2000 LEXUS GS300/GS400 (RM718U)
THROTTLE BODY
ON±VEHICLE INSPECTION
1. REMOVE ENGINE COVER
Remove the 4 nuts and engine cover.
2. INSPECT SYSTEM OPERATION
(a) Check that the throttle linkage moves smoothly.
(b) Inspect the throttle control motor for operating sound.
(1) Turn the ignition switch ON.
(2) When turning the accelerator pedal position sensor
lever, check the running sound of the motor. Also,
check that there is no friction sound.
If operation is not as specified, check the throttle control motor,
wiring and ECM.
(c) Inspect the throttle position sensor and accelerator pedal
position sensor function.
(1) Connect the LEXUS hand±held tester to the DLC3.
(2) When turning the accelerator pedal position sensor
lever to the full±open position, check that the
throttle valve opening percentage (THROTTLE
POS) of the CURRENT DATA showns the standard
value.
Throttle valve opening percentage: 60 % or more
If operation is not as specified, check that the throttle position
sensor, accelerator pedal position sensor, wiring and ECM.
(d) Start the engine, and check that the Malfunction Indicator
Lamp (MIL) does not light up.
(e) Inspect the air assist system.
(1) Allow the engine to warm up to normal operating
temperature.

B09507
B01620
Ohmmeter3 (CL±)
4 (CL+)
1 (M+)
2 (M±)
B01942VCOhmmeter
E2
B01943
VC Ohmmeter
E2
± SFI (2JZ±GE)THROTTLE BODY
SF±33
1499 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(2) Turn the A/C switch ON and OFF, and check the idle
speed.
Idle speed (Transmission in neutral):
700 ± 50 rpm (A/C OFF)
750 ± 50 rpm (A/C ON)
NOTICE:
Perform inspection under condition without electrical load.
(3) With engine idling, pinch the air assist hose and
check that engine speed drops, and then returns
back up to idle speed.
If operation is not as specified, check the throttle body, wiring
and ECM.
(f) After checking the above (b) to (e), perform the diving test
and check that there is no sense of incongruity.
3. INSPECT THROTTLE CONTROL MOTOR
(a) Disconnect the throttle control motor connector.
(b) Using an ohmmeter, measure the resistance between ter-
minal 3 (CL±) and 4 (CL+).
Resistance: 4.2 ± 5.2 W at 20°C (68°F)
(c) Using an ohmmeter, measure the resistance between ter-
minal 1 (M+) and 2 (M±).
Resistance: 0.3 ± 100 W at 20°C (68°F)
If the resistance is not as specified, replace the throttle control
motor. (See page SF±37)
(d) Reconnect the throttle control motor connector.
4. INSPECT THROTTLE POSITION SENSOR
(a) Disconnect the throttle position sensor connector.
(b) Using an ohmmeter, measure the resistance between ter-
minals VC and E2.
Resistance: 1.2 ± 3.2 kW at 20°C (68°F)
If the resistance is not as specified, replace the throttle position
sensor. (See page SF±37)
(c) Reconnect the throttle position sensor connector.
5. INSPECT ACCELERATOR PEDAL POSITION SEN-
SOR
(a) Disconnect the accelerator pedal position sensor con-
nector.
(b) Using an ohmmeter, measure the resistance between ter-
minals VC and E2.
Resistance: 1.2 ± 3.2 kW at 20°C (68°F)
If the resistance is not as specified, replace the accelerator ped-
al position sensor. (See page SF±37)

SF±34
± SFI (2JZ±GE)THROTTLE BODY
1500 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(c) Reconnect the accelerator pedal position sensor connec-
tor.
6. REINSTALL ENGINE COVER
Reinstall the engine cover with the 4 nuts.

