2000 SUZUKI SWIFT RG413 Service Workshop Manual

Page 209 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual 3D-16 FRONT SUSPENSION
Connect tie rod end (1) to steering knuckle (2) and tighten tie
rod end castle nut (3) to specified torque.
Tightening torque
The rod end castle nut (a) : 43 N·m (4.3 kg-m, 31

Page 210 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual FRONT SUSPENSION 3D-17
3) Remove suspension control arm bolt (1).
4) Remove suspension control arm (2).
DISASSEMBLY
1) Remove bushing.
Place suspension control arm onto flat surface side of spe-
cial

Page 211 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual 3D-18 FRONT SUSPENSION
2) Press-fit bushing so that dimensions “A” and “B” in figure
become equal.
INSTALLATION
1) Install body side of suspension control arm but tighten sus-
pension control

Page 212 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual FRONT SUSPENSION 3D-19
REQUIRED SERVICE MATERIAL
SPECIAL TOOL
MaterialRecommended SUZUKI product
(Part Number)Use
Lithium grease SUZUKI SUPER GREASE A
(99000-25010)Strut bearing
09900-00411 09900-004

Page 213 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual 3D-20 FRONT SUSPENSION

Page 214 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual REAR SUSPENSION 3E-1
6F1
6F2
6G
1A
6K
7A
7A1
7B1
7C1
3E
8A
8B
8C
8D
8E
9
10
10A
10B
SECTION 3E
REAR SUSPENSION
CONTENTS
GENERAL DESCRIPTION ..............................  3E-2
DIAGNOSIS .............

Page 215 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual 3E-2 REAR SUSPENSION
GENERAL DESCRIPTION
Rear suspension is Isolated Trailing Link (l.T.L.) type which consists of coil springs, rear axle, rear axle housing,
shock absorbers, lateral rod and trailing

Page 216 of 698

SUZUKI SWIFT 2000 1.G RG413 Service Workshop Manual REAR SUSPENSION 3E-3
4WD vehicle
1. Rear coil spring 5. Lateral rod  9. Brake drum 13. Oil seal
2. Rear bump stopper 6. Trailing arm  10. Rear axle shaft 14. Wheel bearing retainer ring
3. Rear spring
