CAUTION

To prevent luggage or packages
from sliding forward during braking,
do not stack anything in the en-
larged trunk. Keep luggage or pack-
ages low, as close to the floor as
possible.

'99camry U
166

Never allow anyone to ride in the
enlarged trunk. It is not designed
for passengers. They should ride in
their seats with their seat belts
properly fastened. Otherwise, they
are much more likely to suffer seri-
ous bodily injury, in the event of
sudden braking or a collision.

Do not place anything on the filler
panel behind the rear seatback.
Such items may be thrown about
and possibly injure people in the
vehicle during sudden braking or an
accident.

Do not drive with objects left on
top of the instrument panel. They
may interfere with the driver's field
of view. Or they may move during
sharp vehicle acceleration or turn-
ing, and impair the driver's control
of the vehicle. In an accident they
may injure the vehicle occupants.
NOTICE
Do not load the vehicle beyond the
vehicle capacity weight specified in
Part 8.
The vehicle identification number (VIN)
is the legal identifier for your vehicle.
This number is on the left top of the
instrument panel, and can be seen
through the windshield from outside.
This is the primary identification number
for your Toyota. It is used in registering
the ownership of your vehicle.The vehicle identification number (VIN) is
also on the Certification Label.
Your Toyota's identificationÐ
ÐVehicle identification
number

'99camry U
205
Tire surface and wheel nuts
Check the tires carefully for cuts, damage
or excessive wear. See Chapter 7±2 for
additional information. When checking the
tires, make sure no nuts are missing, and
check the nuts for looseness. Tighten
them if necessary.
Tire rotation
Rotate the tires every 12000 km (7500
miles). See Chapter 7±2 for additional in-
formation.
Fluid leaks
Check underneath for leaking fuel, oil, wa-
ter or other fluid after the vehicle has
been parked for a while. If you smell fuel
fumes or notice any leak, have the cause
found and corrected immediately.
Doors and engine hood
Check that all doors including trunk lid
operate smoothly and all latches lock se-
curely. Make sure the engine hood sec-
ondary latch secures the hood from open-
ing when the primary latch is released.
INSIDE THE VEHICLE
Items listed below should be checked
regularly, e.g. while performing periodic
services, cleaning the vehicle, etc.Lights
Make sure the headlights, stop lights, tail
lights, turn signal lights, and other lights
are all working. Check headlight aim.
Service reminder indicators and warning
buzzers
Check that all service reminder indicators
and warning buzzers function properly.
Steering wheel
Be alert for changes in steering condition,
such as hard steering or strange noise.
Seats
Check that all front seat controls such as
seat adjusters, seatback recliner, etc. op-
erate smoothly and that all latches lock
securely in any position. Check that the
head restraints move up and down
smoothly and that the locks hold securely
in any latched position. For folding±down
rear seatbacks, check that the latches
lock securely.
Seat belts
Check that the seat belt system such as
buckles, retractors and anchors operate
properly and smoothly. Make sure that the
belt webbings not cut, frayed, worn or
damaged.Accelerator pedal
Check the pedal for smooth operation and
uneven pedal effort or catching.
Clutch pedal
Check the pedal for smooth operation.
Brake pedal
Check the pedal for smooth operation and
that the pedal has the proper clearance.
Check the brake booster function.
Brakes
At a safe place, check that the brakes do
not pull to one side when applied.
Parking brake
Check that the lever has the proper travel
and that, on a safe incline, your vehicle
is held securely with only the parking
brake applied.
Automatic transmission ºParkº mecha-
nism
Check the lock release button of the se-
lector lever for proper and smooth opera-
tion. On a safe incline, check that your
vehicle is held securely with the selector
lever in ºPº position and all brakes re-
leased.

'99camry U
245
Engine compartment (type B)
14. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, personal
light, trunk light, electric moon roof
lamp, interior light, vanity mirror light,
door courtesy light, power door lock
system
15. ECU±B 10 A: Cruise control system,
anti±lock brake system, SRS airbag
system, seat belt pretensioners
16. DRL NO.2 5 A: Daytime running light
system
Instrument panel
17. H±LP LH(LWR) 10 A: Left±hand head-
light
18. H±LP RH(LWR) 10 A: Right±hand
headlight
19. A/F HTR 25 A: A/F sensor
20. SEAT±HEATER 20 A: No circuit
21. HEATER 10 A: Air conditioning system,
rear window defogger, starting system22. GAUGE 10 A: Gauges and meters,
back±up lights, cruise control system,
charging system, traction control sys-
tem, daytime running light system,
power windows, service reminder indi-
cators and warning buzzers
23. WIPER 25 A: Windshield wipers and
washer
24. MIRROR±HEATER 10 A: Outside rear
view mirror defogger
25. ECU±IG 15 A: Cruise control system,
anti±lock brake system, power antenna,
SRS airbag system, seat belt preten-
sioners, theft deterrent system, shift
lock control system, traction control
system, daytime running light system,
locking with wireless remote control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
26. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/sequential multiport fuel injec-
tion system