SF0NM±07
B09000
Intake Air Resonator
PCV Hose
PS Air Hose
Throttle Control
Motor ConnectorThrottle Body Bracket
Throttle Position Sensor Connector
Water Bypass HoseWater Bypass Hose Engine Wire ClampAccelerator Pedal Position
Sensor Connector
Accelerator Cable
21 (210, 15)
N´m (kgf´cm, ft´lbf) : Specified torqueThrottle Body
Engine Cover
B01947
CoverAccelerator Pedal Position Sensor
Washer Plate
Throttle Control Motor
Throttle Position Sensor Bracket
x 5
± SFI (2JZ±GE)THROTTLE BODY
SF±35
1501 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
COMPONENTS

SF0NN±05
B01615
B01616
Forward
Down±Side
Diagonal(2) (1)
SF±36
± SFI (2JZ±GE)THROTTLE BODY
1502 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE ENGINE COVER
Remove the 4 nuts and engine cover.
3. REMOVE INTAKE AIR RESONATOR
4. REMOVE THROTTLE BODY BRACKET AND
THROTTLE BODY
(a) Disconnect the accelerator cable.
(b) Disconnect the throttle position sensor connector.
(c) Disconnect the throttle control motor connector.
(d) Disconnect the accelerator pedal position sensor con-
nector.
(e) Disconnect the engine wire clamp from the clamp bracket
of throttle body.
(f) Remove the 2 bolts and nut holding the throttle body to
the intake air connector.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
(g) Remove the 4 nuts and throttle body bracket.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
(h) Slightly slide the throttle body away from the intake air
connector.
NOTICE:
When putting up the throttle body, do not hold the motor
part.
(i) Disconnect the 2 water bypass hoses from the throttle
body, and remove the throttle body.
HINT:

At the time of installation, please refer to the following
items.

Connect the water bypass hose with its discrimination
mark downward.

Install the with its craw direction for (1) forward and down±
side diagonal (engine side about 45°) for (2).

A02640
Ohmmeter
SF0NR±03
± SFI (2JZ±GE)CAMSHAFT TIMING OIL CONTROL VALVE
SF±41
1507 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
CAMSHAFT TIMING OIL CONTROL
VA LV E
ON±VEHICLE INSPECTION
1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE
RESISTANCE
(a) Disconnect the oil control valve connector.
(b) Using an ohmmeter, measure the resistance between the
terminals.
Resistance: 5.5 ± 12 W at 20°C (68°F)
If the resistance is not as specified, replace the valve.
(c) Reconnect the oil control valve connector.
2. INSPECT VVT±i OPERATION
(a) Allow the engine to warm up to normal operating tempera-
ture.
(b) Check that the engine stalls or becomes in rough±idling
state when the battery positive voltage is applied to the oil
control valve with the engine idling.
If operation is not as specified, check the oil control valve (see
page SF±43), VVT±i pulley, intake camshaft, wiring and ECM.

SF0NT±03
B01583
ActuatorVacuum Gauge
VSV
P10710
No Vacuum
Vacuum Gauge
P10844
Approx.
33.3 kPa
Pull
Actuator
Rod Vacuum Gauge SF±44
± SFI (2JZ±GE)ACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
1510 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ACOUSTIC CONTROL INDUCTION
SYSTEM (ACIS)
ON±VEHICLE INSPECTION
1. REMOVE ENGINE COVER
Remove the 4 nuts and engine cover.
2. CONNECT VACUUM GAUGE
Using a 3±way connector, connect vacuum gauge to the hose
between the actuator and VSV.
3. START ENGINE
4. INSPECT INTAKE AIR CONTROL VALVE
(a) While the engine is idling, check that the vacuum gauge
needle does not move.
(b) Rapidly depress the accelerator pedal to fully open posi-
tion and check that the vacuum gauge needle momentari-
ly fluctuates approx. 33.3 kPa (250 mmHg, 9.84 in.Hg) or
more. (The actuator rod is pulled down.)
5. REMOVE VACUUM GAUGE
Remove the vacuum gauge, and reconnect the vacuum hoses
to their proper locations.
6. REINSTALL ENGINE COVER
Reinstall the engine cover with the 4 nuts.

SF0NU±02
B08998
N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
21 (210, 15)
21 (210, 15)
Accelerator Cable Clamp EVAP Hose
Clamp Air Intake Chamber
(with Intake Air Control Valve)
Vacuum Hose (from
No.2 Vacuum Pipe)
Vacuum Hose

Gasket
Bracket and Noise Filter
PS Air Hose
Noise Filter
Connector
Engine Wire Clamp
Gasket
VSVVacuum Control Valve Set
Engine Wire Clamp
Vacuum Tank
Vacuum Hose
VSV Connector
Oil Dipstick and Guide for A/T
O±Ring
28 (280, 21)
Engine Cover
± SFI (2JZ±GE)ACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
SF±45
1511 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
COMPONENTS