N13159
N13160
I08491
GND
PRG
PRG
GND
Wireless Door
Lock ECU
Remote Control Mirror
Switch Connector
DI±804
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1039 Author: Date:
(d) Replace the battery for transmitter.
(1) Using a screwdriver, pry outward the cover.
(2) Remove the battery.
(3) Set a new battery into the transmitter.
(4) Install the cover to the transmitter.
3. REGISTRATION OF RECOGNITION CODE
The recognition code of the transmitter is electronically regis-
tered (written to and stored) in an EEPROM contained in the
wireless door lock ECU. This makes it possible to register up to
2 different codes in the EEPROM.
New recognition codes can be registered after all previous
codes have been erased. A transmitter code can be registered
into the EEPROM by following the steps numbered (1) to (5).
(1) The wireless door lock ECU and remote control mir-
ror switch are connected to each other via a PRG
terminal, and the GND terminal of the remote con-
trol mirror switch connector is grounded to body.
Remove the connector from the remote control mir-
ror switch, and use a test lead to short the PRG and
GND connector together. As a result, the PRG ter-
minal of the wireless door lock ECU will be
grounded to body and will cause all transmitter rec-
ognition codes previously registered in the EE-
PROM to be erased. At the same time, the ECU will
respond by operating once the lock and unlock
functions of all the doors, and the open function of
the trunk lid.

Toyota Supports ASE CertificationPage 1 of 1
AX001-01Title:
RETRO-FIT INTERNAL TRUNK
RELEASE KITS
Models:
All Applicable '90 ± '00 Models
Technical Service
BULLETIN
March 9, 2001

In order to respond to requests of our valued customers, we are offering Retro±Fit
Internal Trunk Release Kits. These kits allow the trunk to be opened from the inside in
case of entrapment.
MODELMODEL CODEMODEL YEAR# CLAMPS
AvalonMCX101995 ± 19994AvalonMCX2020004
CamrySXV10, MCV10, VCV101992 ± 19964CamrySXV20, MCV201997 ± 20004
Celica (Coupe)AT200, ST2041994 ± 19994
Corolla (Sedan)AE10#1993 ± 19974Corolla (Sedan)ZZE1101998 ± 20005
ECHONCP1220004
MR2SW20, 211990 ± 19952
PaseoEL441992 ± 19954PaseoEL541996 ± 19994
SolaraSXV20, MCV201999 ± 20004
TercelEL421991 ± 19944TercelEL531995 ± 19994
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
±64640±33030Trunk Release
±64610±17040Trunk Release (MR2 Only)
±90464±00551Clamp
±MDC 00107±00316±TRInstallation Instructions
Order the appropriate trunk release, at least as many clamps as listed above, and a set
of installation instructions. Follow the installation procedure detailed in the installation
instructions. Installation time is 0.7 hours.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Parts
Information
Installation
Procedure
Warranty
Information

Toyota Supports ASE CertificationPage 1 of 2
AX003±00Title:
PORT INSTALLED RS3000 TVIP TRUNK
COURTESY CONNECTION
Models:
'99 Camry
Technical Service
BULLETIN
March 31, 2000

The trunk courtesy connection for 1999 model year Camry vehicles equipped with a Port
Installed Option RS3000 (V3) has been relocated from the luggage compartment light
switch to below the dash (lower finish panel) on the driver's side in the Instrument Panel
J/B. (Refer to Illustrations A & B on page 2.)
The location was changed to improve the installation process.
A splicing connector is used for the new trunk courtesy wire installation (blue) to the
vehicle's wire harness at Instrument Panel J/B (red/yellow).
The previous location is the same as the dealer installed RS3000 trunk courtesy
connection to the luggage compartment light switch connection.
For service related purposes, this bulletin describes the procedures to locate the new
trunk courtesy connection at Instrument Panel J/B in vehicles equipped with PIO
RS3000.
The remote transmitter has two
buttons, Top and Bottom.The status monitor has a Toyota label,
LED, and microphone.
Remote Control
LED
Status Monitor
Microphone
1999 model year Camry vehicles equipped with PIO (V3) TVIP.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Warranty
Information

PORT INSTALLED RS3000 TVIP TRUNK COURTESY CONNECTION ± AX003±00 March 31, 2000
Page 2 of 2
New Location:
These steps below are to be followed to
locate the new trunk courtesy connection
when servicing Camry vehicles equipped
with the PIO RS3000 TVIP.
1. Remove the negative battery cable.
2. Remove the driver's step cover.
3. Remove the driver's cowl cover (1
nut).
4. Locate the Connector Junction Block
in the driver's cowl area. You will
notice a RED/YELLOW wire routed to
the Blue 10P connector which
terminates at an adjacent splicing
connector. This is the TVIP Trunk
Courtesy Wire.
5. Disconnect the Blue 10P connector
from the Connector Junction Block.
With the tab of the Blue 10P
connector facing up, look at the back
(wire side) and locate the wire in the
bottom row, second space from the
right, which has the splicing connector
attached to it. This is the Vehicle's
Trunk Courtesy Signal Wire.
6. After completing the parts inspection
and repairs if applicable, reconnect
the Blue 10P connector and install all
previously removed parts.
Previous Location:
The White 1P connector for the Vehicle's
Trunk Courtesy Signal is located at the
trunk courtesy lamp switch near the trunk
latch in the vehicle's trunk.
Locating
Procedure
Connector
Junction Block
Illustration A
10P
Connector
(Blue)
TVIP Trunk
Courtesy Wire
(Yellow/Red)
Illustration B
Splicing
Connector
10P
Connector
(Blue)
Wire Side View
